MCR54 User Manual
T
S
ECHNICAL
PECIFICATIONS
Frequency ranges
Switchable channels
Switching-window
Frequencies
Frequency error
Modulation
Peak deviation
Antenna input impedance 50 ohm sma type (SWR < 1:2; typ. 1:1.4)
Sensitivity
Amplitude response
Adjacent chan. selectivity
Spurious emissions
Noise Reduction system
AF bandwidth
Frequency response
Distortion
SND/D ratio (Analog)
SND/D ratio (Digital)
Audio output
Digital sample rate
Monitor output
Managing interface
LEDs
Display
Powering
Power consumption
Temperature range
Dimensions
Weight
22
MCR54 B1: 470 ÷ 800 + 961÷1000 + 1045÷1075 MHz (UK)
MCR54 B2: 470 ÷ 800 + 823÷832 + 940÷960 MHz (USA/EU)
MCR54 B3: 470 ÷ 800 + 806÷809 + 1240÷1260 MHz (JP)
2400 user programmable frequencies, organized in 40 groups of 60 channels
up 790 MHz
microprocessor controlled frequency synthesizer circuit, with 5 kHz minimum step.
The frequencies can be easily PC reprogrammed with USB C, Bluetooth 5 (long range) or optional
UPKmini Programming
< ± 2.5 ppm, in the rated temperature range
FM mono, wideband or narrowband IFB (SW selectable)
±54 kHz (wideband), ± 40 kHz (narrowband)
2 μV ( 6 dBμV), for SND/N > 58 dB;
5 μV (14 dBμV), for SND/N > 98 dB
in the whole switching-window*
< 0.5 dB (for RF input signal:6 dBµV ÷ 100 dBµV)
> 80 dB typical (for channel spacing ≥ 400 kHz)
< 2 nW (typical = 0.1 pW)
ENR / ENR-1.2 (Wisycom Extended-NR) , noise optimized
ENC / ENC-1.2 (Wisycom Extended-NC), voice optimized & with reduced pre-emphasis
ENS (for live application)
Others, compatible with most systems, thru an internal DSP emulation of SA572, SA575 and Rms
envelope compander chip set, fully user programmable
30 Hz ÷ 20 kHz (wideband), 30 Hz ÷ 15 kHz (narrowband)
± 0.5 dB in the 30 Hz ÷ 19 kHz range (wideband),
± 0.5 dB in the 30 Hz ÷ 13 kHz (narrowband)
0.3 % typical
120 dB typical*
> 125 dB typical
Electronically balanced on 5 pin mini-XLR Female connector analog or digital (SW selectable)
AES3 @ 48 kHz
headphone 3.5 mm jack socket
USB C, Bluetooth 5 (long range) or optional UPKmini Programming
2 multicolour RGB LEDs to easy indicates Power & Bluetooth
4 multicolour RGB LEDs to easy indicates the audio status of the 4 RX
OLED 128x64 (white)
- External = 5 ÷ 18 Vdc (2.5 W max)
- Autonomous. = with optional BCA 54 Battery Module
2.5 Watt max (with 4 active receivers)
-10 ÷ +55 °C
110,4 x 87,6 x 25 mm (H x W x D)
245g
