AJAX GlassProtect Fibra User Manual

Hide thumbs Also See for GlassProtect Fibra:
Table of Contents

Advertisement

Quick Links

Download this manual
GlassProtect Fibra User Manual
GlassProtect Fibra is a bus glass break detector. Designed for indoor use.
Supports connection of a third party normally closed detector.
The detector is compatible with
other
hubs radio signal range extenders ocBridge Plus uartBridge
,
central panels are not provided.
GlassProtect Fibra works as part of the Ajax security system, exchanging data
with the hub using the secure Fibra wired protocol. Communication range — up
to 2,000 m when connected via twisted pair U/UTP cat.5.
GlassProtect Fibra is the device of the new Fibra wired product line. Such
devices can only be purchased, installed and administered by accredited Ajax
partners.
Buy GlassProtect Fibra
Updated March 11, 2022
Hub Hybrid (2G)
and
,
Hub Hybrid (4G)
. Connection to
,
and third-party

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GlassProtect Fibra and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX GlassProtect Fibra

Summary of Contents for AJAX GlassProtect Fibra

  • Page 1 Fibra wired protocol. Communication range — up to 2,000 m when connected via twisted pair U/UTP cat.5. GlassProtect Fibra is the device of the new Fibra wired product line. Such devices can only be purchased, installed and administered by accredited Ajax partners.

  • Page 2: Functional Elements

    6. Perforated part for wire output through the wall. 7. Perforated part for wire output underneath the detector. 8. QR code with the device ID. Used to connect to the Ajax security system. 9. Terminal strip for detector connection. 10. Tamper button.
  • Page 3 Owing to this algorithm, the detector does not respond to the barking of dogs or cars passing by the protected facility. GlassProtect Fibra will not respond to a break if a lm is glued to the glass: anti-shock, sun-protective, decorative, or other. To detect the break of such glass, we recommend...
  • Page 4 Connection of third-party wired detector You can connect an external wired NC (normally closed) detector to GlassProtect Fibra detector. This detector can be of any type: motion, opening, or vibration detector. GlassProtect Fibra will not power the third-party detector. The detector should be connected separately.
  • Page 5 The addressability of each Ajax device allows you to send events and the type of the device, the name assigned to it, and the room to the PRO Desktop or the CMS.
  • Page 6 The glass break detection zone Consider the placement recommendations when designing your facility’s security system. Only professionals should carry out the design and installation of the security system. A list of authorized o cial Ajax partners is available here Design and preparation It is important for the security system to work correctly to prepare the project and install the detectors and devices properly.
  • Page 7 We recommend laying cables inside walls, oors, and ceilings. This will provide greater security; the wires will not be visible, and it will be impossible for an intruder to access them. When selecting a cable, consider the length of the connection lines and the number of detectors to be connected;...

  • Page 8: Detection Zone

    The permissible cable length depends on its type, material, and the method of connecting the detectors. When connected using the Star connection method with a twisted pair U/UTP cat.5 (4×2×0.51), the wired connection length can be up to 2,000 meters. When devices are connected using the Ring connection method, the maximum cable length is 500 meters when using a twisted pair.

  • Page 9: Installation And Connection

    This could damage the detector. Installation and connection Before installing GlassProtect Fibra, make sure that you have selected the optimal location and that it meets the requirements of this manual. Wires must be hidden from view and located in a di cult place for burglars to access to reduce the likelihood of sabotage.
  • Page 10 Do not use special sleeves to crimp the wire ends and connect them to the detector. GlassProtect Fibra body is not designed for crimped wire connection. To mount a detector: 1. Turn off the hub. Disconnect the external power and the hub’s backup battery.
  • Page 11 4. Run the cabel from the hub into the detector’s body through the hole made. 5. Connect the wires to the terminals according to the scheme below. Be sure to follow the polarity and connection order of the wires. Securely fasten the cable to the terminals.
  • Page 12 6. If the detector is not the last one in the line, prepare and run the cable for the next detector into the GlassProtect Fibra terminals. 7. If the detector is the last in the line, install a termination resistor at the end of the connecting line if the Star connection method is in place.

  • Page 13: Adding To The System

    2. Ensure that the hub is turned on and has internet access via Ethernet and/or mobile network. You can check the connection status in the Ajax app or by looking at the LED on the hub board. It should light up white or green.
  • Page 14 5. Click Add. To add detectors automatically: 1. Open the PRO version of the app. Select the hub you want to add GlassProtect Fibra to. 2. Go to the Devices tab and click Add Device. 3. Select Add Bus Devices. The hub will scan all buses. A list of devices connected to the hub but not added to the system will appear on the screen.
  • Page 15 If the detector is connected to the hub successfully, it will disappear from the list of available devices. Method 2: By alarm Enable the Add Detectors by Alarm option above the list of detectors. Trigger an alarm by simulating the breaking of glass: 1.
  • Page 16 GlassProtect Fibra only works with one hub. When connected to a new hub, the detector stops exchanging commands with the old one. Once added to a new hub, GlassProtect Fibra is not removed from the list of devices of the old hub. This must be done through the Ajax app.
  • Page 17 Malfunctions If a hub identi es a detector fault (for example, there is no connection with the hub via the Fibra protocol), the Ajax app will display a malfunction counter in the upper left corner of the device icon. All faults can be seen in the detector states. Fields with malfunctions will be highlighted in red.
  • Page 18 Learn more GlassProtect Fibra will work when the Night Mode is enabled. Learn more GlassProtect Fibra has detected a glass break. The icon is displayed regardless of the security mode. External contact of GlassProtect Fibra detector is enabled. Learn more GlassProtect Fibra is deactivated disabled.
  • Page 19 2. Choose GlassProtect Fibra from the list. Parameter Meaning Detector temperature — it is measured on the processor and changes gradually. The maximum error between the value in the Temperature app and the room temperature is 2–4°C. The value is updated as soon as the detector identi es a temperature change of at least 1°C.
  • Page 20 Delay When Entering, sec Delay time when entering (5 to 120 seconds). Delay when entering (alarm activation delay) is the time the user has to disarm the security system after entering the secured area. Learn more Delay time when leaving (5 to 120 seconds). Delay when leaving (arming delay) is the time the user has to leave the secured area after Delay When Leaving, sec...
  • Page 21 By the number of alarms — the device is automatically disabled by the system when the number of alarms is exceeded. The feature is con gured in the Ajax PRO apps. By timer — the device is automatically disabled by the system when the recovery timer expires.
  • Page 22 Settings To change GlassProtect Fibra detector settings in the Ajax app: 1. Go to the Devices tab. 2. Choose GlassProtect Fibra from the list. 3. Go to Settings by clicking on the gear icon 4. Set the required parameters.
  • Page 23 What Is Delay When Leaving If active, the set delays when entering/leaving will also apply in the Night Mode. Delays in the Night Mode What is the Night mode What Is Delay When Leaving If active, the detector switches to the armed mode when the Night Mode is enabled.
  • Page 24 Detection Zone Test alarms from a third-party NC detector, and determine the optimal installation location. Learn more Opens the GlassProtect Fibra User Manual in User Manual the Ajax app. Temporary Deactivation Allows temporary to disable the device without removing it from the system.
  • Page 25 The feature is used, for example, in stores to notify employees that someone has entered the building. Chime is set in two stages: setting up opening detectors and setting up sirens. In GlassProtect Fibra, chime applies to connected NC detectors only. Learn more Detector settings 1.

  • Page 26: Functionality Testing

    6. Select the noti cation sound: 1 to 4 short beeps. Once selected, the Ajax app will play the sound. 7. Click Back to save the settings. 8. Set up the siren. How to set up a siren for Chime...

  • Page 27: Maintenance

    3. Choose GlassProtect Fibra. 4. Go to Settings 5. Choose a test: Fibra Signal Strength Test Detection zone 6. Launch and conduct a test. To test the break detector: 1. Start a detection zone test. 2. Hit the glass (without breaking it) or another surface with your st. If the detector microphone catches a low-frequency sound, the LED will blink.

  • Page 28: Complete Set

    Warranty for the AJAX SYSTEMS MANUFACTURING Limited Liability Company products is valid for 2 years after the purchase. If the device does not function correctly, please contact the Ajax Technical Support rst. In most cases, technical issues can be resolved remotely.
