12
C
2
H A P T E R
Assembly
Unpacking and Delivery Form
Unpacking
Delivery Form
WARNING
Danger of breakage!
The ceramic inlet filter of probe 2 is fragile.
Step
Action
1
Unpack the component parts of probe 2 (see below).
2
Make sure that any accompanying accessories do not get lost.
3
Check the contents of the delivery to ensure that it is complete by
comparing the actual goods with the dispatch note.
NOTE
Keep the packing material for possible future transport.
If damage has occurred during transport due to improper handling, please submit
a damage report to the transport institution (railway company, post office,
forwarding agency) within seven days.
Probe 2 is supplied in various partially pre-assembled component parts:
Gas sampling probe with flange and internal heating rod
Ceramic inlet filter (inner filter)
Installation set for mounting the ceramic inlet filter
(4 bolts M12 x 70 with nuts, spring washers and washers)
Harting connector, degree of protection IP55 (only for probe version
"heated, 650 W", catalog no. 23022-4-0768301)
Protective box (option), degree of protection IP54
Carry out the final assembly at the service location as described in the section
"Assembling Probe 2" on page 13.
