Tacking angle
Set the tacking angle value for automatic tack performed by the Gyropilot.
For the compass mode the tacking angle can be set between 70° and 115° (by 5°
steps). The default setting is 100°.
Tack speed
The speed at which tacks are performed by the Gyropilot can be set from 1° per
second to 32° per second. The default setting is 9° per second.
Man Over Board
The Man-Over-Board function can be activated from any MOB button on a Topline
display or a wireless remote control (Gyropilot, Multifonction or Crew) if the MOB
function has been set.
This function works with two selectable modes: Crew and Solo.
Crew mode
This mode is selected to assist the crew for a Man-Over-Board manoeuvre. The
system will not act on the rudder but activate an audible alarm and display dead
reckoned bearing and distance to the MOB event.
Solo mode
If the Gyropilot is in stand-by it will automatically engage and push the rudder by +
40° or – 40°, in relation to the rudder's position at the moment the MOB function has
been activated.
If the Gyropilot is activated and the system features a wind sensor, the Gyropilot
switches automatically to wind mode and steers the boat up to the wind (with a 0°
wind angle course to steer).
If the Gyropilot is activated and the system does not feature a wind sensor, the
Gyropilot switches automatically to rudder mode and applies + 40° or – 40°, in
relation to the rudder's position at the moment the MOB function has been activated.
Speed reference
If the true wind mode is activated the Gyropilot will use the speed over ground (if
available on the Topline bus) or the boat speed through the water, at your choice.
Time out setting
This sets the time the Gyropilot can steer the boat with the gyrometer data in case
of Topline bus data dropout. The setting can range from 0 to 60 seconds. During this
time you don't have access to the pilot.
