NFPA Style 6 SLC

4.3 NFPA Style 6 SLC
NFPA Style 6 requirements can be met by using the diagram below.
SLC Out
SLC Return
B+ B– A– A+
Control Panel
SLC
NOTE: T-tapping of the SLC wiring is NOT allowed for Style 6 configuration.
Johnson Controls, Inc. SLC Wiring Manual — P/N 51870:G 04/23/2009
Two-wire Addressable Detector
Addressable Module
Figure 4.2 Basic NFPA Style 6 SLC
SLC Circuits without Isolators
27
