MCR54 User Manual
Setup Menu
Active RXs
Edit RX1/RX2/RX3/RX4
Scan
Headphones
Display
Adv. Audio
Signalling
Act. Code
Panel locked
8
RX1 RX2 RX3 RX4
Name
"8 characters max"
Frequency
Group / Channel and Frequency selection
Ch. Modulation
Wide/Narrow (HD)
Compander
ENR Wis/ENC Wis...
Sq. mode
OFF/Long Range/Normal/User
LINE level
AES3 level
Audio Out
Sign. Phase
Cal. Tone
Sync
Scan now
Channel/Freq
Scan squelch
OFF- 0/3/6/9/12/15/18/21/24/28/32/36/40/46 dBμV
Scan BNT
Channel/Freq
View last
Volume
0/-24 step 1dB
RX sel
RX1/RX2/RX3/RX4
LED mode
Full/Alarm/OFF
Brightness
0/5
Low Timeout
5/60 sec (step 5 sec)
OFF Timeout
10/120 sec (step 10 sec) / OFF
AES3 enabled
None/MAIN/AUX
AUX1
RX1/RX2/RX3/RX4
AUX2
RX1/RX2/RX3/RX4
AUX1 level
18dBu/-24dBu step 1dB
AUX2 level
18dBu/-24dBu step 1dB
Audio off
RX1 RX2 RX3 RX4
TX Batt.
RX1 RX2 RX3 RX4
No/Yes
Cal Tone
OFF/ON
Frequency
400/600/1000 Hz
Level
-30 to 0 dB (1 dB step)
visible only with
SLK54-IKSS
