User LED and button
The user LED and user button are located on the bottom-left corner of the board. Both LEDs are
controlled with GPIO signals, which can be found in the table below:
Device
User LED (red) GPIO3_IO11
User button
ConnectCore 6UL SBC Express Hardware Reference Manual
Signal
GPIO3_IO3
User LED and button
36
