2.5 VFX-M Connections

There is just one connector on the front panel of the VFX-M. It is a 25 pin
Cannon MDSM Micro D-sub. It brings all the RGB analog video,
Horizontal and Vertical Syncs, and DDC monitor control lines.
A custom made breakout cable, the MVK-1/3, available from Rastergraf,
enables standard VGA monitors to be connected. The MDSM end plugs
into the VFX-M and is retained with jackscrews. The VGA end duplicates
the VGA board side connector.
The following sections detail the applicable pinout information.
Breakout Cable
Connector Name
VGA
--
2-10 Installing Your Rastergraf Graphics Board
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
Section Connector
2.5.1 15-pin D-Sub
2.5.2 25-pin MDSM
Description
VGA
Front Panel Connector
