CombiProtect user manual
Updated June 20, 2024
CombiProtect is a device combining a wireless motion detector with the viewing
angle of 88.5° and distance up to 12 meters, as well as a glass break detector
with the distance up to 9 meters. It can ignore animals and detects a person
within the protected zone from the first step. It can operate for up to 5 years
from a pre-installed battery and is used inside premises.
CombiProtect operates within the Ajax system, connected to the
hub
via the
protected
Jeweller
protocol. The communication range is up to 1200 meters in
the line of sight. In addition, the detector can be used as a part of third-party
security central units via the
Ajax uartBridge
or
Ajax ocBridge Plus
integration
modules.
The detector is set up via a
mobile application
for iOS and Android based
smartphones. The system notifies user of all events through push notifications,
SMS messages and calls (if activated).
The Ajax system is self-sustaining, but the user can connect it to the central
monitoring station of a private security company.
