MCR54 User Manual
CABLES
17
AF cable (50 cm), mini XLR-5F / 2 XLR-3M
CAM50-3
connectors
AF cable (50 cm), mini XLR-5F / 1 XLR-3M
connectors
CAM50-41
Line 1 feed XL3-M (TO BE USED FOR AES3 CAMERA
INPUT)
External power feeding cable, hirose/raw wires (50
CDC34
cm)
AC/DC Power Supply, Switch Mode with Hirose 4 pin
connector (to use one "desktop" apparatus alone)
PSP910-H
Input:100 ÷ 240V ac
Ouput:12V@700mA, 8W
Plug type: EU
USB Cable 1m
CAUSBC1
USB B - USB C Male Black
To monitor/control/power on MCR54 receiver
