6 FIRMWARE EVOLUTION OF MULTIGRAPHIC

REV Date
V1.1 07/03/2013
V1.5 06/02/2014
V1.7 09/04/2014
V2.0 16/09/2014
V2.2 16/09/2015
Information
Nominal version, PROCESSOR COMPATIBLE
-
New functions
calibration utilities of masthead unit, compass and speedo
-
sensors.
Autopilot GPS mode
-
- Saving and restore setting Autopilot
New language : Spanish
-
True wind tables (usable with HR masthead unit, in
-
version ≥ V2.5).
Digital pilot page
-
- Regatta page
Page of display with dynamic chanels on the Topline bus
-
- Management with the remote control
Pilot alarm
-
addition of new widget gauge for the battery monitor
-
- Added page 1 + 1
Fixed bug on the GGA latitude without frame.
-
- Fixed bug that reverse speed and direction current
Fixed a bug on unwanted keys Pilot events
-
Fixed a bug that prevented the VMG calculation if the heel
-
was not present.
Modification true wind tables to limit at 40 knots.
-
Change "time before cut-off" Gyropilot in order to set it up
-
to 5 minutes.
- Fixed a bug of the freeze of screen
Addition of 1 mile on the AIS scale
-
Management the AIS Man OverBoard device
-
Change in the management of the backlight.
-
Additions of the magnetic COG.
-
- Fixed a bug of the freeze of screen
Fixed of the bug which could slow down the functioning of
-
Multigraphic during an important flow AIS.
New Tactical page for the assistant to the regatta
-
The Pilot page can be temporarily displayed on a remote
-
display, according to the Pilot actions generated on the
bus (remote control, Gyrographic, Multigraphic )
- Management of the new software V3.7 of Processor (new
mode of piloting).
Display of channels in red in condition of alarm.
-
Display of the power consumed on the channels of the
-
controller of battery.
Possibility of changing the channel of broadcast of WiFi
-
Box.
89 50_Afficheur_Multigraphic_um_UK_27
