12 Display
Indicates the current device activity or programme status.
13 [STOP]
Button to exit the Shape Generator. When the button is activated, the LED lights up.
14 [PLAY]
Button for subsequent selecting and editing a movement via [ Speed/Size]. When the button is activated, the LED flashes.
15 [Speed/Size]
Button for selecting and editing the speed of movement and size. When the button is activated, the LED lights up.
16 [Offset/Dir]
Button for selecting and editing position and direction. When the button is activated, the LED lights up.
17 [VIEW]
Button to call up the current shapes. When the button is activated, the LED lights up.
18 [TIME]
Button for subsequent editing PAN and TILT. When the button is activated, the LED lights up.
