Section 9

GAUGE SET-UP

Note: There are multiple selectable
parameters to choose from. Specific
parameters vary with vehicle applica
tion
1.
Press the center button on the
5-way navigator to take you to the
System Menu screen.
2.
Next, touch the 'Gauge Setup'
button. (See Figure 30)
3.
The current gauge display will be
shown in G3 and G4 (See Figure 42).
To change the displayed parameter,
scroll through and select from the
available parameters.
4.
Use the buttons labeled 'Up' and
'Down' to scroll through the list.
5.
To select the desired parameter,
highlight it by touching on the
parameter then touch on either the
G3 or G4 gauge button. The respective
gauge display will change accordingly.
26
96803 v.3.0
6 Press the 'Back' button twice to return
to the System Monitor screen. The
System Monitor screen will now display
your new G3 and G4 parameters.
-END, SECTION 9-
Figure 42
