LifeQuality Jeweller User manual
LifeQuality Jeweller is a wireless air quality detector. Measures temperature,
humidity, and CO (carbon dioxide) concentration in the room. Reports air
pollution using an LED indicator and notifications in Ajax apps, enables
automation scenarios.
A hub is required for the detector to operate. The list of compatible hubs and range
extenders is
LifeQuality operates as part of the Ajax system, communicating with the hub
over two secure radio protocols:
to transmit measurements, while Wings transmits data backups. The hub
communication range is up to 1,700 meters without obstacles.
Buy LifeQuality Jeweller
Updated March 8, 2023
2
available here
.
Jeweller
and
Wings
: the detector uses Jeweller

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LifeQuality Jeweller and is the answer not in the manual?

Questions and answers

Related Manuals for AJAX LifeQuality Jeweller

Summary of Contents for AJAX LifeQuality Jeweller

  • Page 1 A hub is required for the detector to operate. The list of compatible hubs and range extenders is available here LifeQuality operates as part of the Ajax system, communicating with the hub over two secure radio protocols: Jeweller Wings : the detector uses Jeweller to transmit measurements, while Wings transmits data backups.

  • Page 2: Functional Elements

    4. Device QR code and ID (serial number). It is used to connect the device to Ajax system. Operating principle 00:00 00:12 LifeQuality Jeweller is a wireless air quality detector. The detector monitors the temperature, humidity, and CO (carbon dioxide) concentration, measuring them...

  • Page 3: Temperature And Humidity Sensor

    LifeQuality measurements are available in Ajax apps in the Devices tab. A PRO or a user with system configuration rights can set up comfort thresholds of temperature, humidity, and CO (carbon dioxide) concentration. When values go beyond the specified limits, hub users receive notifications pointing out which indicator is outside the norm.

  • Page 4: Data Storage

    The history of measurements is presented by charts. Charts show the trend of the selected air quality value over the last hour, day, week, month, or year. Ajax system stores this data on the Ajax Cloud server for up to 2 years.
  • Page 5 The protocols support floating key block encryption and device recognition on every session to prevent sabotage and spoofing. To monitor connection with system devices and display their statuses Ajax apps have a system of hub–detector polls with a frequency of 12 to 300 seconds. The...

  • Page 6: Adding To The System

    4. Make sure that the hub is turned on and has Internet access via Ethernet, Wi-Fi, and/or mobile network. You can do this in the Ajax app or by looking at the hub LED indicator: it lights up white or green.
  • Page 7 ReX 2, connect LifeQuality to the hub first. Then connect the detector to the range extender in its settings. Note that LifeQuality does not work with the ReX radio signal range extender. How to add LifeQuality Jeweller to the hub 1. Open the Ajax app 2.
  • Page 8 Once connected, LifeQuality will appear in the device list in the Ajax app. Device status update depends on the polling interval set in the Jeweller or Jeweller/Fibra settings. The default value is 36 seconds.
  • Page 9 Yellow — the selected parameter goes beyond acceptable values. When the CO (carbon dioxide) concentration in the air is selected: Green — 0–1000 ppm (acceptable level). Yellow — 1001–1399 ppm (high level, causes drowsiness). Red — 1400–1999 ppm (adverse health effects expected by prolonged exposure).

  • Page 10: Functionality Testing

    Functionality testing The Ajax system provides several tests for choosing the installation place with a stable signal for the devices. Jeweller and Wings signal strength tests are available for LifeQuality. Tests determine the strength and stability of the signal at the intended location of the device.

  • Page 11: State Icons

    (36 seconds by default). You can change the device ping interval in the Jeweller (or Jeweller/Fibra) menu in the hub settings. Icons Icons show some of the LifeQuality states as well as measured air quality indicators. You can view them in Ajax apps in the Devices  tab. State icons Icon Value Jeweller signal strength between LifeQuality and the hub (or range extender).
  • Page 12 States The states include information about the device and its operating parameters. You can see LifeQuality states in Ajax apps. To access them: 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the PRO app 3.
  • Page 13 4. Select LifeQuality from the list. Parameter Value Clicking the opens the list of detector malfunctions. Malfunction The field is displayed only if a malfunction is detected. Air temperature in the room where LifeQuality is installed. Measured in Celsius or Fahrenheit depending on the app settings.
  • Page 14 Signal strength between LifeQuality and the hub or radio signal range extender via Jeweller. The recommended value is two or three bars. Jeweller Signal Strength Jeweller is a protocol for transmitting LifeQuality events and alarms. Connection status between LifeQuality and the hub or range extender via Jeweller: Online —...
  • Page 15 Normal state. Battery low — batteries are discharged. We recommend replacing the batteries with new ones. When the charge level is low, the Ajax apps and the security company receive a related Battery Сharge notification. After receiving the low battery notification, the detector can operate for several months more under normal conditions.
  • Page 16 Device No. to the monitoring station with this number. Settings To change LifeQuality settings in the Ajax app: 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the PRO app 3.
  • Page 17 The virtual room to which LifeQuality is assigned. To change the room, click on the field. Room The room name is displayed in the text of SMS and notifications in the events feed. Air monitor settings The settings of the lower and upper limits of a comfortable temperature.
  • Page 18 CO level — if enabled, users will receive notifications once the carbon dioxide concentration goes beyond the specified limits. The settings of the threshold of sensitivity for device sensors and the period of time after which users will be notified about worsening of air quality: Temperature —...
  • Page 19 CO Sensor Calibration How to run the CO sensor calibration manually User Guide Opens LifeQuality User Manual in the Ajax app. Temporary Deactivation Allows to temporarily disable the device without removing it from the system. Two options are available:...
  • Page 20 Unpairs LifeQuality from the hub and deletes its Unpair Device settings. How to set up scenarios 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the PRO app 3. Go to the Devices tab.
  • Page 21 The option will not be available at the time of release. Support for data transfer via Wings will appear in the next OS Malevich updates. 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the PRO app 3.
  • Page 22 . Select an interval: Hour Week Month Year You can also switch between detector measurements inside the screen. To do this, select the indicator in the menu above.
  • Page 23 For example, take it outside or leave it by an open window. The CO sensor is calibrated at the operating temperature of 0°C to +50°C. To start calibration: 1. Open the Ajax app. 2. Select the hub if you have several of them or if you are using the PRO app 3.

  • Page 24: Selecting The Installation Place

    . Go to СО Sensor Calibration menu. 7. Click Start and wait for the calibration to finish. The CO sensor is calibrated for up to 20 minutes. After clicking the Start button, the timer in the app will start the countdown. Calibration ends automatically after the countdown is completed —...

  • Page 25: Signal Strength

    Presence of barriers for radio signal passage between devices: walls, interfloor ceilings, large objects located in the room. Consider the placement recommendations when designing your Ajax system for the object. The security system must be designed and installed by specialists.

  • Page 26: Installation

    Do not install the detector Outdoors. This could damage the detector. In places with fast air circulation. For example, near fans, open windows, or doors. This can lead to incorrect measurements. Opposite any objects with rapidly changing temperature. For example, near electric and gas heaters.
  • Page 27 . Place the detector on the SmartBracket mounting panel. Malfunctions If malfunction is detected (for example, there is no connection with the hub or range extender), the Ajax app displays a malfunction counter in the device field. Malfunctions are displayed in the detector States .

  • Page 28: Maintenance

    Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase. If the device does not function correctly, please contact the Ajax Technical Support first. In most cases, technical issues can be resolved remotely.
  • Page 29 User Agreement Contact Technical Support: e-mail Telegram Subscribe to the newsletter about safe life. No spam Email Subscribe...
