Technical Data

Probe 2

Permissible Operating Parameters
Process gas pressure
pabs
Temperature
Flow rate
Dust content
Back-purging pressure
Heating temperature of the
inlet filter
90% time (T )
90
Filter fineness
Ambient temperature
Voltage
Pneumatic Connections
Sample gas
Compressed air (purging
air) or test gas
Ceramic Inlet Filter
Dimensions
Retention rate
max. 400 kPa (4 bar)
max. 450 °C (Probe tube partially heated), max. 130 °C (Probe tube heated)
max. 2000 l/h, relative to 100 kPa (1 bar) and 0 °C
max. 20 g/m (application recommendation), max. 100 g/m
3
max. 600 kPa (6 bar)
≥ 200 °C (at process gas temperature = 20 °C)
< 2 s at 250 l/h
0.3 µm
+5...+50 °C
230 VAC, 50...60 Hz (115 VAC on inquiry)
Gas ports with G 1/4 female thread (DIN ISO 228/1) for threaded connections
for pipe with 6 mm outer ∅
for hose with 6 mm inner ∅
Gas ports with G 1/4 female thread (DIN ISO 228/1, provided with screw-type
blank cap)
Length: approx. 670 mm, area: approx. 975 cm
for particles > 5 µm 99.99 by weight %
for particles 3.0...5.0 µm 99.99 by weight %
for particles 1.4...3.0 µm 99.98 by weight %
for particles 0.5...1.4 µm 99.5 by weight %
for particles 0.3...0.5 µm 99.5 by weight %
with back-purging
3
, Catalog No.: 23005-4-0730705
