ICO300-83B Series User's Manual
⚫ Features
◼ Fanless design
◼ Wide temperature operation of -40℃ - +70℃
◼ 2 10/100/1000 Base-T Ethernets with Magnetic Isolated Protection
◼ 4 COM Ports support RS-232/422/485
◼ 2 Wireless (USB and PCIe Interface)
◼ Support one 2.5" SATA drive bay (or mSATA )
◼ Wide range 12–24V DC-in with terminal block
◼ 1 DI/DO (8-bit programmable, DB9 female connector)
◼ Din-rail mounting
◼
Wall mounting (optional)
◼ Passed CE with FCC testing
⚫ Embedded O.S. Supported
◼ ICO300 not only supports Windows
®
Windows
supports one SATA SSD (or HDD) and one mSATA.
1.2

System Specifications

1.2.1

CPU

⚫
Onboard Intel® Celeron® N3350 (1.1GHz) or N4200 (1.1GHz)
1.2.2

BIOS

⚫
AMI (American Megatrends Inc.) UEFI (Unified Extensible Firmware Interface)
BIOS.
1.2.3

System Memory

⚫
One DDR3L 204-pin SO-DIMM (1.35V) slot.
⚫ Supports 1333/1600 MHz up to 8GB.
1.2.4

Display

1 x HDMI (up to 1920 x 1200 @60Hz)
⚫
2
10 embedded and Linux package support. For storage device, ICO300
®
10, but also supports embedded OS, such as
Introduction
