Intel® Comet Lake-S Core™ I processor + Intel Q470,
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 3I470DW
Release date: AUG. 19. 2022
3I470DW
DDR4 LAN / DP / HDMI
/ USB / PCIe / M.2
10th gen. Intel Comet Lake-S Core™ I CPU
HDMI, DP, eDP, PCIe, PCIe mini card, M.2,
Multi-LAN, COM, Nano SIM, SATA, USB
Wide Range DC-input
All-In-One

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3I470DW and is the answer not in the manual?

Questions and answers

Related Manuals for Lex System 3I470DW

Summary of Contents for Lex System 3I470DW

  • Page 1 HDMI, DP, eDP, PCIe, PCIe mini card, M.2, Multi-LAN, COM, Nano SIM, SATA, USB Wide Range DC-input CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 3I470DW Release date: AUG. 19. 2022...

  • Page 2: Table Of Contents

    1-4 PACKING LIST ........................1-5 DIRECTIONS FOR INSTALLING THE M.2B KEY MINI CARD ..........CHAPTER 2 HARDWARE INSTALLATION ................2-1 DIMENSION-3I470DW-TOP ....................2-2 LAYOUT-3I470DW-FUNCTION MAP-TOP ................2-2-1 LAYOUT-3I470DW-FUNCTION MAP-BOT ............... 2-3 FUNCTION MAP-3I470DW-TOP ..................2-3-1 FUNCTION MAP-3I470DW-BOT ..................2-4 CONNECTOR MAP-3I470DW-TOP ..................
  • Page 3 3-12 CPI1: MOTHER BOARD DC POWER INPUT (ATX 2x3 PIN 2.54mm WAFER) ....3-13 CPO1: +12V / +5V DC VOLTAGE OUTPUT WAFER CONNECTOR (BLACK) (1x4 PIN 2.0mm) 3-14 CPS1: EXTERNAL POWER-ON SYNC CONTROL ............3-15 USB 3.0 AND USB 2.0 ......................3-16 DISPLAY &...
  • Page 4 4-7-2-2 SATA AND RST CONFIGURATION ................4-8 SECURITY ........................... 4-9 BOOT ........................... 4-10 SAVE & EXIT ........................4-11 HOW TO UPDATE INSYDE BIOS ..................APPENDIX B: RESOLUTION LIST ....................
  • Page 5 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.

  • Page 6: Warning

    Warning ! 1. Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fless solution with HDD The specification & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notification in case of changes of product information and manual.

  • Page 7: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard first. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 8 Photo 1 Insert Unplug...

  • Page 9: Chapter 1 General Information

    Intel LAN chipset, it is perfect control board for networking devices. The 3I470DW SBC equipped with a variety of interfaces: 5 x LAN, 4 x RS232 / RS422 / 485 serial ports, 4 x USB3.0, 4 x USB 2.0, DP, HDMI & eDP) and expansion slots such as PCIe / mPCIe / M.2 slots for I/O modules (Digital I/O, WiFi, 4G / 5G, LoRA, Bluetooth)

  • Page 10: Major Feature

    1-1 Major Feature 1. The Embedded Coffee Lake-S Platform processor includes Integrated Display Engine, GPU and Integrated Memory Controller. The processor is designed be offered in a LGA1200 package. 2. Intel Q470 Chipset Family Platform Controller Hub (PCH) 3. Supports Two Channels of DDR4 SO-DIMM SDRAM, Max. 32GB, data transfer rates of 2400MT/s.

  • Page 11: Specification

    1-2 Specification CPU: Embedded Comet Lake-S Platform processor. The processor is designed be offered in a LGA1200 package. PCH: Intel Q470 Chipset Family Platform Controller Hub (PCH) Memory: Two SO-DIMM slots for DDR4 SDRAM, Max. 64GB, data transfer rates of 2400MT/s Graphics: Intel 9th generation (Gen 9) LP graphics and media encode / decode engine supports OpenGL x 4.5, OpenCL x 2.1, Direct3D x 2015, Direct3D 11.2,...
  • Page 12 1-3 Installing the SO-DIMM 1. Align the SO-DIMM with the connector at a 45 degree angle. 2. Press the SO-DIMM into the connector until you hear a click.

  • Page 13: Packing List

    Notices: 1.The connectors are designed to ensure the correct insertion. If you feel resistance, check t h e connectors & golden finger direction, and realign the card. 2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of the card firmly.
  • Page 14 1-3-1-1 Removing the SO-DIMM 1. Release the SO-DIMM by pulling outward the two retaining clips and the SO-DIMM pops up slightly. 2. Lift the SO-DIMM out of its connector carefully.

  • Page 15: Installing The Mini Pci-E Card (Full Size)

    1-4 Installing the Mini PCI-e Card (Full Size) 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 16: Directions For Installing The M.2B Key Mini Card

    1-5 Directions for installing the M.2B Key Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 17: Chapter 2 Hardware Installation

    Chapter-2 2-1 Dimension-3I470DW...

  • Page 18: Layout-3I470Dw-Function Map-Top

    2-2 Layout-3I470DW-Function Map M.2 B Key 3042 HDD LED Power Sync PCIe PWR LED mSATA USB Port 11 Full Size LAN LED USB Port 10 USB3.0 Line Out PCIe PowerOn USB Port 9 Line In mSATA SMBus Reset Button USB Port 8 Mic In USB3.0...

  • Page 19: Layout-3I470Dw-Function Map-Bot

    2-2-1 Layout-3I470DW-Function Map Nano SIM USB3.0 Port1 USB3.0 Port2 USB3.0 Port3 USB3.0 Port4...

  • Page 20: Function Map-3I470Dw-Top

    2-3 Function Map-3I470DW Power in always ON HDD LED M.2 B Key 3042 Power Sync PWR LED PCIe Full Size USB Port 11 LAN LED mSATA USB Port 10 PCIe Line Out PowerOn USB3.0 USB Port 9 mSATA Line In...

  • Page 21: Function Map-3I470Dw-Bot

    2-3-1 Function Map-3I470DW Nano SIM USB3.0 Port1 USB3.0 Port2 USB3.0 Port3 USB3.0 Port4...

  • Page 22: Connector Map-3I470Dw-Top

    2-4 Connector MAP-3I470DW CPS1 CU11 CU10 NGFF1 JAT1 CFP1 MPCE1 CLPC1 JVL1 CCIO1 CCIO2 CCIO3 CCIO4 CBT1 SATA2 JSB1 SATA3 JSB2 CFP1 CPO1 CDH1 CPI1...

  • Page 23: Connector Map-3I470Dw-Bot

    2-4-1 Connector MAP-3I470DW SIM1...

  • Page 24: Diagram-3I470Dw-Top

    2-5 Diagram- 3I470DW CPS1 CU11 NGFF1 CU10 CFP1 JAT1 MPCE1 CLPC1 CCIO1 JVL1 CCIO2 CCIO3 CCIO4 CBT1 SATA2 JSB1 SATA3 JSB2 CFP1 CPO1 CDH1 CPI1...

  • Page 25: Diagram-3I470Dw-Bot

    2-5-1 Diagram- 3I470DW SIM1...

  • Page 26: List Of Jumpers

    2-8 List of Jumpers JSB1: CMOS DATA Clear JSB2: ME DATA Clear JVL1: eDP panel power select JAT1: Power in always ON function 2-9 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap.

  • Page 27: Jsb1: Coms Data Clear

    2-10 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard configuration in CMOS RAM. Close Pin1 and pin 2 of JSB2 to store the CMOS data. To clear the CMOS, follow the procedures below: Turn off the system and unplug the AC power. Make sure there is no AC &...

  • Page 28: Jsb2:Me Data Clear

    2-11 JSB2: ME DATA Clear JSB2 DESCRIPION *1-x Normal Set ME data clear JSB2 *Normal 2-12 JVL1: eDP panel power select JVL1 DESCRIPION *2-3 +3.3V JVL1 1 2 3 1 2 3 *+3.3V...

  • Page 29: Jat1:Power In Always On Function

    2-13 JAT1: Power in always ON function JVL1 DESCRIPION *1-2 Disable Enable Note: Power in always ON function default is disabled. JAT1 1 2 3 1 2 3 Enable *Disable...

  • Page 30: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CBT1: COMS battery 1x2 pin (1.25mm) wafer CA1: Line-out / Line-in / Mic-in 2x5 pin (2.0mm) Wafer (Option) CC1: COM port1 2x5 pin (2.0mm) wafer.

  • Page 31: Cmos Battery Connector

    CU11: USB 2.0 port 4 pin (1.25mm) Wafer EDP1: eDP 2x10 pin (1.25mm) connector SATA2: SATA port 2 connector 7 pin SATA3: SATA port 3 connector 7 pin SIM1: Nano push-push SIM socket. SODIMM1: DDR4 Channel 0 SODIMM SODIMM2: DDR4 Channel 1 SODIMM MPCE1: Full size mini card port 1 sockets 52 pin M.2:...

  • Page 32: Audio Interface

    3-3 Audio interface CA1: Line-out / Line-in / Mic-in 2x5 pin (2.0mm) Wafer PIN NO. DESCRIPTION PIN NO. DESCRIPTION Line-out-R MIC-IN Line-in-R Line-in-L Line-out-L MIC-IN Note: This is option item for audio function. pin1...

  • Page 33: Cc1 / Cc2 Com Port1 / Port2 2X5 Pin (2.0Mm) Wafer

    3-4 CC1 / CC2 COM port1 / port2 2x5 pin (2.0mm) wafer RS232 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION RS485 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data - Data+ RS422 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION TX - Note: 1.

  • Page 34: Ccio 1/2/3/4 Com Port 3/4/5/6 And Di/Do 2X5 Pin (2.0Mm) Wafer

    3-5 CCIO 1/2/3/4 COM port 3/4/5/6 and DI/DO 2x5 pin (2.0mm) wafer For COM 3/4/5/6: RS232 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION RS485 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data- Data+ RS422 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION...

  • Page 35: For Di / Do

    3-6 For DI / DO PIN NO. DESCRIPTION PIN NO. DESCRIPTION DI-0,4,8,12 DO-3,7,11,15 DI-1,5,9,13 DO-2,6,10,14 DI-2,6,10,14 DO-1,5,9,13 DI-3,7,11,15 DO-0,4,8,12 Note: 1. COM or DI / DO decided by OEM order and BOM controlled 2. UART default is RS232 and RS422 / RS485 by BIOS selected 3.

  • Page 36: Io Device: F81966 Dio Under Windows

    3-6-1 IO Device: F81966 DIO under Windows The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Windows Source file: F81966_LPC_GPIO_Utility_Src_v1.5.zip Binary file: F81966_LPC_GPIO_Utility_Bin_x86_v1.5.zip F81966_LPC_GPIO_Utility_Bin_x64_v1.5.zip F81966 DLL: F81966_DLL_x32_v1.0.zip F81966_DLL_x64_v1.0.zip Introduction F81966 DIO 1. Start test Button, Send bits one by one and one by one receive 2.
  • Page 37 F81966_DLL_API BYTE F81966_LPC_Digital_Read_HIGH(); F81966_DLL_API void F81966_LPC_Digital_Write_HIGH(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Enable(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Disable(); Digital Input / Output test Note when using the following boards: 3I470DW CIO1 needs to be controlled by CIO3 Digital output Digital iutput Low Byte Low Byte...
  • Page 38 sample code Set CIO1 CIO2 Digital Output all high F81966_LPC_Digital_Write_LOW(256); Set CIO1 CIO2 Digital Output all low F81966_LPC_Digital_Write_LOW(0); Set CIO1 Digital Output bit 4 high F81966_LPC_Digital_Write_LOW(16); Set CIO2 Digital Output bit 10 high F81966_LPC_Digital_Write_HIGH(4); Read Din value = F81966_LPC_Digital_Read_LOW(); Watch Dog test sample code Set WDT 10 sec F81966_LPC_Set_WDT_Enable(10);...

  • Page 39: Io Device: F81966 Dio Under Linux Console

    3-6-2 IO Device: F81966 DIO under Linux console The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Linux_console Source file: F81966_DIO_v1.1L_Src Binary file: F81966_DIO_v1.1L_Bin_x86 F81966_DIO_v1.1L_Bin_x64 F81966 Libary : F81966_LIB_v1.1L_x86 F81966_LIB_v1.1L_x64 Introduction F81966 DIO 1. Start test Button, Send bits one by one and one by one receive 2.
  • Page 40 BYTE F81966_LPC_Digital_Read_LOW(); BYTE F81966_LPC_Digital_Read_HIGH(); void F81966_LPC_Set_WDT_Enable(BYTE byteValue); void F81966_LPC_Set_WDT_Disable(); void EntryLPC(); void ExitLPC(); Digital Input / Output test Note when using the following boards: 3I470DW CIO1 needs to be controlled by CIO3 Digital output Digital iutput Low Byte Low Byte CIO1...
  • Page 41 sample code Set CIO1 CIO2 Digital Output all high F81966_LPC_Digital_Write_LOW(256); Set CIO1 CIO2 Digital Output all low F81966_LPC_Digital_Write_LOW(0); Set CIO1 Digital Output bit 4 high F81966_LPC_Digital_Write_LOW(16); Set CIO2 Digital Output bit 10 high F81966_LPC_Digital_Write_HIGH(4); Read Din value = F81966_LPC_Digital_Read_LOW(); Watch Dog test sample code Set WDT 10 sec F81966_LPC_Set_WDT_Enable(10);...

  • Page 42: Cdh1 Display Port And Hdmi Connector

    3-7 CDH1: Display Port and HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA0+ DATA0- DATA1+ DATA1- DATA2+ DATA2- DATA3+ DATA3- AUX+ AUX- H.P. Detect +3.3V HDMI: PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS DATA2+ TMDS DATA2- TMDS DATA1+ TMDS DATA1- TMDS DATA0+ TMDS DATA0- TMDS CLK+...

  • Page 43: Cfp1 Front Panel Connector 2X5 Pin (2.0Mm) Wafer

    3-8 CFP1: Front Panel connector 2x5 pin (2.0mm) wafer PIN NO. DESCRIPTION PIN NO. DESCRIPTION Power button pin Power button GND Reset pin Reset GND Power LED- Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ CFP1 pin1...

  • Page 44: Lan Interface

    3-9 LAN Interface CL1/2/3/4/5: RJ45 LAN1/2/3/4/5 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0+ MDI2- MDI0- MDI1- MDI1+ MDI3+ MID2+ MDI3- CL11/21/31/41/51: LAN1/2/3/4/5 2x4 pin (2.0mm) wafer (OEM) PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0- MDI0+ MDI2+ MID1+ MDI1- MDI2- MDI3- MDI3+ Note: These CL11/21/31/41/51 wafer default hasn't been existed.

  • Page 45: Clpc1: For Lpc Signal 2X5 Pin Wafer (2.0Mm)

    3-10 CLPC1: for LPC signal 2x5 pin wafer (2.0mm) PIN NO. DESCRIPTION PIN NO. DESCRIPTION FRAME RESET SERIAL IRQ +3.3V CLPC1 pin1 3-11 CO1: SMBus Bus 4 pin (1.25mm) Wafer PIN NO. DESCRIPTION +3.3V SMBus Clock SMBus DATA pin1...

  • Page 46: Cpi1: Mother Board Dc Power Input (Atx 2X3 Pin 2.54Mm Wafer)

    3-12 CPI1: Mother board DC Power input (ATX 2x3 pin 2.54 mm Wafer) PIN NO. DESCRIPTION 1,3,5 DC-IN 2,4,6 CPI1 pin1 3-13 CPO1: +12V / +5V DC voltage output wafer connector (Black) (1x4 pin 2.0 mm) PIN NO. DESCRIPTION +12V* *Note: Attention! Check Device Power in spec CPO1...

  • Page 47: Cps1: External Power-On Sync Control

    3-14 CPS1: External Power-On Sync control PIN NO DESCRIPTION PS_ON_N *Note: The sync signal is Low active. When Motherboard powered on that is Low, Power-off is high. The signal is +3.3V tolerance. It can be used for gold finger power to sync motherboard power sequence. CPS1 pin1...

  • Page 48: Usb 3.0 And Usb

    3-15 USB 3.0 and USB 2.0 CU1/2/3/4: USB 3.0 Port 1/2/3/4 Type A Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VBUS SS_RX- SS_RX+ SS_TX- SS_TX+ Note: the power supply 0.9A for each USB 3.0 respect specification. USB 3.0 USB 3.0 USB 3.0 USB 3.0 CU8/9/10/11 USB 2.0 port (1x4 pin 1.25mm Wafer) PIN NO.

  • Page 49: Display & Touch Interface

    3-16 Display & Touch Interface EDP1: eDP interface (2x10 pin 1.25mm wafer) PIN NO DESCRIPTION PIN NO DESCRIPTION Lane-0-DATA- +12V Lane-0-DATA+ +12V Lane-1-DATA- Lane-1-DATA+ Backlight Enable PWM dimming I2C Clock +LCD (5V or 3.3V) I2C Data +LCD (5V or 3.3V) eDP Aux+ +LCD (5V or 3.3V) eDP Aux-...

  • Page 50: Sata Interface

    3-17 SATA interface SATA2 / SATA3: SATA port 1x7 pin Connector PIN NO. DESCRIPTION Note: 1. CPO1 provide SATA HDD power +12V, GND, +5V SATA3 SATA2 3-18 SIM1: Nano Push-Push SIM socket PIN NO. DESCRIPTION Power Reset Clock Data SIM detect Note: 1.

  • Page 51: Sodimm1 / Sodimm2 Socket

    3-19 SODIMM1 / SODIMM2 socket Note : SODIM1 / SODIM2 : SO-DIMM DDR4 1.2V DRAM Socket Only Support un-buffer type module Only suport Raw card type A.C.E. SODIMM1 SODIMM2...

  • Page 52: Module Socket

    3-20 Module socket MPCE1 PCI Express Mini card PIN NO. Description PIN NO. Description +3.3V +1.5V PCIe-CLK- PCIe-CLK+ WAKEUP_LTE W_DISABLE_N Reset PCIe-RX- / mSATA-RX+ +3.3V pin1 PCIe-RX+ / mSATA-RX- +1.5V SMB-CLK pin52 PCIe-TX- / mSATA-TX- SMB-DATA MPCE1 PCIe-TX+ / mSATA-TX+ USB-DATA- USB-DATA+ +3.3V...

  • Page 53: Ngff1: B Key Size

    3-21 NGFF1: B Key size PIN NO. Description PIN NO. Description CONFIG_3 +3.3V or +3.7V +3.3V or +3.7V Full_Card_Power_OFF_N USB-DATA- W_DISABLE_1_N USB-DATA+ LED# CONFIG_0 W_DISABLE_2_N NGFF1 PCIe-RX- PCIe-RX+ PCIe-TX- PCIe-TX+ RESET# PCIe-CLK- PCIe-CLK+ LTE_RESET_N CONFIG_1 +3.3V or +3.7V +3.3V or +3.7V +3.3V or +3.7V CONFIG_2 Note:...

  • Page 54: Connector Wafer Of Compatible Brand And Part Number List

    3-22 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing CBT1 1x2 2Pin 1.25mm MOLEX 53047-0210 51021-0200 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS CCIO1 2x5 10Pin...

  • Page 55: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS first operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.

  • Page 56: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here: ●...

  • Page 57: General Help

    4-3 General Help Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>.

  • Page 58: Menu Bars

    4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic configuration Advanced To change system advanced configuration Chipset To change PCH IO configuration Security Password settings Boot Quiet boot or boot from USB selected. Save &...

  • Page 59: Advanced

    4-6 Advanced PCH-FW Configuration Please refer section 4-6-1 Trusted Computing Please refer section 4-6-2 F81966 Super IO Configuration Please refer section 4-6-3 Hardware Monitor Please refer section 4-6-4 USB Configuration Please refer section 4-6-5 Network Stack Configuration Please refer section 4-6-6 NVMe Configuration Please refer section 4-6-7...
  • Page 60 4-6-1 PCH-FW Configuration Manageability Features Status & AMT BIOS Features is to Enable AMT Configuration Settings or not, default is Enabled.
  • Page 61 CIRA Configuration Please refer section 4-6-1-1 ASF Configuration Please refer section 4-6-1-2 Secure Erase Configuration Please refer section 4-6-1-3 OEM Flags Settings Please refer section 4-6-1-4 MEBx Resolution Settings Please refer section 4-6-1-5...

  • Page 62: Cira Configuration

    4-6-1-1 CIRA Configuration To trigger CIRA Boot. Note: Network access must be activated first from MEBx setup.

  • Page 63: Asf Configuration

    4-6-1-2 ASF Configuration To Enable progress to receive PET events or not.

  • Page 64: Secure Erase Configuration

    4-6-1-3 Secure Erase Configuration To change the behavior of Secure Erase module. There are Simulated & Real. Default is Simulated.

  • Page 65: Oem Flags Settings

    4-6-1-4 OEM Flags Settings...

  • Page 66: Mebx Resolution Settings

    4-6-1-5 MEBx Resolution Settings Resolution for Non-UI text Mode. There are Auto, 80x25, 100x31...
  • Page 67 Resolution for UI text Mode. There are Auto, 80x25, 100x31...
  • Page 68 Resolution for Graphics Mode. There are Auto, 640x480, 800x600, 1024x768...
  • Page 69 4-6-2 Trusted Computing To enable support security device or not.

  • Page 70: F81966 Super Io Configuration

    4-6-3 F81966 Super IO Configuration Serial Port 1 Configuration Please refer section 4-6-3-1 Serial Port 2 Configuration Please refer section 4-6-3-2 Serial Port 3 Configuration Please refer section 4-6-3-3 Serial Port 4 Configuration Please refer section 4-6-3-4 Power Failure Please refer section 4-6-3-5...

  • Page 71: Serial Port 1 Configuration

    4-6-3-1 Serial Port 1 Configuration To Enable Serial port or not, default is Enabled.
  • Page 72 Change Settings, default is Auto.
  • Page 73 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 74: Serial Port 2 Configuration

    4-6-3-2 Serial Port 2 Configuration To Enable Serial port or not, default is Enabled.
  • Page 75 Change Settings, default is Auto.
  • Page 76 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 77: Serial Port 3 Configuration

    4-6-3-3 Serial Port 3 Configuration To Enable Serial port or not, default is Enabled.
  • Page 78 Change Settings, default is Auto.
  • Page 79 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 80: Serial Port 4 Configuration

    4-6-3-4 Serial Port 4 Configuration To Enable Serial port or not, default is Enabled.
  • Page 81 Change Settings, default is Auto.
  • Page 82 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 83: Power Failure

    4-6-3-5 Power Failure To select the power behavior after power fail, default is Keep last state.

  • Page 84: Hardware Monitor

    4-6-4 Hardware Monitor Press [Enter] to view PC health status. This section shows the status of your CPU, Fan, and overall system. This is only available when there is Hardware Monitor function onboard.

  • Page 85: Usb Configuration

    4-6-5 USB Configuration Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. Disable option will keep USB devices available only for EFI applications. The optional settings are: Enabled (default), Disabled, Auto. XHCI Hand-off This is a workaround for OS without XHCI handoff support.

  • Page 86: Network Stack Configuration

    4-6-7 Network Stack Configuration To enable the UEFI Network stack or not, default is Disabled.

  • Page 87: Nvme Configuration

    4-6-8 NVMe Configuration To detect NVMe storage automatically.

  • Page 88: Chipset

    4-7 Chipset System Agent (SA) Configuration. Please refer section 4-7-1 PCH-IO Configuration. Please refer section 4-7-2...

  • Page 89: System Agent (Sa) Configuration

    4-7-1 System Agent (SA) Configuration Graphics Configuration. Please refer section 4-7-1-1 PEG Port Configuration. Please refer section 4-7-1-2...
  • Page 90 4-7-1-1 Graphics Configuration Primary Display To select which of IGFX / PEG Graphics device should be Primary Display Or select SG for Switchable Gfx. The optional settings are: Auto, IGFX (default), PEG, PCI. Internal Graphics Keep IGFX enabled based on the setup options. The optional settings are: Auto, Enabled (default), Disabled.
  • Page 91 4-7-1-2 PEG Port Configuration Enable Root Port To enable the Root Port or not. The optional settings are: Auto (default), Enabled, Disabled. Max Link Speed Configure PEG Port Max Speed. The optional settings are: Auto (default), Gen1, Gen2, Gne3.

  • Page 92: Pch-Io Configuration

    4-7-2 PCH-IO Configuration PCI Express Configuration. Please refer section 4-7-2-1 SATA And RST Configuration. Please refer section 4-7-2-2...
  • Page 93 4-7-2-1 PCI Express Configuration...
  • Page 94 PCI Express Root Port 14 (MPCE1 / SATA1) The optional settings are: Enabled (default), Disabled. PCI Speed To select PCI Express port speed. The optional settings are: Auto (default), Gen1, Gen2, Gen3...

  • Page 95: Sata And Rst Configuration

    4-7-2-2 SATA And RST Configuration SATA Controller Use this item to Enable or Disable SATA Device. SATA Mode Selection Determines how SATA controller(s) operate. The optional settings are: AHCI, Intel RST Premium.
  • Page 96 MPCE1 switch to PCIe / SATA or USB 3.0...

  • Page 97: Security

    4-8 Security Administrator Password User Password To set up an Administrator or an User password...

  • Page 98: Boot

    4-9 Boot Bootup NumLock State To select Power-on state for NumLock, default is <On> Quiet Boot The optional settings are: Enabled (default), Disabled. Wake-Up From USB The optional settings are: Enabled, Disabled (default).

  • Page 99: Save & Exit

    4-10 Save & Exit Save Change and Reset Save configuration and reset Discard Changes and Reset Reset without saving the changes Restore Defaults To restore the optimal default for all the setup options...

  • Page 100: How To Update Insyde Bios

    STEP 3. Copy the latest BIOS for your LEX motherboard from our website to your bootable disc. STEP 4. (Here take 3I470DW as an example, please enter your motherboard’s name) Insert your bootable disc into X: (X could be C:, A: or others.

  • Page 101: Appendix B: Resolution List

    Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
