2.5.2 VFX-M Front Panel Connector

As mentioned before, the VFX-M uses a 25-pin ITT Cannon MDSM
(MDSM-25PE-Z10) connector for the video connections. It is necessary to
build a breakout cable to make connections to standard devices. Rastergraf
can supply the cable (MVK-1/3) or you can build it yourself.
You can get a 3 foot pigtail from ITT Cannon which has the MDSM
connector and a shielded twisted pair cable already made up. All you have
to do is wire the other end. The part number is CA111972-12.
Note: The pin list below shows the ITT Cannon pin numbers.

Table 2-3 VFX-M Connector Pinout (sorted by Function)

2-12 Installing Your Rastergraf Graphics Board
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
MDSM
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Description
Blue
ground
Green
ground
Red
ground
not used
ground
reserved – do not connect
ground
reserved – do not connect
ground
Horizontal Sync
ground
DDCCK
ground
DDCDA
ground
reserved – do not connect
ground
reserved – do not connect
ground
reserved – do not connect
ground
Vertical Sync
