Lex System 2I110D Manual

Intel tiger lake-up3 core i /celeron processor, ddr4 lan / hdmi / usb / m.2 / com
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DDR4 LAN / HDMI / USB / M.2 / COM
11th gen. Intel Tiger Lake-U Core™ I / Celeron CPU
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 2I110D
Release date: AUG. 31. 2022
2I110D
Intel® Tiger Lake-UP3 Core™ I /
Celeron processor,
HDMI, eDP, 2 x M.2, USB
Multi-LAN, COM, 1 x Nano SIM
All-In-One

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2I110D and is the answer not in the manual?

Questions and answers

Related Manuals for Lex System 2I110D

Summary of Contents for Lex System 2I110D

  • Page 1 11th gen. Intel Tiger Lake-U Core™ I / Celeron CPU HDMI, eDP, 2 x M.2, USB Multi-LAN, COM, 1 x Nano SIM CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 2I110D Release date: AUG. 31. 2022...

  • Page 2: Table Of Contents

    1-4 DIRECTIONS FOR INSTALLING THE M.2B KEY MINI CARD ........CHAPTER 2 HARDWARE INSTALLATION ..............2-1 DIMENSION-2I110D ....................2-2 LAYOUT-2I110D-CONNECTOR AND JUMPER TOP ..........2-2-1 LAYOUT-2I110D-CONNECTOR AND JUMPER BOTTOM BOT ....... 2-3 LAYOUT-2I110D-FUNCTION MAPTOP ............... 2-3-1 LAYOUT-2I110D-FUNCTION MAP BOT ..............2-4 DIAGRAM-2I110D TOP ....................
  • Page 3 3-14 NGFF1 M.2 NGFF CARD B KEY SOCKETS 75 PIN ..........3-15 NGFF2 M.2 NGFF CARD M KEY SOCKETS 75 PIN ..........3-16 SIM1: NANO SIM CARD SOCKET ................3-17 CONNECTOR WAFER OF COMPATIBLE BRAND AND PART NUMBER LIST ..CHAPTER 4 INTRODUCTION OF BIOS ................
  • Page 4 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 5: Warning

    Warning ! Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fanless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.

  • Page 6: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 7 Photo 1 Insert Unplug...

  • Page 8: Chapter 1 General Information

    General Information The 2I110D is an ultra compact (102 x 108 mm) SBC with11th Gen. Intel® Tiger Lake UP3 i7 / i5 / i3 / Celeron processor, integrated 4 x GbE LAN, 9 x USB, 2 x COM Port and HDMI, eDP display interface that off...

  • Page 9: Major Feature

    1-1 Major Feature Intel® Core i3-1115GRE Processor 2.2GHz / 3.9GHz (Quad core), Intel® Core i7-1185GRE Processor 1.8GHz / 4.4GHz (Quad core). Intel® UHD Graphics for 11th Gen Intel® Processors, Intel® Iris® Xe Graphics. DDR4 SODIMM slot x 1, up to 32GB. Support 1 x 10 / 100 / 1000 Mbps &...

  • Page 10: Specification

    1-2 Specifi cation SOC: Intel® Core i3-1115GRE Processor 2.2GHz / 3.9GHz (Quad core), Intel® Core i7-1185GRE Processor 1.8GHz / 4.4GHz (Quad core). Memory: DDR4 SODIMM slot x 1, up to 32GB. Graphics: Intel® UHD Graphics for 11th Gen Intel® Processors, Intel®...

  • Page 11: Installing The So-Dimm

    1-3 Installing the SO-DIMM 1. Align the SO-DIMM with the connector at a 45 degree angle. 2. Press the SO-DIMM into the connector until you hear a click.
  • Page 12 Notices: 1.The connectors are designed to ensure the correct insertion. If you feel resistance, check t h e connectors & golden fi nger direction, and realign the card. 2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of the card fi...

  • Page 13: Removing The So-Dimm

    1-3-1-1 Removing the SO-DIMM 1. Release the SO-DIMM by pulling outward the two retaining clips and the SO-DIMM pops up slightly. 2. Lift the SO-DIMM out of its connector carefully.

  • Page 14: Directions For Installing The M.2B Key Mini Card

    1-4 Directions for installing the M.2B Key Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 15: Chapter 2 Hardware Installation

    Chapter-2 2-1 Dimension-2I110D...

  • Page 16: Layout-2I110D-Connector And Jumper Top

    2-2 Layout-2I110D-Connector and Jumper CFP1 CU8 CU10 NGFF2 HDMI1 CIO1 EDP1 JVL1 NGFF1 JAT1 JSB1 SODIM1 CPU FAN1 CPO1 CPI1...

  • Page 17: Layout-2I110D-Connector And Jumper Bottom Bot

    2-2-1 Layout-2I110D-Connector and Jumper Bottom SIM1 SATA1...

  • Page 18: Layout-2I110D-Function Maptop

    2-3 Layout-2I110D-Function MAP Front Panel COM2 PCIe x4 & mSATA COM1 Ext. Battery USB 2.0 USB 2.0 USB 2.0 HDMI Clear CMOS Jumper HW always on jumper eDP Panel Power Jumper PCIe X2 & USB3.0/2.0 DDR4 SODIMM SM BUS CPU FAN...

  • Page 19: Layout-2I110D-Function Map Bot

    2-3-1 Layout-2I110D-Function MAP Nano SIM USB 3.0 USB 3.0 USB 3.0 SATA...

  • Page 20: Diagram-2I110D Top

    2-4 Diagram- 2I110D CFP1 CU8 CU10 NGFF2 HDMI1 CIO1 EDP1 JVL1 NGFF1 JAT1 JSB1 SODIM1 CPU FAN1 CPO1 CPI1...

  • Page 21: Diagram-2I110D Bot

    2-4-1 Diagram- 2I110D SIM1 SATA1...

  • Page 22: Function Map-2I110D

    2-5 Function MAP- 2I110D COM2 COM1 Front Panel USB 2.0 Ext. Battery PCIe x4 & mSATA Clear CMOS jumper HW always on jumper eDP Panel Power jumper PCIe x2 & USB 3.0 & 2.0 DDR4 SODIMM SM BUS CPU FAN...

  • Page 23: List Of Jumpers

    2-6 List of Jumpers JSB1: CMOS DATA Clear JAT1: HW system always on JVL1: eDP panel power select 2-7 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap.

  • Page 24: Jsb1: Cmos Data Clear

    2-8 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin1 and pin 2 of JSB1 to store the CMOS data. To clear the CMOS, follow the procedures below: 1. Turn off the system and unplug the AC power 2.

  • Page 25: Jat1: Hw System Always On

    2-9 JAT1: HW system always on JAT1 DESCRIPTION *1-2 Normal Set HW system always on JAT1 HW system always on *Normal Set 2-10 JVL1: eDP panel power select JVL1 DESCRIPTION *2-3 +3.3V Note: Attention! Check Device Power in spec JVL1 *+3.3V...

  • Page 26: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CPI1: DC 12V-IN 2x4 pin (2.0mm) Red wafer CBT1: COMS battery 1x2 pin (1.25mm) wafer CC1~CC2: COM 2x5 pin (2.0mm) wafer CFP1:...

  • Page 27: Cmos Battery Connector

    3-2 CMOS battery connector CBT1: CMOS Battery 1x2 pin (1.25mm) Wafer. PIN NO. DESCRIPTION Note: 1. When the board without Adaptor plug in, this board power RTC consumption about 2.7uA 2. If adaptor always plug in RTC power consumption about 0.1uA CBT1 pin1...

  • Page 28: Com Interface

    3-3 COM interface CC1 / CC2: COM 2x5 pin (2.0mm) Wafer (RS232 Mode) PIN NO. DESCRIPTION PIN NO. DESCRIPTION RI / VCC (RS485 Mode) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data- Data+ (RS422 Mode) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Note: 1.

  • Page 29: Front Panel Pin Header

    3-4 Front Panel Pin Header CFP1: Front Panel connector 2x5 pin (2.0mm) Wafer PIN NO. Description PIN NO. Description Power button Reset Power LED- Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ CFP1 pin1...

  • Page 30: Dio Interface

    3-5 DIO Interface CIO1: 4DI / 4DO 2x5 pin (2.0mm) Wafer PIN NO. Description PIN NO. Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Note: 1. DIO and WDT function from SIO F81966D-I. CIO1 pin1 WDT For F81966D-I watch dog timer device: DC spec: Input low Voltage (VIL): +0.8 Max Input High Voltage(VIH): +2V Min...

  • Page 31: Io Device: F81966 Dio Under Windows

    3-5-1 IO Device: F81966 DIO under Windows The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Windows Source fi le: F81966_LPC_GPIO_Utility_Src_v1.5.zip Binary fi le: F81966_LPC_GPIO_Utility_Bin_x86_v1.5.zip F81966_LPC_GPIO_Utility_Bin_x64_v1.5.zip F81966 DLL: F81966_DLL_x32_v1.0.zip F81966_DLL_x64_v1.0.zip Introduction F81966 DIO 1. Start test Button, Send bits one by one and one by one receive 2.
  • Page 32 F81966_DLL_API BYTE F81966_LPC_Digital_Read_HIGH(); F81966_DLL_API void F81966_LPC_Digital_Write_HIGH(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Enable(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Disable(); Digital Input / Output test Note when using the following boards: 2I110D CIO1 needs to be controlled by CIO3 Digital output Digital iutput Low Byte Low Byte...
  • Page 33 sample code Set CIO1 CIO2 Digital Output all high F81966_LPC_Digital_Write_LOW(256); Set CIO1 CIO2 Digital Output all low F81966_LPC_Digital_Write_LOW(0); Set CIO1 Digital Output bit 4 high F81966_LPC_Digital_Write_LOW(16); Set CIO2 Digital Output bit 10 high F81966_LPC_Digital_Write_HIGH(4); Read Din value = F81966_LPC_Digital_Read_LOW(); Watch Dog test sample code Set WDT 10 sec F81966_LPC_Set_WDT_Enable(10);...

  • Page 34: Io Device: F81966 Dio Under Linux Console

    3-5-2 IO Device: F81966 DIO under Linux console The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Linux_console Source fi le: F81966_DIO_v1.1_Src_L.tar.gz Binary fi le: F81966_DIO_v1.1_Bin_x64_L.tar.gz F81966_DIO_v1.1_Bin_x32_L.tar.gz F81966 Libary: F81966_LIB_v1.1_x64_L.tar.gz F81966_LIB_v1.1_x32_L.tar.gz Introduction F81966 DIO 1. Start test Button, Send bits one by one and one by one receive 2.
  • Page 35 BYTE F81966_LPC_Digital_Read_LOW(); BYTE F81966_LPC_Digital_Read_HIGH(); void F81966_LPC_Set_WDT_Enable(BYTE byteValue); void F81966_LPC_Set_WDT_Disable(); void EntryLPC(); void ExitLPC(); Digital Input / Output test Note when using the following boards: 2I110D CIO1 needs to be controlled by CIO3 Digital output Digital iutput Low Byte Low Byte CIO1...
  • Page 36 sample code Set CIO1 CIO2 Digital Output all high F81966_LPC_Digital_Write_LOW(256); Set CIO1 CIO2 Digital Output all low F81966_LPC_Digital_Write_LOW(0); Set CIO1 Digital Output bit 4 high F81966_LPC_Digital_Write_LOW(16); Set CIO2 Digital Output bit 10 high F81966_LPC_Digital_Write_HIGH(4); Read Din value = F81966_LPC_Digital_Read_LOW(); Watch Dog test sample code Set WDT 10 sec F81966_LPC_Set_WDT_Enable(10);...

  • Page 37: Usb Interface

    3-6 USB Interface CU1~CU3: USB 3.0 Type A Connector PIN NO. Description PIN NO. Description VBUS SS_RX- SS_RX+ SS_TX- SS_TX+ Note: 1. The power supply 0.9A for each USB 3.0 respect specifi cation. pp y 2. CU1, CU2, CU3 support wake up for option. U1, CU2, CU3 support wake up for option.

  • Page 38: Lan Interface

    3-7 LAN Interface CL1 / CL2 / CL3 / CL4: LAN RJ45 Connector PIN NO. Description PIN NO. Description MDI0+ MDI2- MDI0- MDI1- MDI1+ MDI3+ MDI2+ MDI3- CL1: LAN RJ45 Connector for 1Giga LAN LAN LED Speed 10Mbps 100Mbps 1000Mbps Front Front Front...

  • Page 39: Co1: Smbus 1X4 Pin (1.25Mm) Wafer

    3-8 CO1: SMBus 1x4 pin (1.25mm) Wafer PIN NO. Description +3.3V SMBus Clock SMBus DATA pin1 3-9 Display Interface HDMI1: HDMI Type A Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS DATA2+ TMDS DATA2- TMDS DATA1+ TMDS DATA1- TMDS DATA0+ TMDS DATA0- TMDS CLK+ TMDS CLK-...
  • Page 40 EDP1: eDP Panel 2x10 pin (1.25mm) Wafer PIN NO. DESCRIPTION PIN NO. DESCRIPTION Lane-0-DATA- +12V or +5V Lane-0-DATA+ +12V or +5V Lane-1-DATA- Lane-1-DATA+ Backlight Enable PWM dimming for eDP I2C Clock +LCD (5V or 3.3V) I2C Data +LCD (5V or 3.3V) eDP Aux+ +LCD (5V or 3.3V) eDP Aux-...

  • Page 41: Cpi1: Dc Power Input (2X4 Pin 2.0Mm Wafer) (Red)

    3-10 CPI1: DC Power input (2x4 pin 2.0mm Wafer) (Red) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DC-IN DC-IN DC-IN DC-IN Note: 1. Very important check DC-in Voltage. CPI1 pin1 3-11 CPO1: DC +5 / +12V output 1x4 pin (2.0mm) Black Wafer PIN NO.

  • Page 42: Cpu Fan1: Cpu Fan 1X4 Pin (2.54Mm) Wafer (Option)

    3-12 CPU FAN1: CPU Fan 1x4 pin (2.54mm) Wafer (option) PIN NO. DESCRIPTION +12V CPU FAN-IN CPU FAN-OUT Note: DC in +12V by switch to FAN power +12V, so DC in need stable +12V input FAN1 pin1...

  • Page 43: Sata Interface

    3-13 SATA Interface SATA1: SATA port connectors 7pin PIN NO. Description Note: 1. CPO1 provides SATA-HDD power +12V, GND, +5V SATA1...

  • Page 44: Ngff1 M.2 Ngff Card B Key Sockets 75 Pin

    3-14 NGFF1 M.2 NGFF card B key sockets 75 pin NGFF1: size 3042 (H=8.5) PIN NO. DESCRIPTION PIN NO. DESCRIPTION CFG3_USB3_PCIE_N +3.3V +3.3V FULL_CARD_PWR_N USB2_P4_DP W_DISABLE_1_N USB2_P4_DN M2_LED_N B KEY W_DISABLE_2_N M2_PERn1_U3Rn M2_PERp1_U3Rp SIM_RST_M2 SIM_CLK_M2 M2_PETn1_U3Tn SIM_DATA_M2 M2_PETp1_U3Tp SIM_PWR_M2 M2_PERn0 M2_PERp0 M2_PETn0 M2_PETp0...
  • Page 45 PIN NO. DESCRIPTION PIN NO. DESCRIPTION MD_RESET_N SIM_DET +3.3V +3.3V CFG2 power select +3.3V Note: 1. WWAN Module For 3.7V by OEM NGFF1...

  • Page 46: Ngff2 M.2 Ngff Card M Key Sockets 75 Pin

    3-15 NGFF2 M.2 NGFF card M key sockets 75 pin NGFF2: size 2242 (H=8.5) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V PCIE4_Rn3 PCIE4_Rp3 M2_LED_N PCIE4_Tn3 +3.3V PCIE4_Tp3 +3.3V +3.3V PCIE4_Rn2 +3.3V PCIE4_Rp2 PCIE4_Tn2 PCIE4_Tp2 PCIE4_Rn1 PCIE4_Rp1 PCIE4_Tn1 PCIE4_Tp1 PCIE4_Rn0_ MSRp PCIE4_Rp0_ MSRn PCIE4_Tn0_ MSTn PCIE4_Tp0_ MSTp...
  • Page 47 PIN NO. DESCRIPTION PIN NO. DESCRIPTION CLK_SRC0_DP M KEY PCIe_SATA#_DET +3.3V +3.3V +3.3V Note: 1. NGFF2 support mSATA / PCIe Auto detect. 2. NGFF2 support PCIe x4 GEN4 NVMe device. NGFF2...

  • Page 48: Sim1: Nano Sim Card Socket

    3-16 SIM1: Nano SIM card socket PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA Note: 1. NGFF1 Pin 30, 32, 34, 36, 66 for SIM card reader use. SIM1 Nano SIM...

  • Page 49: Connector Wafer Of Compatible Brand And Part Number List

    3-17 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing CC1~CC2 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CFP1 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CIO1 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CPI1 2x4 8Pin 2.0mm B8B-PHDSS PHDR-08VS...

  • Page 50: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS first operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.

  • Page 51: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us fi rst see a short description of the function keys you may use here: ●...

  • Page 52: Getting Help

    4-3 Getting Help Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>. 4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic confi...

  • Page 53: Main

    4-5 Main Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the Date. Please use [Tab] to switch between data elements. System Time Set the Time.

  • Page 54: Advanced

    4-6 Advanced Turbo Boost To turn on turbo boost or not, default is disabled.
  • Page 55 Confi g TDP Enabled to change the TDP up or TDP down, default is disabled.
  • Page 56 cTDP Level To change the TDP up(28W) or TDP down(12W), default is TDP(15W) PCH-FW Confi guration Please refer section 4-6-1 AMT Confi nguration Please refer section 4-6-2 Trusted Computing Please refer section 4-6-3 ACPI Settings Please refer section 4-6-4 F81966 Super IO Confi guration Please refer section 4-6-5 Hardware Monitor Please refer section 4-6-6...

  • Page 57: Pch-Fw Configuration

    4-6-1 PCH-FW Confi guration...

  • Page 59: Amt Configuration

    4-6-2 AMT Confi guration OEM Flags Settings Please refer section 4-6-2-1 MEBx Resolution Settings Please refer section 4-6-2-2...
  • Page 60 4-6-2-1 ► OEM Flags Settings To enable Intel® Management Engine BIOS Extension settings, default is Disabled.
  • Page 61 4-6-2-2 ► MEBx Resolution Settings...

  • Page 62: Trusted Computing

    4-6-3 Trusted Computing Security Device Support To enable BIOS support security device or not, default is Enabled.

  • Page 63: Acpi Settings

    4-6-4 ACPI Settings ACPI S3 Support To enable BIOS support security device or not, default is Enabled.

  • Page 64: F81966 Super Io Configuration

    4-6-5 F81966 Super IO Confi guration Serial Port 1 Confi guration Please refer section 4-6-5-1 Serial Port 2 Confi guration Please refer section 4-6-5-2 Power Failure Please refer section 4-6-5-3...

  • Page 65: Serial Port 1 Configuration

    4-6-5-1 ► Serial Port 1 Confi guration To Enable Serial port or not, default is Enabled.
  • Page 66 Change Settings, default is Auto.
  • Page 67 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 68: Serial Port 2 Configuration

    4-6-5-2 ► Serial Port 2 Confi guration To Enable Serial port or not, default is Enabled.
  • Page 69 Change Settings, default is Auto.
  • Page 70 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 71: Power Failure

    4-6-5-3 ► Power Failure To select the power behavior after power fail, default is Keep last state.

  • Page 72: Hardware Monitor

    4-6-6 Hardware Monitor...
  • Page 73 Press [Enter] to view PC health status. This section shows the status of your CPU, Fan, and overall system. This is only available when there is Hardware Monitor function onboard.

  • Page 74: Usb Configuration

    4-6-7 USB Confi guration...

  • Page 75: Network Stack Configuration

    4-6-8 Network Stack Confi guration To enable the Network stack or not, default is Disabled.

  • Page 76: Nvme Configuration

    4-6-9 NVMe Confi guration To detect NVMe storage automatically.

  • Page 77: Chipset

    4-7 Chipset System Agent (SA) Confi guration. Please refer section 4-7-1 PCH-IO Confi guration. Please refer section 4-7-2...

  • Page 78: System Agent (Sa) Configuration

    4-7-1 System Agent (SA) Confi guration Graphics Confi guration. Please refer section 4-7-1-1...

  • Page 79: Graphics Configuration

    4-7-1-1 ► Graphics Confi guration Primary Display Primary display. The optional settings are: Auto, IGFX, PCH PCI Internal Graphics Graphics Translation Table Size. The optional settings are: Auto, Disabled, Enabled Aperture Size The optional settings are: 256MB (default), 512MB, 1024MB...

  • Page 80: Pch-Io Configuration

    4-7-2 PCH-IO Confi guration PCI Express Confi guration. Please refer section 4-7-2-1 SATA And RST Confi guration. Please refer section 4-7-2-2...
  • Page 81 4-7-2-1 ► PCI Express Confi guration...
  • Page 82 The optional settings are: Enabled(default), Disabled.
  • Page 83 To select PCI Express port speed. The optional settings are: Auto(default), Gen1, Gen2, Gen3...

  • Page 84: Sata And Rst Configuration

    4-7-2-2 ► SATA And RST Confi guration SATA Controller Use this item to Enable or Disable SATA Device.

  • Page 85: Security

    4-8 Security Administrator Password User Password To set up an Administrator or an User password...

  • Page 86: Boot

    4-9 Boot Bootup NumLock State To select Power-on state for NumLock, default is <On> Quiet Boot The optional settings are: Enabled(default), Disabled. Wake-Up From USB 3.0 The optional settings are: Enabled, Disabled(default).

  • Page 87: Save & Exit

    4-10 Save & Exit Save Change and Reset Save confi guration and reset Discard Changes and Reset Reset without saving the changes Restore Defaults To restore the optimal default for all the setup options...

  • Page 88: How To Update Insyde Bios

    STEP 3. Copy the latest BIOS for your LEX motherboard from our website to your bootable disc. STEP 4. (Here take 2I110D as an example, please enter your motherboard’s name) Insert your bootable disc into X: (X could be C:, A: or others.

  • Page 89: Appendix B:resolution List

    Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
