Reflex Fillcontrol Plus Operating Manual page 22

Installation
Terminal
Signal
number
1 PE
2 N
3 L
4 PE
5 N
6 M1
10 Y1
11 N
12 PE
13 COM
14 NC
15 NO
16 Not assigned
17 Makeup (230 V)
18 Makeup (230 V)
19 PE shield
20 - Level (signal)
21 + Level (+ 18 V)
22 PE (shield)
23 - Pressure (signal)
24 + Pressure (+ 18 V)
25 0 – 10 V (correcting
variable)
26 0 – 10 V (feedback)
27 GND
28 + 24 V (supply)
29 A
30 B
31 GND
32 + 24 V (supply)
33 E1
34 E2
22 — English
230 V power supply via mains cable and plug.
Not used.
Not used.
Group message (floating).
External makeup demand for level-dependent makeup.
• From a pressurisation station, for example.
(Set the controller to "Levelcontrol")
Not used.
Pressure analogue input.
• Display at the controller.
• Activation of the makeup.
– For the "Magcontrol" makeup variant
Not used.
RS-485 interface.
Supply for E1 and E2.
Contact water meter (in "Fillset Impuls", for example), see
chapter 4.6 "Optional equipment and accessories" on page 12 .
• Evaluation of the makeup.
• Contact 32/33 closed = meter pulse.
Not used.
Fillcontrol Plus — 06.07.2016 - Rev. B
