MCR54 User Manual
With SLK54-SX it is possible to enabled AES outputs only on AUX (Top Feed). Analog Base outputs
can be configured with any combination of 2 receivers (RX1+RX2, RX2+RX3, ...)
None
AUX
15
AUX (on TOP FEED)
CH1
An [RXi]
AES [RX1+RX2]
1
GND
2
CHANNEL1+
3
CHANNEL1-
4
CHANNEL2+
5
CHANNEL2-
CH2
An [RXi]
An [RXi]
An [RXi]
AES [RX3+RX4]
MAIN (on SLK54-SX)
2
CHANNEL1
3
CHANNEL2
CH1
CH2
An [RXi]
An [RXi]
