Switch to the "▼Make-up" main menu.
•
Press "OK" to open the menu.
Use the "▼" and "▲" buttons to navigate to the next main menu option.
•
Switch to the "Make-up>" main menu.
•
Press "Quit" to return to the previous main menu option.
Use the "▼" and "▲" buttons to navigate within the selected main menu option.
•
Time for a make-up cycle:
–
If the set time is exceeded, the system interrupts the make-up.
–
The system returns the "Make-up" fault message.
Number of make-up cycles:
–
If the set number of make-up cycles is exceeded within 2 hours, the system interrupts
the make-up and returns the "Make-up cycles" fault message.
–
The system returns the "Make-up cycles" fault message.
The system displays the "With water meter" menu option.
–
Select one of the following options:
FQIRA+ contact water meter is installed, see chapter 4.6 "Optional equipment and
YES:
accessories" on page 12 .
The contact water meters is required for make-up quantity monitoring and the
operation of a softening system.
NO:
Standard model. A contact water meter is not installed.
The following entries are only displayed if "YES" has been set in the "With water meter"
menu option.
Make-up quantity:
–
Press "OK" to change the entry. – Select one of the following settings:
•
Press "YES" to reset the value displayed to "0".
•
Press "No" to retain the displayed value.
Maximum make-up quantity.
–
The system interrupts the make-up if the set quantity is exceeded.
–
The "Max. make-up qty" fault message is returned.
Softening:
–
Select one of the following options:
YES
The system offers queries regarding the softening process.
NO:
The system does not offer queries regarding the softening process.
The system displays the followingentries if "YES" has been set in the "With softening" menu
option.
Lock make-up:
–
Select one of the following options:
YES:
The system stops the make-up process when the set soft water capacity is
exceeded.
NO:
The system does not stop the make-up process. The system displays the "Softening"
message.
Fillcontrol Plus — 06.07.2016 - Rev. B
Make-up>
▼Make-up
Max. make-up time
020 min.
(023)
Max. make-up cycl.
003 / 2 h
(024)
With water meter
YES
Make-up quantity
000020 l
Max. make-up qty.
000100 l
With softening
YES
Lock make-up?
YES
English — 31
Controller
(027)
(028)
(029)
(030)
(031)
