LeaksProtect User Manual
Updated October 18, 2019
Miniature wireless detector LeaksProtect detects a minimal leakage,
allowing for timely response and elimination of the problem.
LeaksProtect operates within the Ajax security system, by connecting via
the protected
protocol to the
. The communication range is up to
Jeweller
hub
1300 meters if there are no obstacles. In addition, the detector can be used
as part of third-party security central units due to the
or
uartBridge
ocBridge
integration module.
Plus
The detector is set up via a
for iOS and Android-based
mobile application
smartphones. The user is notified of all events through push notifications,
SMS messages and calls (if activated).
The Ajax security system is self-sustaining, but the user can connect it to
the central monitoring station of a private security company.
Buy leakage detector LeaksProtect
Functional Elements

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LeaksProtect and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX LeaksProtect

Summary of Contents for AJAX LeaksProtect

  • Page 1 The user is notified of all events through push notifications, SMS messages and calls (if activated). The Ajax security system is self-sustaining, but the user can connect it to the central monitoring station of a private security company. Buy leakage detector LeaksProtect...
  • Page 2 4. On/off button of the device LeaksProtect Operating Principle LeaksProtect has contacts at the bottom of its body, sensitive to water leakage – if at least one contact pair gets wet, the detector will immediately transmit an alarm signal to the hub, notifying the user and private security company.
  • Page 3 Only users with administrative privileges can add the device to the hub. How to connect the detector to the hub: 1. Select the Add Device option in the Ajax application. 2. Name the device, scan/write manually the QR Code (located on the body and packaging), and select the location room.
  • Page 4 Request for connection to the hub is transmitted for a short time at the time of switching on the device. If the connection to the hub failed LeaksProtect will switch off after 6 seconds. To retry the connection, you do not need to turn off the device. If LeaksProtect was already assigned to another hub, switch it off, then perform the standard adding procedure.
  • Page 5 States 1. Devices 2. LeaksProtect Parameter Value Temperature of the Detector. This is measured on the proces Temperature and changes gradually. Signal Strength Signal strength between the hub and the detector Connection Connection status between the hub and the detector...

  • Page 6: Setting Up The Detector

    Setting Up the Detector You may rename the detector, change the location room, as well as delete it from the list of devices of the hub. 1. Devices 2. LeaksProtect 3. Settings Setting Value First field Detector name, can be edited...
  • Page 7 Indication The LeaksProtect light indicator may light up red or green depending on the device status. Indication When Pressing the “On” button Event Indication Pressing the power button (detector is switched on) Lights up red while the button is held down...

  • Page 8: Functionality Testing

    Functionality Testing The Ajax security system allows conducting tests for checking the functionality of connected devices. The tests do not start straight away but within a period of 36 seconds when using the standard settings. The test time start depends on the settings of the detector scanning period (the paragraph on “Jeweller”...

  • Page 9: Detector Testing

    When the detector contacts are exposed to liquid, the resistance between them drops. To activate the alarm, it is sufficient that at least one contact pair of LeaksProtect is closed. 1. To check the flood detector, close the contact pair with a wet finger for 3 seconds (the delay will prevent any false actuation).

  • Page 10: Tech Specs

    Detector Maintenance and Battery Replacement Check the operational capability of the LeaksProtect detector on a regular basis. We recommend cleaning the sensor contacts as it gets dirty, at least, once per 2-3 months. Use an alcohol solution for cleaning. Clean the detector body from dust, spider web and other contaminations as they appear –...

  • Page 11: Warranty

    2. Batteries AAA (pre-installed) – 2 pcs 3. Quick Start Guide Warranty Warranty for the “AJAX SYSTEMS MANUFACTURING” LIMITED LIABILITY COMPANY products is valid for 2 years after the purchase and does not apply to the pre-installed battery. If the device does not work correctly, you should first contact the support service —...
