4 MULTIGRAPHIC SPECIFICATIONS

Feature
Dimensions
Weight
Power supply
Consumption at 12 Volts
NMEA input
Environment
Power supply cable
Display
With sun cover: 196 x 122 x 28mm (length x height x
depth)
Without sun cover: 192 x 118 x 23mm ((length x
height x depth)
800 g (with 6 m cable and sun cover)
8V – 32V DC
Day backlight:
Level 1 = 100mA
Level 20 = 180 mA
night backlight:
Level 1 = 100mA
Level 20 = 120mA
Standby: 91mA
NMEA 183, baud rate configurable automatically from
4800 or 38400 bauds. AIS direct data acquisition.
Protection IP 68 (waterproof at permanent immersion
and to high pressure water flow)
Operation temperature -20°C - +50°C
Storage temperature -20°C - +60°C
Ø 5.5 mm, 4 wires + braid, length 6m.
5.7'' colour graphic screen, translective, embedded
LED backlight.
86 50_Afficheur_Multigraphic_um_UK_27
Value
