Lex System 2I130DW Manual

Intel raptor lake core i/pentium processor, ddr5 lan/hdmi/usb/m.2/com, all-in-one intel 13th gen raptor lake-u i7/i5/i3, pentium cpu 1 x hdmi, 2 x m.2, usb 4 x lan, 2 x com, 1 x nano sim wide range dc in +9-36v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DDR5 LAN / HDMI / USB / M.2 / COM
Intel® 13th Gen Raptor Lake-U i7 / i5 / i3, Pentium CPU
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 2I130DW
Release date: JAN. 02. 2024
2I130DW
Intel® Raptor Lake Core™ I
/ Pentium processor,
All-In-One
1 x HDMI, 2 x M.2, USB
4 x LAN, 2 x COM, 1 x Nano SIM
Wide Range DC IN +9~36V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2I130DW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lex System 2I130DW

Summary of Contents for Lex System 2I130DW

  • Page 1 4 x LAN, 2 x COM, 1 x Nano SIM Wide Range DC IN +9~36V CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 2I130DW Release date: JAN. 02. 2024...

  • Page 2: Table Of Contents

    1-5 DIRECTIONS FOR INSTALLING THE M.2 M KEY MINI CARD ........CHAPTER 2 HARDWARE INSTALLATION ..............2-1 DIMENSION-2I130DW ....................2-2 LAYOUT-2I130DW-CONNECTOR AND JUMPER TOP ..........2-2-1 LAYOUT-2I130DW-CONNECTOR AND JUMPER BOTTOM BOT ......2-3 LAYOUT-2I130DW-FUNCTION MAP TOP ..............2-3-1 LAYOUT-2I130DW-FUNCTION MAP BOT ............... 2-4 DIAGRAM-2I130DW TOP ....................
  • Page 3 3-13 CO1: SMBUS 1x4 PIN (1.25mm) WAFER ..............3-14 CI C1: I C BUS 1x4 PIN (1.25mm) WAFER .............. 3-15 SATA INTERFACE ..................... 3-16 NGFF1 M.2 NGFF CARD M KEY SOCKETS 75 PIN ..........3-17 NGFF2 M.2 NGFF CARD B KEY SOCKETS 75 PIN ..........3-18 SIM2: NANO SIM CARD SOCKET ................
  • Page 4 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 5: Warning

    Warning ! Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fanless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.

  • Page 6: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 7 Photo 1 Insert Unplug...

  • Page 8: Chapter 1 General Information

    Chapter-1 General Information The 2I130DW is the 2.5" Plus SBC with Intel® 13th Gen Raptor Lake-U & 12th Gen Alder Lake-U i7 / i5 / i3 / Celeron processor designed for high performance Edge Computing and AI computing. The 2I130DW combines Intel's new graphics architecture and up to 32GB DDR5 memory to ensure improved graphics performance.

  • Page 9: Major Feature

    1-1 Major Feature Intel® U300E Processor 1.1GHz / 4.3GHz (5 core), Intel® Core i3-1315UE Processor 1.2GHz / 4.5GHz (6 core), Intel® Core i5-1335UE Processor 1.3GHz / 4.5GHz (10 core)Intel® Core i7-1365URE Processor 1.7GHz / 4.9GHz (10 core) Intel® UHD Graphics for 13th Gen Intel® Processors DDR5 SODIMM slot x 1, up to 32GB Support 4 x 2.5Gbps Intel LAN port.

  • Page 10: Specification

    1-2 Specifi cation SOC: Intel® U300E Processor 1.1GHz / 4.3GHz (5 core), Intel® Core i3-1315UE Processor 1.2GHz / 4.5GHz (6 core), Intel® Core i5-1335UE Processor 1.3GHz / 4.5GHz (10 core) Intel® Core i7-1365URE Processor 1.7GHz / 4.9GHz (10 core) Memory: DDR5 SODIMM slot x 1, up to 32GB Display: HDMI, eDP SATA: Integrated Serial ATA Host Controller 1 SATA port, SATA Gen3 Data transfer rates up to 6.0 Gb/s (600 MB/s).

  • Page 11: Installing The So-Dimm

    1-3 Installing the SO-DIMM 1. Align the SO-DIMM with the connector at a 45 degree angle. 2. Press the SO-DIMM into the connector until you hear a click.
  • Page 12 Notices: 1.The connectors are designed to ensure the correct insertion. If you feel resistance, check t h e connectors & golden fi nger direction, and realign the card. 2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of the card fi...

  • Page 13: Removing The So-Dimm

    1-3-1-1 Removing the SO-DIMM 1. Release the SO-DIMM by pulling outward the two retaining clips and the SO-DIMM pops up slightly. 2. Lift the SO-DIMM out of its connector carefully.

  • Page 14: Directions For Installing The M.2 B Key Mini Card

    1-4 Directions for installing the M.2 B Key Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 15: Directions For Installing The M.2 M Key Mini Card

    1-5 Directions for installing the M.2 M Key Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 16: Chapter 2 Hardware Installation

    Chapter-2 2-1 Dimension-2I130DW...

  • Page 17: Layout-2I130Dw-Connector And Jumper Top

    2-2 Layout-2I130DW-Connector and Jumper CIO1 NGFF2 CFP1 HDMI1 CI2C1 NGFF1 JVL1 EDP1 NGFF1 SODIMM1 CPI1 CBT1 CPU FAN1 CPO1 JSB1 JAT1...

  • Page 18: Layout-2I130Dw-Connector And Jumper Bottom Bot

    2-2-1 Layout-2I130DW-Connector and Jumper Bottom SIM2 SATA1...

  • Page 19: Layout-2I130Dw-Function Map Top

    2-3 Layout-2I130DW-Function MAP COM2 COM1 PCIe x2/USB3.0/2.0 USB 2.0 Front Panel HDMI I2C BUS SM BUS NGFF1 eDP Panel Power Jumper NGFF1 DDR5 SODIMM DC-IN Ext. Battery CPU FAN +5V, +12V Out Clear CMOS jumper HW always on jumper...

  • Page 20: Layout-2I130Dw-Function Map Bot

    2-3-1 Layout-2I130DW-Function MAP Nano SIM USB 3.0 USB 3.0 USB 3.0 SATA...

  • Page 21: Diagram-2I130Dw Top

    2-4 Diagram- 2I130DW CIO1 NGFF2 CFP1 HDMI1 CI2C1 NGFF1 JVL1 EDP1 SODIMM1 CPI1 CBT1 JSB1 CPU FAN1 CPO1 JAT1...

  • Page 22: Diagram-2I130Dw Bot

    2-4-1 Diagram- 2I130DW SIM2 SATA1...

  • Page 23: Function Map-2I130Dw

    2-5 Function MAP- 2I130DW Front Panel PCIe & mSATA COM1 USB 2.0 COM2 PCIe x2 & USB 3.0 & USB 2.0 C Bus SM Bus eDP Panel Power jumper DDR5 SODIMM Ext. Battery CPU FAN CPU FAN HW always on jumper...

  • Page 24: List Of Jumpers

    2-6 List of Jumpers JSB1: CMOS DATA Clear JAT1: HW system always on JVL1: eDP panel power select 2-7 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap.

  • Page 25: Jsb1: Cmos Data Clear

    2-8 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin1 and pin 2 of JSB1 to store the CMOS data. To clear the CMOS, follow the procedures below: 1. Turn off the system and unplug the AC power 2.

  • Page 26: Jat1: Hw System Always On

    2-9 JAT1: HW system always on JAT1 DESCRIPTION *1-2 Normal Set HW system always on JAT1 1 2 3 1 2 3 HW system always on *Normal Set 2-10 JVL1: eDP panel power select JVL1 DESCRIPTION *2-3 +3.3V Note: Attention! Check Device Power in spec JVL1 1 2 3 1 2 3...

  • Page 27: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CPI1: DC-IN 2x4 pin (2.0mm) Red wafer CPO1: +12V / +5V power output 4 pin (2.0mm) Black wafer CBT1: COMS battery 1x2 pin (1.25mm)wafer CC1~CC2:...

  • Page 28: Cpi1: Dc Power Input (2X4 Pin 2.0Mm Wafer) (Red)

    3-2 CPI1: DC Power input (2x4 pin 2.0mm Wafer) (Red) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DC-IN DC-IN DC-IN DC-IN Note: 1. Very important check DC-in Voltage. CPI1 pin1 3-3 CPO1: DC +5 / +12V output (1x4 pin 2.0mm Wafer) (Black) PIN NO.

  • Page 29: Cmos Battery Connector

    3-4 CMOS battery connector CBT1: CMOS Battery 1x2 pin (1.25mm) Wafer. PIN NO. DESCRIPTION Note: 1. When the board without Adaptor plug in, this board power RTC consumption about 2.7uA 2. If adaptor always plug in RTC power consumption about 0.1uA CBT1 pin1...

  • Page 30: Com Interface

    3-5 COM interface CC1 / CC2: COM 2x5 pin (2.0mm) Wafer (RS232 Mode) PIN NO. DESCRIPTION PIN NO. DESCRIPTION RI / VCC (RS485 Mode) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data- Data+ (RS422 Mode) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Note: 1.

  • Page 31: Front Panel Pin Header

    3-6 Front Panel Pin Header CFP1: Front Panel connector 2x5 pin (2.0mm) Wafer PIN NO. Description PIN NO. Description Power button Reset Power LED- Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ CFP1 pin1...

  • Page 32: Dio Interface

    3-7 DIO Interface CIO1: 4DI / 4DO 2x5 pin (2.0mm) Wafer PIN NO. Description PIN NO. Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Note: 1. DIO and WDT function from SIO F81966D-I. CIO1 pin1 WDT For F81966D-I watch dog timer device: DC spec: Input low Voltage (VIL): +0.8 Max Input High Voltage(VIH): +2V Min...

  • Page 33: Io Device: F81966 Dio Under Windows

    3-7-1 IO Device:F81966 LPC DIO under Windows The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Windows <Google Drive> Source fi le: F81966_LPC_GPIO_Utility_v1.5.4_Src Binary fi le: F81966_LPC_GPIO_Utility_Bin_x86_v1.5.4 F81966_LPC_GPIO_Utility_Bin_x64_v1.5.4 F81966 DLL : F81966_DLL_v1.1.1_x86 F81966_DLL_v1.1.1_x64 <FTP> Source fi le: F81966_LPC_GPIO_Utility_Src_v1.5.4 Binary fi le: F81966_LPC_GPIO_Utility_Bin_x86_v1.5.4 F81966_LPC_GPIO_Utility_Bin_x64_v1.5.4 F81966 DLL : F81966_DLL_v1.1.1_x86 F81966_DLL_v1.1.1_x64 Introduction F81966 DIO 1.
  • Page 34 F81966_DLL_API BYTE F81966_LPC_Digital_Read_HIGH(); F81966_DLL_API void F81966_LPC_Digital_Write_HIGH(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Enable(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Disable(); Digital Input / Output test Note when using the following boards: 2I130DW CIO1 needs to be controlled by CIO3 Digital output Digital iutput Low Byte Low Byte...
  • Page 35 sample code Set CIO1 CIO2 Digital Output all high F81966_LPC_Digital_Write_LOW(256); Set CIO1 CIO2 Digital Output all low F81966_LPC_Digital_Write_LOW(0); Set CIO1 Digital Output bit 4 high F81966_LPC_Digital_Write_LOW(16); Set CIO2 Digital Output bit 10 high F81966_LPC_Digital_Write_HIGH(4); Read Din value = F81966_LPC_Digital_Read_LOW(); Watch Dog test sample code Set WDT 10 sec F81966_LPC_Set_WDT_Enable(10);...

  • Page 36: Io Device: F81966 Dio Under Linux Console

    3-7-2 IO Device:F81966 LPC DIO under Linux console The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Linux_console <Google Drive> Source fi le: F81966_DIO_v1.1L_Src Binary fi le: F81966_DIO_v1.1L_Bin_x86 F81966_DIO_v1.1L_Bin_x64 F81966 Libary : F81966_LIB_v1.1L_x86 F81966_LIB_v1.1L_x64 <FTP> Source fi le: F81966_DIO_v1.1L_Src Binary fi le: F81966_DIO_v1.1L_Bin_x86 F81966_DIO_v1.1L_Bin_x64 F81966 Libary : F81966_LIB_v1.1L_x86 F81966_LIB_v1.1L_x64 Introduction F81966 DIO 1.
  • Page 37 BYTE F81966_LPC_Digital_Read_LOW(); BYTE F81966_LPC_Digital_Read_HIGH(); void F81966_LPC_Set_WDT_Enable(BYTE byteValue); void F81966_LPC_Set_WDT_Disable(); void EntryLPC(); void ExitLPC(); Digital Input / Output test Note when using the following boards: 2I130DW CIO1 needs to be controlled by CIO3 Digital output Digital iutput Low Byte Low Byte CIO1...
  • Page 38 sample code Set CIO1 CIO2 Digital Output all high F81966_LPC_Digital_Write_LOW(256); Set CIO1 CIO2 Digital Output all low F81966_LPC_Digital_Write_LOW(0); Set CIO1 Digital Output bit 4 high F81966_LPC_Digital_Write_LOW(16); Set CIO2 Digital Output bit 10 high F81966_LPC_Digital_Write_HIGH(4); Read Din value = F81966_LPC_Digital_Read_LOW(); Watch Dog test sample code Set WDT 10 sec F81966_LPC_Set_WDT_Enable(10);...

  • Page 39: Cpu Fan1: Cpu Fan 1X4 Pin (2.54Mm) Wafer

    3-8 CPU FAN1: CPU Fan 1x4 pin (2.54mm) Wafer PIN NO. DESCRIPTION +12V CPU FAN-IN CPU FAN-OUT Note: DC in +12V by switch to FAN power +12V, so DC in need stable +12V input FAN1 pin1...

  • Page 40: Edp1: Edp Panel 2X10 Pin (1.25Mm) Wafer

    3-9 EDP1: eDP Panel 2x10 pin (1.25mm) Wafer PIN NO. DESCRIPTION PIN NO. DESCRIPTION Lane-0-DATA- +12V or +5V Lane-0-DATA+ +12V or +5V Lane-1-DATA- Lane-1-DATA+ Backlight Enable PWM dimming for eDP C Clock +LCD (5V or 3.3V) C Data +LCD (5V or 3.3V) eDP Aux+ +LCD (5V or 3.3V) eDP Aux-...

  • Page 41: Hdmi1: Hdmi Type A Connector

    3-10 HDMI1: HDMI Type A Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS DATA2+ TMDS DATA2- TMDS DATA1+ TMDS DATA1- TMDS DATA0+ TMDS DATA0- TMDS CLK+ TMDS CLK- DDC CLOCK DDC DATA H.P. Detect HDMI1 HDMI...

  • Page 42: Usb Interface

    3-11 USB Interface CU1~CU3: USB 3.0 Type A Connector PIN NO. Description PIN NO. Description VBUS SS_RX- SS_RX+ SS_TX- SS_TX+ Note: 1. The power supply 0.9A for each USB 3.0 respect specifi cation. 2. CU1, CU2, CU3 support wake up for option. U1, CU2, CU3 support wake up for option.

  • Page 43: Lan Interface

    3-12 LAN Interface CL1 / CL2 / CL3 / CL4: LAN RJ45 Connector PIN NO. Description PIN NO. Description MDI0+ MDI2- MDI0- MDI1- MDI1+ MDI3+ MDI2+ MDI3- CL1 / CL2 / CL3 / CL4 : LAN RJ45 Connector for 2.5 Giga LAN LAN LED LAN LED Speed 10Mbps...

  • Page 44: Co1: Smbus 1X4 Pin (1.25Mm) Wafer

    3-13 CO1: SMBus 1x4 pin (1.25mm) Wafer PIN NO. Description +3.3V SMB Clock SMB DATA pin1 3-14 CI C1: I C BUS 1x4 pin (1.25mm) Wafer PIN NO. Description +3.3V C Clock C DATA pin1...

  • Page 45: Sata Interface

    3-15 SATA Interface SATA1: SATA port connectors 7pin PIN NO. Description Note: 1. CPO1 provides SATA-HDD power +12V, GND, +5V SATA1...

  • Page 46: Ngff1 M.2 Ngff Card M Key Sockets 75 Pin

    3-16 NGFF1: M.2 NGFF card M key sockets 75 pin NGFF1: size 2280 (H=8.5) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V PCIE4_Rn3 PCIE4_Rp3 M2_LED_N PCIE4_Tn3 +3.3V PCIE4_Tp3 +3.3V +3.3V PCIE4_Rn2 +3.3V PCIE4_Rp2 PCIE4_Tn2 PCIE4_Tp2 PCIE4_Rn1 PCIE4_Rp1 PCIE4_Tn1 PCIE4_Tp1 PCIE4_Rn0/SATA-RX+ PCIE4_Rp0/SATA-RX- PCIE4_Tn0/SATA-TX- PCIE4_Tp0/SATA-TX+...
  • Page 47 PIN NO. DESCRIPTION PIN NO. DESCRIPTION M KEY SATA/PCIe Detect +3.3V +3.3V +3.3V Note: 1.NGFF1 support SATA & PCIex4 GEN4 NVMe device. NGFF1...

  • Page 48: Ngff2 M.2 Ngff Card B Key Sockets 75 Pin

    3-17 NGFF2: M.2 NGFF card B key sockets 75 pin NGFF2: size 2242 / 3042 (H=8.5) PIN NO. DESCRIPTION PIN NO. DESCRIPTION CFG3_USB3_PCIE_N +3.3V or +3.7V +3.3V or +3.7V FULL_CARD_PWR_N USB2_P8_DP W_DISABLE_1_N USB2_P8_DN M2_LED_N B KEY W_DISABLE_2_N PERn6_U3Rn4 PERp6_U3Rp4 SIM_RST_M2 SIM_CLK_M2 PETn6_U3Tn4 SIM_DATA_M2...
  • Page 49 PIN NO. DESCRIPTION PIN NO. DESCRIPTION MD_RESET_N SIM_DET +3.3V or +3.7V +3.3V or +3.7V CFG2 power select +3.3V or +3.7V Note: 1. NGFF2 support PCIe / USB 3.0 Auto detect. 2. NGFF2 VCC voltage default is +3.3V, when use 4G LTE device the VCC voltage is +3.7V by For OEM. NGFF2...

  • Page 50: Sim2: Nano Sim Card Socket

    3-18 SIM2: Nano SIM card socket PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA Note: 1. NGFF2 Pin 30, 32, 34, 36, 66 for SIM card reader use. SIM2 Nano SIM...

  • Page 51: Connector Wafer Of Compatible Brand And Part Number List

    3-19 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing CC1~CC2 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CFP1 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CIO1 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CPI1 2x4 8Pin 2.0mm B8B-PHDSS PHDR-08VS...

  • Page 52: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS first operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.

  • Page 53: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us fi rst see a short description of the function keys you may use here: ●...

  • Page 54: Getting Help

    4-3 Getting Help Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>. 4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic confi...

  • Page 55: Main

    4-5 Main Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the Date. Please use [Tab] to switch between data elements. System Time Set the Time.

  • Page 56: Advanced

    4-6 Advanced CPU Power Management Control Please refer section 4-6-1 PCH-FW Confi guration Please refer section 4-6-2 AMT Confi nguration Please refer section 4-6-2 Trusted Computing Please refer section 4-6-3 ACPI Settings Please refer section 4-6-4 F81966 Super IO Confi guration Please refer section 4-6-5 Hardware Monitor Please refer section 4-6-6...
  • Page 57 4-6-1 CPU Power Management Control...
  • Page 58 Turbo Boost Max To turn on turbo boost or not, default is disabled.
  • Page 60 Confi g TDP Confi gurations Confi gurable TDP Boot Mode Enabled to change the TDP up or TDP down, default is Base Power...

  • Page 61: Pch-Fw Configuration

    4-6-2 PCH-FW Confi guration...

  • Page 63: Trusred Configuration

    4-6-3 Trusted Computing...
  • Page 64 Security Device Support To enable BIOS support security device or not, default is Enabled.
  • Page 65 4-6-4 ACPI Settings...
  • Page 66 ACPI S4 Support To enable support S4 mode, default is Disabled. ACPI S3 Support To enable support S3 mode, default is Enabled.

  • Page 67: F81966 Super Io Configuration

    4-6-5 F81966 Super IO Confi guration...
  • Page 68 Serial Port 1 Confi guration Please refer section 4-6-5-1 Serial Port 2 Confi guration Please refer section 4-6-5-2 Power Failure Please refer section 4-6-5-3...

  • Page 69: Serial Port 1 Configuration

    4-6-5-1 ► Serial Port 1 Confi guration To Enable Serial port or not, default is Enabled.
  • Page 70 Change Settings, default is Auto.
  • Page 71 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 72: Serial Port 2 Configuration

    4-6-5-2 ► Serial Port 2 Confi guration To Enable Serial port or not, default is Enabled.
  • Page 73 Change Settings, default is Auto.
  • Page 74 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 75: Power Failure

    4-6-5-3 ► Power Failure To select the power behavior after power fail, default is Keep last state.
  • Page 76 4-6-6 Hardware Monitor...

  • Page 77: Network Stack Configuration

    4-6-7 Network Stack Confi guration To enable the Network stack or not, default is Disabled.

  • Page 78: Nvme Configuration

    4-6-8 NVMe Confi guration To detect NVMe storage automatically...

  • Page 79: Chipset

    4-7 Chipset System Agent (SA) Confi guration. Please refer section 4-7-1 PCH-IO Confi guration. Please refer section 4-7-2...
  • Page 80 4-7-1 System Agent (SA) Confi guration Graphics Confi guration. Please refer section 4-7-1-1...

  • Page 81: Graphics Configuration

    4-7-1-1 ► Graphics Confi guration Primary Display Primary display. The optional settings are: Auto, IGFX, PEG Slot, PCH PCI Internal Graphics Graphics Translation Table Size. The optional settings are: Auto, Disabled, Enabled, GTT Size The optional settings are: 2MB, 4MB, 8MB(default) Aperture Size The optional settings are: 256MB(default), 512MB, 1024MB...

  • Page 82: Pch-Io Configuration

    4-7-2 PCH-IO Confi guration PCI Express Confi guration. Please refer section 4-7-2-1 SATA Confi guration. Please refer section 4-7-2-2...
  • Page 83 4-7-2-1 ► PCI Express Confi guration To select PCI Express port speed. The optional settings are: Auto(default), Gen1, Gen2, Gen3...
  • Page 84 The optional settings are: Enabled(default), Disabled.
  • Page 85 To select PCI Express port speed. The optional settings are: Auto(default), Gen1, Gen2, Gen3...

  • Page 86: Sata Configuration

    4-7-2-2 ► SATA Confi guration SATA Controller Use this item to Enable or Disable SATA Device.

  • Page 87: Security

    4-8 Security Administrator Password User Password To set up an Administrator or an User password...

  • Page 88: Boot

    4-9 Boot Bootup NumLock State To select Power-on state for NumLock, default is <On> Quiet Boot The optional settings are: Enabled(default), Disabled. Wake-Up On LAN The optional settings are: Enabled(default)., Disabled Wake-Up On USB The optional settings are: Enabled, Disabled(default).

  • Page 89: Save & Exit

    4-10 Save & Exit Save Change and Reset Save confi guration and reset Discard Changes and Reset Reset without saving the changes Restore Defaults To restore the optimal default for all the setup options...

  • Page 90: How To Update Insyde Bios

    STEP 3. Copy the latest BIOS for your LEX motherboard from our website to your bootable disc. STEP 4. (Here take 2I130DW as an example, please enter your motherboard’s name) Insert your bootable disc into X: (X could be C:, A: or others.

  • Page 91: Appendix B:resolution List

    Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
