3 INSTALLATION

This section describes the installation and configuration of the Multigraphic as well
as setting the parameters for an installation with a Gyropilot 2 processor. Refer to
the Gyropilot 2 manual for the full pilot installation (drive unit, processor, rudder
feed-back...).
Warning:
Please take time to read this manual carefully before you start installation
-
Any connection to the TOPLINE bus must be performed through the specific
-
interface box 90-60-417 (featuring an NMEA port) which comes with the
Multigraphic.
Use only with the TOPLINE bus cable
-
All Topline bus connections must be performed while the system is powered
-
off.

3.1 Packing list. The Multigraphic comes with:

A Multigraphic with six metres cable, featuring TOPLINE bus and an NMEA
-
port.
A white sun cover
-
- A fixing bolt

3.2 Suggested spare parts list

- TOPLINE bus standard junction box: 90-60-121
- TOPLINE connection box with a NMEA port : 90-60-417
White sun cover: 72-60-068
-
Carbone sun cover : 72-60-071
-

3.3 Before installing check

The best location for the unit must be:
Easy for the helmsman to read and operate,
-
- Safe location with low risk of shocks,
More than 40 cm from a compass,
-
Not horizontal.
-
20-61-001.
#
