4.
4.1
Three feeding pushers are necessary to cover the entire range of the Quick Load Servo II
bar feed system. Each pusher has a defined range of operation :
Pusher diameter
*
**
Replacement :
Bring the loading channel into working
mode position (down position), then place
the bar feed system into the STOP mode
(remote station).
1.
2.
3.
4.
•
•
•
•
QUICK LOAD SERVO III

MECHANICAL SETTINGS AND OPTIONAL ACCESSORIES

Feeding pusher
**6,35 mm (1/4")
12 mm (1/2")
25 mm (1")
This ordering number corresponds to the complete pusher, with all of the elements
indicated below. When a feeding pusher is ordered for the first time, use this
number.
2 extra roller supports, intended to bolster the support of bars of small diameter, are
furnished with the 6.35 mm diameter pushers. Their placement on the loading table
will be determined by the length of the bars to be loaded.
Loosen the fastening screws (A)
sufficiently to free the groove (C)
that holds the pusher (B) in the
connecting piece (D).
Slide the pusher forward by making
into the guide bushing (E).
When the rear of the pusher is
sufficiently loosened to be able to
remove it, pull the guide bushing
(E) toward the back to dislodge it.
The pusher is now free and can be
removed.
Place the new pusher into the
opening, and insert the guide
bushing.
Introduce the rear of the pusher
into the connection piece and push
to a stop.
Tighten the fastening screws so that they lodge into the groove of the pusher.
Check to see that the mechanical stop sleeve is properly positioned (see next
section)
Ordering Nr
*021.011.022 / 6
*021.011.062
*021.011.022 / 25
START UP MANUAL
Diameter Range
6 mm - 15 mm (1/4" - 1/2")
16 mm - 32 mm (>2/3" - 1 1/4")
33 mm - 120 mm (>1 1/4" - 4,7")
