Settings Related To Bar Stock And Machined Parts - LNS QUICK LOAD SERVO S3 Startup Manual

8
3.
3.1
Specifications
Bar profile
Bar diameter
Length of pieces to be machined
Thickness of the cutoff tool
a)
Conditions:
Press the [MENU] key; the remote command displays the following text :
Note :
For more
information
concerning
the
parameters,
see Chapter 7,
point 5.
command displays the following text :
QUICK LOAD SERVO III

SETTINGS RELATED TO BAR STOCK AND MACHINED PARTS

Example 1: Start-up for round bars
Set-up of parameters :
The loading table is in low position
2 bars of the new diameter are on the loading table
Bar feeder in STOP mode
1 : P A R T S E T U P
2 : A P P L I C A T I O N S E T U P
3 : P O S I T I O N / T O R Q U E
4 : M I S C E L L A N E O U S
F U N C T I O N S
5 : S E R V I C E
1 : R O U N D M A T E R I A L
2 : H E X A G O N A L
3 : S Q U A R E
4 : O T H E R S
Round
20.0 mm
55.0 mm
2.0 mm
M A I N M E N U
L O A D I N G O F :
[ @ ]
P R M 8 7
START UP MANUAL
Press the [1] key; the remote
