C-Mount Couplers - Stryker C-Mount User Insert

C-Mount
Couplers
Warnings and Cautions
1. Read these instructions thoroughly before using the coupler.
2. Inspect the coupler for any damage that may have occurred during
shipment.
3. Test the coupler for functionality before using it in a surgical
procedure.
4. This coupler is shipped non-sterile. Clean and sterilize the coupler
prior to the first use and after every subsequent use. Follow the
cleaning, disinfection, and sterilization instructions provided in these
instructions.
5. Federal law (USA) restricts this device to use by, or on order of a
physician.
Product Description and
Intended Use
Stryker Endoscopy C-mount couplers are used to attach endoscopes to
surgical camera heads. C-Mount couplers come in one of three models:
C-Mount, Autoclavable C-Mount, and Rotating C-Mount. Figures 1 and 2
label the parts of the coupler discussed in this manual.
1
Figure 1: C-Mount Coupler
1. Camera end
2. Focusing ring
3. Endobody clamp
Couplers
2
User Insert
3
4
