Angel 2000 Glider
Instruction Manual.
ELEVATOR - RUDDER PUSHROD
Nylon Snap keeper.
HORN INSTALLATION.
1) Install the elevator control horn using
the same method as with the aileron con-
trol horns.
2) Position the elevator control horn on
the both side of elevator.
M2 clevis.
M2 lock nut.
8mm
Elevator pushrod.
Control horn
Elevator pushrod.
Control horn
Fuel tubing.
8mm
Hex Nut.
M2 clevis.
Rudder pushrod.
8
