B.2.4: Ifc-640/E, Ifc-3030 - Johnson Controls IFC-200 Wiring Manual

SLC Surge Suppression
SLCP-30 Connections
Optional Four-wire
Return Loop
Style 6 (Class A)
NOTE: Do not connect shield (if present) to surge protector or fire panel.
B.2.4 IFC-640/E, IFC-3030/IFC2-3030
DTK-2LVLP-F Connections
Optional Four-wire
Return Loop
Style 6 (Class A)
NOTE: Do not connect shield (if present) to surge protector or fire panel.
PLP-42N Connections
Optional Four-wire
Return Loop
Style 6 (Class A)
NOTE: Use 12 AWG (3.31 mm
connect the unit's ground terminal to equipment ground. Wire length must be minimized to
provide best protection. Do not connect shield (if present) to surge protector or fire panel.
SLCP-30 Connections
Optional Four-wire
Return Loop
Style 6 (Class A)
NOTE: Do not connect shield (if present) to surge protector or fire panel.
62
SLCP-30
–
+
SLC Loop
–
+
IN
–
+
SLC Loop
–
+
IN
PLP-42N
SLC Loop
2
) to 18 AWG (0.82 mm
SLCP-30
–
+
SLC Loop
–
+
IN
Johnson Controls, Inc. SLC Wiring Manual — P/N 51870:G 04/23/2009
SLC Terminal Block
OUT
2LVLP-F
OUT
2
) wire with crimp-on connectors to
SLC Terminal Block
OUT
Installation
SLC Terminal Block
SLC Terminal Block
