3. Installation Site Preparations:
3.1 Tool List:
(1) Screws*
(3) Philips screwdriver
(5) Wire stripper
(7) Electric drill
(9) BNC connector
*Included in the kit
3.2 Installation Preparation:
(1) Check the space and toughness of the site and make sure that the
environmental conditions meet the installation requirements for this product.
(2) The installation surface should be able to bear 4 times the weight of the
PTZ and its accessories.
3.3 Output Mode Setting:
(1) Default Settings: AHD, PAL system
This output can be changed via the controller (Even if the user cannot gain a
video output from the unit due to output incompatibility)
(2) Set your controller/DVR PTZ Settings to the Camera's Default
Communication Settings: Protocol: CoC / PELCO-D, address: 1 (Unless user
changed it by the DIP switch configuration), baud rate: 2400.
(3) In order to change the output type follow the instructions below:
(2) Monkey wrench
(4) Straight Screwdriver
(6) Socket head wrench
(8) Hammer
(10) BNC Clamp
