3.3 VectorVision compact Camera & Monitor Kit
Attachment
3.3.1 Introduction
This section provides general information on the attachment of the monitor and camera to the Vec-
In this Section
torVision compact system.
You can use the information provided here to perform a visual check to ensure that all screw con-
nections are secure.
• The camera is attached to the VectorVision compact system with the VectorVision camera
About the Kits
• The monitor is attached directly to the VectorVision compact frame.
Handling the
Camera and
Monitor Kits
The monitor and camera are preassembled with the VectorVision compact system and are adjust-
Assembly
ed at Brainlab assembly facilities. The camera arm can be replaced as a unit.
Technical User Guide Rev. 2.7 VectorVision & Kolibri
arm kit.
Do not attempt to attach the monitor or camera kits to the system, nor detach the kits
from the system.
51
