Controller
9.2

Configuring settings in the controller

Use the Customer menu to display or correct system-specific values. In the course of commissioning, the factory settings must be
adjusted for the system-specific conditions.
Note!
For a description of the operation, see chapter 9.1 "Operator panel" on page 29 .
All grey marked menu items must be reviewed during commissioning.
• Press "Manual" to switch to manual operation.
• Press "Menu" to display the first main menu option "Customer menu".
Switch to the next main menu option.
• Press "Quit" to return to the previous main menu option.
Use the "▼" and "▲" buttons to navigate within the selected main menu option.
•
Set the required language.
Change the flashing display items for "Hour", "Minute" and "Seconds".
The set time is used for entries in the fault memory.
Change the flashing display items for "Day", "Month" and "Year".
This date is used for entries in the fault memory.
Magcontrol
– Select this setting for the fresh water make-up in systems with a diaphragm expansion
tank.
Levelcontrol
– Select this setting for the fresh water make-up in systems with a pressure maintaining
station.
The controller displays "Min. op. pressure" if the "Magcontrol" make-up variant is set.
– Enter the "P " minimum working pressure.
0
– For setting the minimum operating pressure, see chapter 7.2 "Determining the P
minimum operating pressure for the controller" on page 24 .
The controller displays "Safety valve pressure" if the "Magcontrol" make-up variant is set.
– Enter the activating pressure of the safety valve of the heat or cooling generator.
30 — English Fillcontrol Plus — 06.07.2016 - Rev. B
▼Customer menu
Language
Time:
Date:
Fillcontrol xx
Magcontrol
Min. op. pressure
0
01.8 bar
Safety valve pressure
03.0 bar
(005)
(006)
