LED Pixel Rail Drive
640 MKII
controller
user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stairville LED Pixel Rail Drive 640 MKII and is the answer not in the manual?

Questions and answers

Related Manuals for thomann Stairville LED Pixel Rail Drive 640 MKII

Summary of Contents for thomann Stairville LED Pixel Rail Drive 640 MKII

  • Page 1 LED Pixel Rail Drive 640 MKII controller user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 12.02.2019, ID: 449740 (V3)

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 7 Safety instructions............................. 9 Features............................... 16 Installation and starting up........................ 17 Connections and controls........................23 Operating..............................28 6.1 Menu overview..........................33 6.2 Functions in 10-channel DMX mode..................
  • Page 4 Table of contents Cleaning............................... 41 Protecting the environment......................42 controller...

  • Page 5: General Information

    Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. LED Pixel Rail Drive 640 MKII...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...
  • Page 8 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided.

  • Page 9: Safety Instructions

    Safety instructions Safety instructions Intended use This device is used to control Pixel Rail Strips (item no.: 449739). Use the device only as described in this user manual. Any other use or use under other operating conditions is consid‐ ered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
  • Page 10 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. Do not use the device if covers, protectors or optical components are missing or damaged.
  • Page 11 Safety instructions NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. LED Pixel Rail Drive 640 MKII...
  • Page 12 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter ‘Technical specifications’...
  • Page 13 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
  • Page 14 Safety instructions NOTICE! Possible staining The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet.
  • Page 15 Safety instructions NOTICE! Compatible devices The device may only be used with Stairville Pixel Rail 40 RGB MKII (item no. 449739). LED Pixel Rail Drive 640 MKII...

  • Page 16: Features

    Features Features Controller for up to 16 pixel rail strips (maximum four per output) of the type Stairville LED Pixel Rail 40 RGB MKII (Item no.: 449739) Control protocols: DMX (10/55 channels), ArtNet (4x480 channels), RDM Operating modes: Stand Alone (30 programmes), Master / slave In and outputs: DMX, RJ45 (ArtNet) Operating via buttons and display on the unit Lockable connections (Power Twist) for self-supply and to supply further devices...

  • Page 17: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 18 Installation and starting up Connection examples The following figures show the connection configuration of the pixel strips in the various oper‐ ating modes. Master / Slave operation controller...
  • Page 19 Installation and starting up Control via ArtNet LED Pixel Rail Drive 640 MKII...
  • Page 20 Installation and starting up Control via DMX controller...
  • Page 21 Installation and starting up NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers.
  • Page 22 Installation and starting up Notes on wiring The following figure shows the maximum permissible cable lengths. A maximum of four Stair‐ ville LED Pixel Rail 40 RGB MKII may be connected per output. controller...

  • Page 23: Connections And Controls

    Connections and controls Connections and controls Front panel LED Pixel Rail Drive 640 MKII...
  • Page 24 Connections and controls 1 [POWER IN] Lockable input socket (Power Twist) for power supply 2 [POWER OUT] Lockable output socket (Power Twist) for the power supply of further units. 3 Fuse holder 4 [Switch] Main switch to turn the device on and off. 5 Safety cable eyelet.
  • Page 25 Connections and controls 9 [UP] Increases the displayed value by one. 10 [DOWN] Decreases the displayed value by one. 11 [SIGNAL] Indicator LED. This LED lights up on incoming signal. LED Pixel Rail Drive 640 MKII...
  • Page 26 Connections and controls Rear panel controller...
  • Page 27 Connections and controls 12 [DMX IN] DMX input (3 and 5-pin) to control the device via DMX. 13 [ARTNET IN] RJ45 input to control the device via ArtNet. 14 [ARTNET OUT] RJ45 output to control other devices via ArtNet. 15 [DMX OUT] DMX output (3 and 5-pin) for connecting additional DMX devices in a DMX universe.

  • Page 28: Operating

    Operating Operating Connect the device to the power grid and turn it on with the main switch [Switch] . Operating mode Auto Automatic operation can only be activated when the unit is operating alone or as master in a master / slave combination. This setting is only relevant if the device is not controlled via DMX or ArtNet.
  • Page 29 Operating Parameter Function Speed Programme speed, value range ‘1’ … ‘9’ (slow … fast). Program Programme selection, value range ‘01’ … ‘29’ , ‘Mix’ . DMX address This setting is only relevant when the device is controlled via DMX. Press [MODE] and use the buttons [UP] and [DOWN] to select the ‘DMX Address’ option. Con‐ firm with [ENTER] to open the ‘DMX Address’...
  • Page 30 Operating Software info This menu offers you the option to display the currently installed software version. Press [MODE] and use the buttons [UP] and [DOWN] to select the ‘Software Version’ option. Confirm with [ENTER] to display the version information. With [MODE] you return to the previous menu level. Length and number of the pixel In this menu you determine the length and thus the number of possible pixel strips per output.
  • Page 31 Operating Network settings In this menu you determine the network settings. Press [MODE] and use the buttons [UP] and [DOWN] to select the ‘Network Settings’ option. Confirm with [ENTER] to open the ‘Network Settings’ menu. Use the buttons [UP] and [DOWN] to select the desired option and confirm with [ENTER]. Adjust the displayed value with [UP] and [DOWN] and press Enter to confirm each new setting.
  • Page 32 Operating Operating mode Slave This setting is only relevant if the device is controlled via DMX and working as slave in a master / slave configuration. Press [MODE] and use the buttons [UP] and [DOWN] to select the ‘Slave Mode’ option. Confirm with [ENTER] and use [UP] and [DOWN] to select the ‘YES’...

  • Page 33: Menu Overview

    Operating 6.1 Menu overview LED Pixel Rail Drive 640 MKII...

  • Page 34: Functions In 10-Channel Dmx Mode

    Operating 6.2 Functions in 10-channel DMX mode Channel Value Function 0 … 255 Dimmer function (0 % … 100 %) 0 … 255 Strobe effect (slow … fast) 0 … 255 Intensity red LED (0 % … 100 %) 0 … 255 Intensity green LED (0 % …...

  • Page 35: Functions In 55-Channel Dmx Mode

    Operating 6.3 Functions in 55-channel DMX mode Channel Value Function 0 … 255 Dimmer function (0 % … 100 %) 0 … 255 Strobe effect (slow … fast) 0 … 255 Automatic programme 1 (multi colour effect. The last effect will be played automatically.) 0 …...

  • Page 36: Network Connection

    Operating Channel Value Function … 0 … 255 Intensity blue, fourth spotlight at the fourth output 6.4 Network connection ArtNet For operation via ArtNet, first Install the necessary software on your PC (Windows or Mac with fixed IP address). Connect the pixel rail strips to the controller and switch it on. Give the con‐ troller an IP address corresponding to the ArtNet settings.

  • Page 37: Technical Specifications

    Technical specifications Technical specifications Control protocols DMX (10/55 channels) ArtNet (4x480 channels) Number of DMX channels 10 or 55, depending on operating mode Input connections DMX control XLR chassis sockets, 3 and 5-pin ArtNet control RJ45 Voltage supply Power Twist Output connections DMX control XLR chassis sockets, 3 and 5-pin...
  • Page 38 Technical specifications Strobe effect 0 … 25 Hz Cable length max. 80 m (CAT6 cable) Power consumption max. 400 W Operating supply voltage 100 – 240 V 50/60 Hz Fuse 5 mm × 20 mm, 5 A, 250 V, fast-acting Protection class IP20 Dimensions (W ×...

  • Page 39: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...
  • Page 40 Plug and connection assignment DMX connections A five-pin XLR socket serves as DMX output, a five-pin XLR plug serves as DMX input. The drawing below and the table show the pin assignment of a matching coupling. Assignment Ground (shielding) Signal inverted (DMX–, ‘cold’) Signal (DMX+, ‘hot’) unused / second connection (DMX–) unused / second connection (DMX+)

  • Page 41: Cleaning

    Cleaning Cleaning Device components Clean the device components that are accessible from the outside regularly. The cleaning fre‐ quency depends on the operating environment: damp, smoky or particularly dirty environ‐ ments can cause greater accumulation of dirt on the device components. Clean with a dry soft cloth.

  • Page 42: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
