8
Operation
8.1
Operating modes
8.1.1
Automatic mode
In automatic mode, the device is switched in continuous operation. To start the automatic operation, proceed as follows:
•
Press "Auto" on the controller's operator panel.
The automatic mode "Auto" LED illuminates to visually signal continuous operation. The controller monitors the makeup functions.
8.1.2
Manual mode
Manual mode is used to test the functions during commissioning and to service the device. The functions available for selection depend
on the set mode, "Levelcontrol" or "Magcontrol".
The following functions can be selected manually:
•
In "Levelcontrol" mode: Manual opening and closing the "WV" make-up valve.
•
In "Magcontrol" mode: Manual opening and closing the "WV" make-up valve or "Filling".
Proceed as follows to test the functioning in "Levelcontrol" mode:
1.
Press "Manual".
–
The "Auto" LED flashes.
–
"WV" flashes at the display.
2.
Press "OK".
–
The make-up valve opens. The displays shows "WV!".
3.
Press "OK".
–
The make-up valve closes. The displays shows "WV".
Proceed as follows to test the functioning in "Magcontrol" mode:
1.
Press "Manual".
–
The "Auto" LED flashes.
2.
Use the arrow keys to select "WV" or "Filling".
–
"WV" or "Filling" flashes at the display.
3.
Press "OK".
–
The make-up valve opens or the filling process is started. The displays shows
"WV!" or "Filling".
4.
Press "OK".
–
The make-up valve closes or the filling process is stopped. The displays shows
"WV" or "Filling".
Note!
The controller calculates the pressure required for filling. As soon as this value has been attained, the controller
automatically stops the filling process.
Note!
Manual operation can not be performed if safety-relevant parameters are exceeded.
•
The switch is blocked.
Fillcontrol Plus — 06.07.2016 - Rev. B
2.0 bar
WV!
Filling
English — 27
Operation
