Data Polling EEPROM
Data Polling Flash
AT90S2313
70
2. Wait for at least 20 ms and enable serial programming by sending the Program-
ming Enable serial instruction to the MOSI (PB5) pin.
3. The serial programming instructions will not work if the communication is out of
synchronization. When in sync, the second byte ($53) will echo back when issu-
ing the third byte of the Programming Enable instruction. Whether the echo is
correct or not, all four bytes of the instruction must be transmitted. If the $53 did
not echo back, give SCK a positive pulse and issue a new Programming Enable
instruction. If the $53 is not seen within 32 attempts, there is no functional device
connected.
4. If a Chip Erase is performed (must be done to erase the Flash), wait t
after the instruction, give RESET a positive pulse, and start over from step 2.
See Table 30 for t
WD_ERASE
5. The Flash or EEPROM array is programmed one byte at a time by supplying the
address and data together with the appropriate Write instruction. An EEPROM
memory location is first automatically erased before new data is written. Use
Data Polling to detect when the next byte in the Flash or EEPROM can be writ-
ten. If polling is not used, wait t
See Table 31 for t
WD_PROG
need to be programmed.
6. Any memory location can be verified by using the Read instruction that returns
the content at the selected address at the serial output MISO (PB6) pin.
7. At the end of the programming session, RESET can be set high to commence
normal operation.
8. Power-off sequence (if needed):
Set XTAL1 to "0" (if a crystal is not used).
Set RESET to "1".
Turn V
power off.
CC
When a byte is being programmed into the EEPROM, reading the address location
being programmed will give the value P1 until the auto-erase is finished, and then the
value P2. See Table 27 for P1 and P2 values.
At the time the device is ready for a new EEPROM byte, the programmed value will read
correctly. This is used to determine when the next byte can be written. This will not work
for the values P1 and P2, so when programming these values, the user will have to wait
for at least the prescribed time t
30 for t
value. As a chip-erased device contains $FF in all locations, program-
WD_PROG
ming of addresses that are meant to contain $FF can be skipped. This does not apply if
the EEPROM is reprogrammed without first chip-erasing the device.
Table 27. Read Back Value during EEPROM Polling
Part
AT90S2313
When a byte is being programmed into the Flash, reading the address location being
programmed will give the value $7F. At the time the device is ready for a new byte, the
programmed value will read correctly. This is used to determine when the next byte can
be written. This will not work for the value $7F, so when programming this value, the
user will have to wait for at least t
erased device contains $FF in all locations, programming of addresses that are meant
to contain $FF can be skipped.
value.
before transmitting the next instruction.
WD_PROG
value. In an erased device, no $FFs in the data file(s)
before programming the next byte. See Table
WD_PROG
P1
$80
before programming the next byte. As a chip-
WD_PROG
WD_ERASE
P2
$7F
0839G–08/01
