2.5.2 Pilot Page selection
2 different pilot pages are available : analogue format or digital format (see § 2.3 for
customizing)

2.5.2.1 Gyropilot page

Access to the
pilot mode with
Course to steer

2.5.2.2 Digital Page

Pilot

Mode.
Accessible with
the OK button.
Pilot's course to
steer
User's selected
data, set up
according to the
user's preference
Press « OK »
cancel the last action.
Rudder
indicator
to access the pilot mode and settings. Press « page »
17
angle
Rudder angle
50_Afficheur_Multigraphic_um_UK_27
Gain value adjustable
with the up and down
arrows on the pad
Sensor identification
and value related to
the pilot mode.
Gain value. Can be
adjusted with high and
low arrows of the key
pad
Sensor and value for
the related and
selected pilot mode.
to
