LNS QUICK LOAD SERVO S3 Startup Manual page 13

12
3.3
Specifications
Bar profile
Bar diameter
Length of pieces to be machined
Thickness of the cutoff tool
a)
Conditions:
Press the [MENU] key; the remote command displays the following text :
Note :
For more
information
concerning
the
parameters,
see Chapter 7,
point 5.
Press the [ENTER] key; the remote command displays the following text :
Square
Press the [ENTER] key twice; the remote command displays the following text:
QUICK LOAD SERVO III
Example 3 : Start-up for square bars
Set-up of parameters :
The loading table is in low position
2 bars of the new diameter are on the loading table
Bar feeder in STOP mode
1 : P A R T S E T U P
2 : A P P L I C A T I O N S E T U P
3 : P O S I T I O N / T O R Q U E
4 : M I S C E L L A N E O U S
5 : S E R V I C E
1 : R O U N D M A T E R I A L
2 : H E X A G O N A L
3 : S Q U A R E
4 : O T H E R S
Square
40.0 mm across the flats
58.0 mm
2.0 mm
M A I N M E N U
F U N C T I O N S
L O A D I N G O F :
[ @ ]
P R M 8 7
N E W S T O C K
D I A M E T E R
0 . 0 0 0 I N C H E S
C U R R E N T D I A M E T E R
[ * * * * ] I N C H E S
E D I T N E W V A L U E A N D
P R E S S F 4 ( E N T E R )
START UP MANUAL
On the keypad, select [3]
