Omnipod DASH™ Insulin Management System 1
Selecting, Adding and Deleting Items
Toggles
Tap a toggle to change the selection from one side to the other.
Toggles allow you to choose between two options or to turn a feature on or
off. The toggle is on the right side and blue when a feature is on, and on the
left and grey when a feature is off.
Checkboxes, radio buttons and drop-down lists
Checkboxes are squares. Tap a checkbox to tick or untick it. You can tick more
than one checkbox in a list.
Radio buttons are circles. Tap a radio button to select it. A dot appears inside
the selected radio button. You can select only one radio button at a time. To
deselect a radio button, tap the radio button next to a different option.
A plus symbol in a circle indicates that you can add an item to a list. Tap the
plus symbol to add the item to the list.
A red x in a circle indicates that you can remove an item from a list. To
remove the item, tap the red x.

Navigation Icons and Navigation Shorthand

The PDM has buttons below the screen that can be used for navigation. In
addition, some screen icons can be used for navigation.
Back arrow and back button
Many screens display a "back" arrow icon in the upper left corner.
Tapping the back arrow returns to the previous screen.
Tapping the left-hand button below the PDM screen
generally also returns to the previous screen.
Drop-down lists are indicated by a down or up arrow
next to an item. The currently selected setting appears
to the left of the drop-down arrow. To select a different
option, tap the down arrow to show the drop-down
list of options. To replace the currently selected option
at the top, tap the desired option from the drop-down
list.
Tap the up arrow to hide the list of options.
Effective Date: 27SEP2019, ECO-000240
7
