Rastergraf VFX-M User Manual page 76

Rastergraf
Index
5 wire VGA monitors, 2-6
Additional References, 1-6
Adjusting the Video Timing, 4-19
analog color map, 1-3
auto-increment, 4-12
Basic Troubleshooting Procedures, 5-29
Checking your Display, 2-9
color register, 4-5
CompactPCI, i
Configuration Information, 1-11
conventions used in manual, 0-4
display memories, 4-7
EEPROM, 1-7
Flash EEPROM, 4-23
fuse, 5-28
General Specifications, 1-7
initial testing, 2-2
interrupt settings, 2-4
interrupts, 4-22
Maintenance, 5-31
Monitor Requirements, 1-10
page fault, 4-12
pan, 4-20
PCI, i
Peritek Software and Operating Systems
Support, 3-2
pipelining, 3-2
PMC, i
PMC bus
installation, 2-3
Request for Timing Table, 4-21
Return Policy, 5-31
scroll, 4-20
Serial EEPROM, 4-24
Service, 5-32
system memory, 4-7
technical support, 0-2
unpacking your graphics board, 2-2
VFX-M Serial EEPROM Example Listing,
4-25
VFX-M Side 1 Major Parts Locations, 2-7
VGA Video Connector, 2-11
