MCR54 User Manual
Power on
Allow to enable/disable each single receivers:
Edit RX (same menu for each of the 4 receivers)
Edit RX: Name
Selecting Name, it's possible to edit the name of the receiver (12 characters). The number of visible
characters depends on the type of characters used (uppercase or lowercase characters).
Edit RX: Frequency
Select current group and channel. If the specific group/channel is not locked, frequency can be
edited in this menu.
Edit RX: Channel modulation
Narrowband or Wideband software selectable according to transmitter modulation.
NOTE: During the SYNC process the receiver sends the type of modulation (NB or WB) and the TX adapts
automatically to the receiver's modulation settings accordingly.
Edit RX: Compander
MCR54 supports 5 different type of "Compander systems" (others on request through Digicom)
ENS: designed for voice and music applications
ENR-Wisy: designed for maximum noise reduction. Ideal for use in louder environments.
ENC-Wisy: designed for maximum audio fidelity (use this in case of special vocal application or to
remote instruments). Ideal for use in quite environments.
ENR-1.2*/ENC-1.2*: to use with some type of camera (ex. Canon® C300, Canon® XF305, Sony®
Pmw200, Sony® Pmw300, Sony® PmwF5, Sony® Fs7, Nikon® D600 or Nikon® D800,
Canon® SD mark3...) which accept a signal with reduced dynamic. This type of expansion
doesn't add artifacts to the signal and allows to have a less noisy signal. It allows to
improve the quality of the audio registration (compared to the ENR/ENC standard)
increasing the S/N ratio up to 15dB.
To use these expanders, it's necessary to set ENR on the transmitter and ENR 1.2 on the
receiver or set ENC on the transmitter and ENC 1.2 on the receiver.
ENR-1.2 it's used for the optimization of noise, ENC-1.2 it's used to optimize the voice.
NOTE: The compander of the receiver must be the same as the transmitter
MCR54 core is a power digital audio processor that, besides an unbeatable audio quality and
flexibility, can emulate most expanders systems on the market. On this menu you can setup the
9
