R_SPEEDO
2.7.6.2.3 Stats GPS
When a HF GPS is connected to the NMEA input of the Multigraphic an additional
menu appears "GPS Stats" in the external devices menu. This menu displays the
visible satellites and their signal levels. It is possible with a NMEA 0183 GPS to
obtain this page if it sends the GGA, GSA and GSV frames which activate this page.

2.7.6.3 Topline Instrument system

This system menu displays the properties and software versions of all the sensors
and displays connected to the Topline bus.
+
DYN7 PNKEA,,7
DYN8 PNKEA,,8
43
--
--
VHW --
50_Afficheur_Multigraphic_um_UK_27
--
--
--
Display's nodes
Software Version
