Johnson Controls IFC-200 Wiring Manual page 64

Terminal Conversion Charts for V-type and H-type Devices
C.2 M300CJ and M302MJ
Solenoid A-
Solenoid A+
Solenoid B/A +
Solenoid B/A -
V-type Terminal Number
1
2
3
4
5
6
7
8
9
N/A
N/A
64
SLC -
SLC +
VDC -
VDC +
Type V
Terminal Function
SLC -
SLC +
VDC -
VDC +
Unused
Solenoid B/A -
Solenoid B/A +
Solenoid A +
Solenoid A -
Unused
Unused
Table C.2 M300CJ and M302MJ Terminal Conversions
Johnson Controls, Inc. SLC Wiring Manual — P/N 51870:G 04/23/2009
