INSTALLING VERTICAL STABILIZER.

1) While holding the vertical stabilizer firm-
ly in place, use a pen and draw a line on each
side of the vertical stabilizer where it meets
the top of the fuselage.
6
2) Using a modeling knife, remove the cov-
ering from over the precut hinge slot cut into
the lower rear portion of the fuselage.
2x15mm
3) Next assemble and install the rudder con-
trol horn as the process for elevator control
horn.
move it, cut with only enough pressure to only
cut through the covering itself. Cutting into
the balsa structure may weaken it.
4) Slide the vertical stabilizer back in-
place. Using a triangle, check to ensure
that the vertical stabilizer is aligned 90º
to the horizontal stabilizer.
Instruction Manual.
Remove covering.
When cutting through the covering to re-
Epoxy.
