Lex System 2I385A Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Intel Bay Trail-I E3815 / E3845 / E3825
(Single Core / Quad Core / Dual Core) CPU,
Intel Bay Trail-D J1900 (Quad Core) CPU,
2 x LAN / LVDS / Touch Screen / USB / COM
(Single Core 1.46 GHz / Quad Core 1.91 GHz / Dual Core 1.33 GHz) CPU,
Intel Bay Trail-D J1900 (Quad Core 2.0 GHz) CPU,
VGA, Audio, SATA, USB, COM , LVDS, Touch Screen
CAUTION
NO. 2I385A / CW_V0.1
Release date: SEP. 07. 2017
2I385A / 2I385CW
DDR3L 1066 / 1333 MT/s,
Intel Bay Trail-I E3815 / E3845 / E3825
2 x Intel GbE LAN , 2 x PCIe mini card slots,
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
All-In-One

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2I385A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lex System 2I385A

Summary of Contents for Lex System 2I385A

  • Page 1 2 x Intel GbE LAN , 2 x PCIe mini card slots, VGA, Audio, SATA, USB, COM , LVDS, Touch Screen CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 2I385A / CW_V0.1 Release date: SEP. 07. 2017...

  • Page 2: Table Of Contents

    CHAPTER 2 HARDWARE INSTALLATION ..............2-1 UNPACKING PRECAUTION ..................2-2 UNPACKING CHECKUP ....................2-3 DIMENSION-2I385A/2I385CW ..................2-4 LAYOUT-2I385A/2I385CW-CONNECTOR AND JUMPER .......... 2-4-1 LAYOUT-2I385A/2I385CW-CONNECTOR AND JUMPER BOTTOM ......2-4-2 LAYOUT-2I385A/2I385CW-FUNCTION MAP ............2-4-3 LAYOUT-2I385A/2I385CW-FUNCTION MAP BOTTOM ........... 2-5 DIAGRAM-2I385A ......................2-5-1 DIAGRAM-2I385CW ....................
  • Page 3 3-15 LAN INTERFACE ....................... 3-16 USB INTERFACE ....................... 3-17 SATA INTERFACE ..................... 3-18 PCI EXPRESS MINI CARD ..................3-19 CONNEXTOR WAFER OF COMPATIBLE BRAND AND PART NUMBER LIST ..CHAPTER 4 INTRODUCTION OF BIOS ................ 4-1 ENTER SETUP ......................4-2 BIOS MENU SCREEN & FUNCTION KEYS ..............4-3 GETTING HELP ......................
  • Page 4 APPENDIX A:POWER CONSUMPTION TEST ..............APPENDIX B:RESOLUTION LIST ..................APPENDIX C:F75111N I C DIO DEVICE ................1-1 IO DEVICE : F75111 UNDER DOS ................1-2 IO DEVICE : F75111 UNDER WINDOWS ..............1-3 IO DEVICE : F75111 VB6 UNDER WINDOWS ............1-4 IO DEVICE : F75111 UNDER LINUX ................
  • Page 5 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.

  • Page 6: Warning

    Warning ! Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.

  • Page 7: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 8 Photo 1 Insert Unplug...

  • Page 9: Chapter 1 General Information

    PC specifi cation in the industry. Despite the limited space of 2I385A/CW, it supports 4 COM ports and 4 ports of Hi-Speed USB 2.0 to enhance the host controller interface which will ensure the high performance level and fl...

  • Page 10: Major Feature

    Hardware digital Input & Output, 4 x DI / 4 x DO Hardware Watch Dog Timer, 0~255 sec programmable DC +12V Input (2I385A) or Wide range DC input from +9V to +36V (±1V) (2I385CW) 10. PCB Dimension: 102 x 73 mm (2.5 inch) 11.

  • Page 11: Specification

    USB interface, one half size PCIe Mini card for mSATA and USB interface 12. BIOS: Insyde UEFI BIOS 13. Dimension: 102 x 73 mm (2.5 inch) 14. Power: DC +12V Input (2I385A) or Wide range DC input from +9V to +36V (±1V) (2I385CW) 15. LVDS: 24/48 bits 16.

  • Page 12: Installing The Mini Pci-E Card

    1-3 Installing the Mini PCI-e Card 2. Install a mSATA card at the angle of 45°. 1. Unfasten the round-headed M2*6 (The half size Mini PCI-e slot supports mSATA) screw for half size Mini PCI-e. 3. Fasten a round-headed M2*6 screw.

  • Page 13: Directions For Installing The Mini Card

    1-4 Directions for installing the Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 14: Packing List

    1-5 Packing List Material Code Description Detail Specifi cation Quantity 7G1901-1500001-0 MB-2I385A-I44-001 LF,2I385A-I44,Rev.:001 6G8006-2347-0100 LEX Product Driver DVD LF, Intel Baytrail Driver 6G8001-2192-0400 Manual LF,M/B,2I385A/C 6G6003-7330-0100 Power Cable LF,L=9cm,2.0 1*4/DC JK 6G5212-0301-0300 30W Power Adapter,12V/2.5A LF,L Type,EA10301-M06,EDAC *The packing list above is for the users who purchase single motherboard. The users who purchase the board with chassis may refer to the packing list in the Assembly Guide.

  • Page 15: Chapter 2 Hardware Installation

    Chapter-2 Hardware Installation 2-1 Unpacking Precaution This chapter provides the information how to install the hardware of 2I385A/2I385CW. Please follow section 1-5, 2-1 and 2-2 to check the delivery package and unpack carefully. Please follow the jumper setting procedure. NOTE! 1.

  • Page 16: Unpacking Checkup

    2-2 Unpacking checkup First of all, please follow all necessary steps of section 2-1 to protect 2I385A/2I385CW from electricity discharge. With reference to section 1-5 please check the delivery package again with following steps: 1. Unpack the 2I385A/2I385CW board and keep all packing material, manual and driver disc etc, do not dispose ! 2.

  • Page 17: Dimension-2I385A/2I385Cw

    2-3 Dimension-2I385A/2I385CW...

  • Page 18: Layout-2I385A/2I385Cw-Connector And Jumper

    2-4 Layout-2I385A/2I385CW-Connector and Jumper JSB1 CALR1 MPCE1 MPCE2 CFP1 CIO1 CPP1 JVL1 CPI1 LVDS1 CPO1...

  • Page 19: Layout-2I385A/2I385Cw-Connector And Jumper Bottom

    2-4-1 Layout-2I385A/2I385CW-Connector and Jumper Bottom SATA1...

  • Page 20: Layout-2I385A/2I385Cw-Function Map

    2-4-2 Layout-2I385A/2I385CW-Function MAP Mini Card Socket 2 PCIe, USB, SMBus COMS Mini Card Socket 1 ClearJumper PCIe, mSATA Auto detect RJ45 LAN Audio AMP USB, SMBus 10M/100M/1000M Right Left SMBus Front Panel 4DI/4DO Audio Line-in Line-out Mic-in COM2 COM3 COM4...

  • Page 21: Layout-2I385A/2I385Cw-Function Map Bottom

    2-4-3 Layout-2I385A/2I385CW-Function MAP Bottom SATA Genll USB2.0 USB2.0...

  • Page 22: Diagram-2I385A

    2-5 Diagram- 2I385A BAT1 MPCE2 JSB1 MPCE1 CALR1 CFP1 CIO1 CPP1 JVL1 CPI1 CPO1...

  • Page 23: Diagram-2I385Cw

    2-5-1 Diagram- 2I385CW BAT1 MPCE2 JSB1 MPCE1 CALR1 CFP1 CIO1 CPP1 JVL1 CPI1 LVDS1 CPO1...

  • Page 24: Bottom Side Diagram-2I385A/2I385Cw

    2-5-2 Bottom Side Diagram- 2I385A/2I385CW SATA1 BACK Panel LAN2 LAN1...

  • Page 25: List Of Jumpers

    2-6 List of Jumpers JSB1: CMOS DATA clear JVL1: LCD Panel power select 2-7 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap. Some jumpers have three pins, labeled 1, 2, and 3.

  • Page 26: Jsb1: Coms Data Clear

    2-8 JSB1: CMOS Data Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin1 and pin 2 of JSB1 to store the CMOS data. To clear the CMOS,follow the procedures below: 1. Turn off the system and unplug teh AC power 2.

  • Page 27: Jvl1: Lcd Panel Power Select

    2-9 JVL1: LCD panel power select JVL1 Description *2-3 +3.3V Note: Attention! Check Device Power in spec. JVL1 *+3.3V...

  • Page 28: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors BAT1: Li 3V battery holder CA3: Line-out/Line-in/Mic-in/SPDIF-out 2x5 pin (2.0mm) Wafer CALR1: Amplifi...

  • Page 29: Dc Power Input

    3-2 DC Power Input CPI1: DC -in 1x4 (2.0mm)Wafer Internal connector (Red) PIN NO. Description DC-IN DC-IN Note: Very important check DC-in Voltage CPI1 pin1 3-3 CMOS Battery connector BAT1: 3V Battery hold 2pin BAT1: Battery use Li 3V / 40mAh (CR1220) Note : 1.When board without Adaptor plug in, this board power RTC consumption 2.7uA 2.If adaptor always plug in RTC power consumption 0.1uA...

  • Page 30: Dc+12V/+5V Voltge Power Output (4Pin 2.0Mm Wafer) (Black)

    3-4 DC+12V /+5 Voltge Power output (4pin 2.0mm Wafer)(Black) CPO1: +12V/+5V DC voltage output PIN NO. Description +12V* * Note: Attention! Check Device Power in spec CPO1 pin1 pin1 CFP1 3-5 Front Panel Pin Header CFP1 Front Panel connector 2x5pin (2.0mm) wafer PIN NO.

  • Page 31: Lvds Connector

    3-6 LVDS Connector LVDS1: LVDS interface (2x15pin 1.25mm wafer) PIN NO. Description PIN NO. Description PWM dimming +LCD(5V or 3.3V) +LCD(5V or 3.3V) Channel-1-DATA3+ Channel-0-DATA3+ Channel-1-DATA3- Channel-0-DATA3- Channel-0-DATA2+ Channel-0-CLK+ Channel-0-DATA2- Channel-0-CLK- Channel-0-DATA1+ Channel-0-DATA0+ Channel-0-DATA1- Channel-0-DATA0- +LCD(5V or 3.3V) +LCD(5V or 3.3V) Channel-1-DATA2+ Channel-1-CLK+ LVDS1...

  • Page 32: Touch Screen Device

    3-8 Touch screen device CT1: Touch screen (2x5 pin 2.0mm wafer) USB interface. For 8- wire type pin defi ne PIN NO. Description PIN NO. Description Bottom Bottom Sense Top Sense Right Right Sense Left Left Sense Note: For eight wire type cable Pin 3 and Pin4 need short. For 4- wire type pin defi...

  • Page 33: Audio Interface

    3-9 Audio interface CA3: Line-out/Line-in/Mic-in/SPDIF-out 2x5 pin (2.0mm) Wafer PIN NO. Description PIN NO. Description Line-out-R MIC-IN Line-in-R SPDIF-OUT Line-in-L Line-out-L MIC-IN 3-10 Audio Amplifi er CALR1: Amplifi er Line-out Right/Left channel 4pin (1.25mm) wafer PIN NO. Description Left+ Left- Right- Right+ pin1...

  • Page 34: Com Interface

    3-11 COM interface CC1 COM1 DB9 Connector (RS232 Mode) PIN NO. Description PIN NO. Description RI/Voltage Note: 1. SATA1 support SATA 2.0 spec update 3Gb/sec. 2. CPO1 provide SATA HDD power +12V, GND, +5V 3. The SATA signal share with mSATA of MPCE1, but just one can be worked in same time. CC1 COM1 DB9 Connector (RS485 Mode) PIN NO.

  • Page 35: Vga Display Interface

    CC2/3/4 COM2/3/4 2x5pin (2.0mm) wafer (RS232 Mode) PIN NO. Description PIN NO. Description CC2/3/4 COM2/3/4 2x5pin (2.0mm) wafer (RS485 Mode) PIN NO. Description PIN NO. Description RS485 Data- RS485 Data+ pin1 Note: 1. CC2/CC3 connector default RS232 function, OEM RS485 2.

  • Page 36: Digital Input/Output

    3-13 Digital Input / Output CIO1 DIO 0—3 (2x5pin 2.0mm wafer) PIN NO. Description PIN NO. Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Note: 1. DI pin default pull up 10KΩ to +5V 2. If use need isolate circuit to control external device 3.

  • Page 37: I C Bus Interface

    3-14 I C Bus Interface CO1: I C Bus 4pin (1.25mm)Wafer PIN NO. Description +3.3V I C Clock pin1 I C DATA 3-15 LAN Interface CL1/CL2 : RJ45 LAN port Giga /100Mb( RJ45 Jack) PIN NO. Description PIN NO. Description TR0-/TX+ TR2-/NC TR0+/TX-...

  • Page 38: Usb Interface

    3-16 USB Interface CU1/CU2: USB2.0 Port Type A PIN NO. Description DATA - DATA + CU3/CU4: USB2.0 Port (1x4pin 1.25mm Wafer) PIN NO. Description DATA - DATA + pin1 pin1...

  • Page 39: Sata Interface

    3-17 SATA Interface SATA1: SATA Port 1x7pin connector PIN NO. Description Note: 1. SATA1 support SATA 2.0 spec update 3Gb/sec. 2. CPO1 provide SATA HDD power +12V, GND, +5V 3. The SATA signal share with mSATA of MPCE1, but just one can be worked in same time. SATA1...

  • Page 40: Pci Express Mini Card

    3-18 PCI Express Mini card MPCE1/MPCE2: Support USB and PCIe by one Interface (Mini card socket 52pin) MPCE1 : Full size mini card MPCE2 : Half size mini card PIN NO. Description PIN NO. Description +3.3V +1.5V PCIe-CLK- PCIe-CLK+ MPCE1 Reset pin52 PCIe-RX-/mSATA-RX+...

  • Page 41: Connextor Wafer Of Compatible Brand And Part Number List

    3-19 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS CALR1 1x4 4Pin 1.25mm MOLEX 53047-0410 51021-0400 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.0mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.0mm...

  • Page 42: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS fi rst operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and confi...

  • Page 43: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us fi rst see a short description of the function keys you may use here: Press ←→...

  • Page 44: Getting Help

    4-3 Getting Help Status Page Setup Menu/ Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>.

  • Page 45: Menu Bars

    4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic confi guration Advanced To change system advanced confi guration Security Password settings Power PME & Power button settings Boot Exit Save setting, loading and exit options. User can press the right or left arrow key on the keyboard to switch from menu bar.

  • Page 46: Advanced

    System Time Set the Time. Please use [Tab] to switch between data elements. 4-6 Advanced Boot Confi guration Please refer section 4-6-1 PCI Express Confi guration Please refer section 4-6-2 Video Confi guration Please refer section 4-6-3 Thermal Confi guration Please refer section 4-6-4 SATA Confi...

  • Page 47: Boot Configuration

    ACPI Table/Features Control Please refer section 4-6-7 4-6-1 Boot Confi guration Numlock Select Power-on state for Numlock, default is <ON> 4-6-2 PCI Express Confi guration PCIe 1/2/3/4 confi guration settings...

  • Page 48: Pci Express Root Port 1/2/3/4

    4-6-2-1 ► PCI Express Root Port 1/2/3/4 Control the PCI Express Root Port. The optional settings are: Enabled(default), Disabled. Select PCI Express port speed. The optional settings are: Gen1(default), Gen2 Select PCIE TXE ROM support The optional settings are: Disabled(default), Enabled...

  • Page 49: Video Configuration

    4-6-3 Video Confi guration Confi gure LVDS Panel Number as The Panel resolution supported are below: 640 x 480 18bit 800 x 600 18bit 1024 x 768 18bit (default) 800 x 480 18bit 1024 x 600 18bit 1280 x 800 18bit 1366 x 768 18bit 800 x 600 24bit 1024 x 768 24bit...

  • Page 50: Thermal Configuration

    IGD - DVMT Pre-Allocated Use this item to select DVMT 5.0 pre-allocated (fi xed) graphics memory size used by the internal graphics device. The optional settings are: 64(default)/96/128/160/192/224/256/288/320/352/384/416/448/480/512MB IGD - DVMT Total Gfx Mem Use this item to select DVMT 5.0 total graphics memory size used by the internal graphics device The optional settings are:128M, 256M(default), MAX 4-6-4 Thermal Confi...

  • Page 51: Sata Configuration

    4-6-5 SATA Confi guration SATA Controller Use this item to Enable or Disable SATA Device. The optional settings are: Enabled(default) or Disabled Chipset SATA Mode Determine how SATA controller(s) operate. The optional settings are: IDE Mode(default), AHCI Mode. SATA Speed Indicates the maximum speed the SATA controller can support.

  • Page 52: Console Redirection

    SATA Port 1 Connected to an ODD Use this item to Enable or Disable SATA Port1 ODD function The optional settings are: Enabled(default) or Disable 4-6-6Console Redirection Console Serial Redirect Use this item to enable or disable Console Redirection. The optional settings are: Enabled, Disabled(default). Text Mode Resolution The optional settings are: Force 80x25 Force 80x24(DEL FIRST ROW)

  • Page 53: Acpi Table/Features Control

    Stop Bits The optional settings are: 1 Bit(default) , 2 Bits Flow Control The optional settings are: None(default) , RTS/CTS , XON/XOFF 4-6-7 ACPI Table/Features Control ACPI Table/Features Control Select ACPI sleep state the system will enter when the SUSPEND button is pressed. The optional settings: DSDT - ACPI S3 (Suspend to RAM), Enabled or Disabled(default) 4-7 Security...

  • Page 54: Power

    Supervisor Password To set up an Supervisor password 1. Select Supervisor Password. The screen then pops up an Create New Password dialog. 2. Enter your desired password that is no less than 3 characters and no more than 10 characters. 3.

  • Page 55: Boot

    4-9 Boot Boot type Select boot type for Dual type ,Legacy boot type or UEFI boot type, default is Dual boot type Quiet Boot The optional settings are: Enabled(default), Disabled. EFI / Legacy Device order Determine EFI device fi rst or legacy device fi rst. The optional settings: EFI device fi...

  • Page 56: Legacy

    4-9-1 Legacy Normal Boot Menu Select Normal Boot option priority or Advance Boot option priority. The optional settings: Normal(default), Advance...

  • Page 57: Boot Type Order

    4-9-2 Boot Type Order Boot Type Order Setting the boot type priority. The default settings is 1.USB drive 2.Hard Disk Drive 3.CD/DVD ROM drive 4.Others...

  • Page 58: Exit

    4-10 EXIT Exit Saving Changes This item allows user to reset the system after saving the changes. Save Change Without Exit This item allows user to saving the changes but doesn’t restart. Exit Discard Changes This item allows user restart the system but no saving the changes Load Optimal Default Use this item to restore the optimal default for all the setup options.

  • Page 59: Device Manaager

    4-11 Device Manager Please press the key F10 when boot up to go into the Device Manager menu Serial Port 1/2 Confi guration Please refer section 4-11-1 Serial Port 3/4/5/6 Confi guration Please refer section 4-11-2...

  • Page 60: Sio Fintek81801U

    4-11-1 SIO FINTEK81801U Serial Port 1/2 Use this item to enable or disable serial port (COM1 or COM2). The optional settings are: Enabled(default), Disabled. Serial Port 1 Base IO Address / Interrupt / Serial Mode Use this item to select an optimal setting for super IO device. The optional settings are: IO=3F8h;...
  • Page 61 Serial Port 2 Base IO Address / Interrupt / Serial Mode Use this item to select an optimal setting for super IO device. The optional settings are: IO=2F8h; IRQ=3(default) IO=2E8h; IRQ=3,4 IO=3E8h; IRQ=3,4 IO=3F8h; IRQ=3,4 Serial Mode RS232 driver(default) : When hardware select to RS232 or RS422 mode, please enter to RS232 driver.

  • Page 62: Hardware Monitor

    4-11-2 Hardware Monitor Press [Enter] to view PC health status. This section shows the status of your CPU, Fan, and overall system. This is only available when there is Hardware Monitor function onboard.

  • Page 63: Sio Fintek81216D/Dg

    4-11-3 SIO FINTEK81216D/DG Serial Port 3/4 Use this item to enable or disable serial port (COM3, COM4, COM6 for Touch). The optional settings are: Enabled(default), Disabled. Serial Port 3 Base IO Address / Interrupt Use this item to select an optimal setting for super IO device. The optional settings are: IO=3E8h;...
  • Page 64 Serial Port 4 Base IO Address / Interrupt Use this item to select an optimal setting for super IO device. The optional settings are: IO=2E8h; IRQ=10(default) IO=2F8h; IRQ=3,4,5,6,7,10,11 IO=3F8h; IRQ=3,4,5,6,7,10,11 IO=3E8h; IRQ=3,4,5,6,7,10,11 IO=4F8h; IRQ=3,4,5,6,7,10,11 IO=4E8h; IRQ=3,4,5,6,7,10,11 Serial Mode RS232 driver: When hardware select to RS232 or RS422 mode, (COM1 to COM3 default RS232) please enter to RS232 driver.

  • Page 65: Chapter 5 Driver Installation

    Chapter-5 DRIVER INSTALLATION There is a system installation DVD in the package. This DVD does not only include all the drivers you need but also some other free application programs and utility programs. In addition, this DVD also includes an auto detect software telling you which hardware is installed and which driver is needed so that your system can function properly.
  • Page 66 AUTOMATIC DRIVER INSTALLATION menu...
  • Page 67 1. INF Install Intel Baytrail chipset driver 2. VGA Install onboard VGA driver 3. Serial IO Install Serial IO driver (FOR Win 7 only) 4. xHCI Install Intel USB 3.0 xHCI driver (FOR Win 7 only) 5. HD Audio Install HD Audio Codec driver 6.

  • Page 68: Inf Install Intel Baytrail Chipset Driver (Example For Win8 64Bit)

    5-1 INF Install Intel Baytrail Chipset Driver (example for WIN8 64bit) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Intel® Chipset Device Software" menu" screen, click "INF". screen, click "Next". 3. At the "License Agreement" 4. At the "Readme File Information" screen, screen,click "Yes"...
  • Page 69 5. Click "Next" 6. Click "Finish" & restart computer. NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 64/32-bit, X:\driver\INTEL\BAY\INF\WIN7\infi nst_autol.exe For Windows 8 / 8.1 32/64-bit X:\driver\INTEL\BAY\INF\WIN_8_64\infi nst_autol.exe...

  • Page 70: Vga Install Intel Baytrail Vga Driver (Example For Win8 64Bit)

    5-2 VGA Install Intel Baytrail VGA Driver (example for WIN8 64bit) 1. At the"AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu"screen, click "VGA". screen, Click "Next". 3. At the "License Agreement” screen, 4. At the "Readme File Information” screen, Click "Yes"...
  • Page 71 6. Click "Finish" to restart computer 5. At the "Setup Progress" screen, Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32-bit, X:\driver\INTEL\BAY\VGA\WIN_7_32\Setup.exe For Windows 7 64-bit X:\driver\INTEL\BAY\VGA\WIN_7_64\Setup.exe For Windows 8 / Windows 8.1 32-bit X:\ \driver\INTEL\BAY\VGA\WIN_8_32\Setup.exe For Windows 8 / Windows 8.1 64-bit X:\driver\INTEL\BAY\VGA\WIN_8_64\Setup.exe...

  • Page 72: Serial Io Install Driver Baytrail Serial Io Driver (For Windows 7 Only)

    5-3 Serial IO Install Driver Baytrail Serial IO Driver (FOR Windows 7 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup menu" screen, click "Serial IO". Programscreen, Click "Next". 3. At the "License Agreement" screen, 4.
  • Page 73 5. At the "Ready to install the program" screen, 6. Click "Finish" and restart computer Click "Install" NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32-bit, X:\driver\INTEL\BAY\SERIALIO\WIN7_32Bit.msi For Windows 7 64-bit X:\driver\INTEL\BAY\SERIALIO\Win7_64Bit.msi...

  • Page 74: Xhci Install Intel Usb 3.0 Xhci Driver (For Windows 7 Only)

    5-4 xHCI Install Intel USB 3.0 xHCI Driver (FOR Windows 7 only) 1. At the"AUTOMATIC DRIVER INSTALLATION 2. At the "Intel® USB 3.0 extensible Host menu" screen, Click "USB 3.0 Controller Driver" screen, Click" Next. 3. At the "License Agreement" screen, 4.
  • Page 75 6. Click "Finish" to restart computer 5. At the "Setup Progress" screen, Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, X:\driver\INTEL\BAY\XHCI\Driver_Installer\Setup.exe...

  • Page 76: Hd Audio Install High Definition Audio Driver

    5-5 HD Audio Install High Defi nition Audio Driver (example for WIN8 64bit) 1. At the "AUTOMATIC DRIVER 2. Click "Next". INSTALLATION menu", click "HD Audio" 3. Click "Finish" to restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, Windows 8/8.1 32 / 64-bit X:\driver\INTEL\BAY\SOUND\Win7_Win8_Win81_R273.exe...

  • Page 77: Mbi Install Intel Mbi Driver (For Win 8/8.1 Only)

    5-6 MBI Install Intel MBI Driver (FOR Win 8/8.1 only) 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Welcome to the Setup Program menu", click "HD Audio" screen, Click “Next”. 3. At the "License Agreement" screen, 4. At the "Setup Progress" screen, Click "Yes".
  • Page 78 5. Click "Finish" to restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 8/8.1 32 / 64-bit, X:\driver\INTEL\BAY\MBI\Setup.exe...

  • Page 79: Txe Install Intel Txe Driver

    5-7 TXE Install Intel TXE driver 5-7-1 TXE Install for WIN8/WIN8.1 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Setup" screen, Click "Next". menu", click "TXE" 3. At the "License Agreement" screen, 4. Click "Next". Click "Yes".
  • Page 80 5. Click “Finish” & restart computer NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 8 32 / 64-bit, X:\driver\INTEL\BAY\TXE\WIN_8\SetupTXE.exe For Windows 8.1 32 / 64-bit, X:\driver\INTEL\BAY\TXE\WIN_8.1\SetupTXE.exe...

  • Page 81: Txe Install For Win7

    5-7-2 TXE Install for WIN7 Please install PXE Patch fi rst. 1. At the "AUTOMATIC DRIVER INSTALLATION 2. At the "Windows Update" screen, menu", click "TXE Patch " Click "Yes". 3. Click "Finish" & restart computer 4. At the "AUTOMATIC DRIVER INSTALLATION menu", click "TXE "...
  • Page 82 5. At the "TXE Setup" screen, Click "Next". 6. At the "License Agreement" screen, Click "Yes". 8. Click "Finish" & restart computer 7. Click "Next". NOTE: SYSTEM INSTALL will auto detect fi le path For Windows 7 32 / 64-bit, TXE Patch X:\driver\INTEL\BAY\TXE\WIN_7\kmdf-1.11-Win-6.1-x86.msu X:\driver\INTEL\BAY\TXE\WIN_7\kmdf-1.11-Win-6.1-x64.msu...

  • Page 83: How To Update Insyde Bios

    5-8 How to update Insyde BIOS Under DOS Mode STEP 1. Prepare a bootable disc. (Storage device could be USB FDD or USB pen drive.) STEP 2. Copy utility program to your bootable disc. You may download it from our website. STEP 3.

  • Page 84: Appendix A:power Consumption Test

    Appendix A: Power Consumption Test Condition ( 2I385A/CW--E3815 ) Item Spec Atom E3815 1.46 Ghz Memory DDR3L 1066 2GB Operating System Windows 7 / SP1 Test Program 3D Mark 06 HDD 2.5" SATA Slim Type HDD mSATA 24GB/32GB Test Result for reference only !
  • Page 85 Condition ( 2I385A/CW--E3845 ) Item Spec Atom E3845 1.91 Ghz Memory DDRL 1333 4GB Operating System Windows 7 / SP1 Test Program 3D Mark 06 HDD 2.5" SATA Slim Type HDD mSATA 24GB/32GB Test Result for reference only ! Start up...

  • Page 86: Appendix B:resolution List

    Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )

  • Page 87: Appendix C:f75111N I C Dio Device

    Appendix C: F75111N I C DIO device 1-1 IO Device:F75111 under DOS The Sample code source you can download from Source fi le: F75111_Dos_Src.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_DOS Binary fi le: F75111_Dos_Bin.rar USERNAME & PASSWORD: sf How to use this Demo Application 1.Boot Ms-Dos Operating System 2.execute "75WDT.EXE"...

  • Page 88: Io Device: F75111 Under Windows

    1-2 IO Device: F75111 under Windows The Sample code source you can download from Source fi le: F75111_DIOSrc.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111 Binary fi le: F75111_DemoBin.rar USERNAME & PASSWORD: sf How to use this Demo Application 1. Press the "Start" button to test DIO function 2.
  • Page 89 p.s. f75111 send "F75111_SetWDTEnable(BYTE byteTimer)" including a parameter "timer", if there's no disable signal (F75111_SetWDTDisable()) to stop it before timer countdown to 0, System will reboot. if there's disable signal received, resent Enable WDT signal, for a loop to prevent from reboot Introduction Initial Internal F75111 port address (0x9c) defi...
  • Page 90 Set output value void F75111::InterDigitalOutput(BYTE byteValue) BYTE byteData = 0; byteData = (byteData & 0x01 )? byteValue + 0x01 : byteValue; byteData = (byteData & 0x02 )? byteValue + 0x02 : byteValue; byteData = (byteData & 0x04 )? byteValue + 0x04 : byteValue; byteData = (byteData &...

  • Page 91: Io Device: F75111 Vb6 Under Windows

    Disable WatchDog void F75111_SetWDTDisable () WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,0x00); // Disable WatchDog 1-3 IO Device: F75111 VB6 under Windows The Sample code source you can download from Source fi le: 75111_VB_v10.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111_VB6 Binary fi le: 75111_VB_Src.rar USERNAME & PASSWORD: sf How to use this Demo Application A Function - Enable WDT timer ,Key-in the value by seconds then system will reboot after value which you key-in in left text box !! B Function - Disable WDT timer ,Push down the button then WDT timer value will be clear !!
  • Page 92 SDK Function Introduction Function EnableWDT Function EnableWDT(timer As Integer) Call WriteI2CByte(&H3, &H3) Call WriteI2CByte(&H37, timer) Call WriteI2CByte(&H36, &H73) End Function Function DisableWDT Function DisableWDT() Call WriteI2CByte(&H36, &H0) End Function Function SetDOValue Function SetDOValue(dovalue As Integer) Call WriteI2CByte(&H23, &H0) Call WriteI2CByte(&H20, &HFF) Call WriteI2CByte(&H2B, &HFF) Call WriteI2CByte(&H21, dovalue) End Function...

  • Page 93: Io Device: F75111 Under Linux

    1-4 IO Device: F75111 under linux The Sample code source you can download from Source fi le: F75111v2.0L.tar.gz http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_linux Binary fi le: F75111v2.0LBin.tar.gz USERNAME & PASSWORD: sf How to compile source code 1. Compile source code with Code::Blocks download and install the Code::Block with command "apt-get install codeblocks" Open an exist project(F75111.cbp) in Code::Blocks, click the compile button ( add an option 'pkg-confi...
  • Page 94 1. Press the "Start" button to test DIO function 2. Press the "Enable" button to test WDT function 3. Press the "Disable" button to disable WDT 4. Check the "Enable Loop" box and press "Enable" to do WDT loop test 5.
  • Page 95 Set output value void F75111::InterDigitalOutput(BYTE byteValue) BYTE byteData = 0; byteData = (byteData & 0x01 )? byteValue + 0x01 : byteValue; byteData = (byteData & 0x02 )? byteValue + 0x02 : byteValue; byteData = (byteData & 0x04 )? byteValue + 0x04 : byteValue; byteData = (byteData &...
  • Page 96 Enable WatchDog void F75111_SetWDTEnable (BYTE byteTimer) WriteByte(F75111_INTERNAL_ADDR,WDT_TIMER_RANGE ,byteTimer); // set WatchDog range and timer WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,WDT_TIMEOUT_FLAG | WDT_ENABLE | WDT_PULSE | WDT_PSWIDTH_100MS); // Enable WatchDog, Setting WatchDog confi gure Disable WatchDog void F75111_SetWDTDisable () WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,0x00); // Disable WatchDog...
