Page 1: Table Of Contents
• Left Mount • Mounting the Backbox • Door Assembly Instructions • CAB-3 Series Backboxes • Mounting the ICA-4L • Component Placement *Indicates those sections where changes have occurred since the last printing. © 2000 Johnson Controls, Inc. Code No. LIT-448155 www.johsoncontrols.com...
Page 2 All manuals and user guides at all-guides.com Page • Optional Chassis Mounting • Other Components • Display Interface Connection Power Supplies • AC Primary Power Input • MPS-24A or MPS-24AE Main Power Supply • Mounting the Main Power Supply • MPS-TR Main Power Supply Monitor •...
Page 3 All manuals and user guides at all-guides.com Serial Communications Page 107 • Optional Serial Interface Boards *107 • CRT-2 Terminal • Remote Printers *113 • Annunciator Modules *117 Standard-Specific Requirements • System Components *123 • NFPA 72-1999 Auxiliary Fire Alarm Systems *126 •...
Page 4 All manuals and user guides at all-guides.com Hardware Installation—Installing the IFC-1010/2020...
Page 5: Safety Guidelines
All manuals and user guides at all-guides.com Safety Guidelines Adherence to the following will aid in problem-free installation with Installation long-term reliability: Precautions WARNING: Several different sources of power can be connected to this Fire Alarm Control Panel (FACP). Disconnect all sources of power before servicing.
Page 6 All manuals and user guides at all-guides.com • Verify that wire sizes are adequate for all initiating and indicating device loops. Most devices cannot tolerate more than a 10% I.R. drop from the specified device voltage. • Like all solid-state electronic devices, this system may operate erratically or can be damaged when subjected to lightning induced transients.
Page 7: Fire Alarm System Limitations
All manuals and user guides at all-guides.com While installing a fire alarm system may make lower insurance rates Fire Alarm possible, it is not a substitute for fire insurance. System Limitations • An automatic fire alarm system, typically made up of smoke detectors, heat detectors, manual pull stations, audible warning devices, and a fire alarm control with remote notification capability can provide early warning of a developing fire.
Page 8: Fcc Warning
All manuals and user guides at all-guides.com • Telephone lines needed to transmit alarm signals from a premise to a central monitoring station may be out of service or temporarily disabled. The most common cause of fire alarm malfunctions, however, is inadequate maintenance.
Page 9: Introduction
All manuals and user guides at all-guides.com Introduction The product that this document supports is UL (Underwriters Location of Laboratories) Multiple Listed, which requires that the content of the Content documentation inherited from the manufacturer remain intact. Minor Changes changes clarify information such as vendor-specific product names and literature names and numbers.
Page 10 All manuals and user guides at all-guides.com Voice Prerecorded or live voice alarm messages can be dispatched through an Evacuation audio message generator. A fire fighters master telephone unit allows Functions communication between the control panel and fire fighters telephones installed throughout the system.
Page 11: Fire Alarm And Related Service Standards
All manuals and user guides at all-guides.com It is imperative the installer understand the requirements of the Authority Fire Alarm and Having Jurisdiction (AHJ) and review the following documents for Related Service applicability: Standards • NFPA 72 National Fire Alarm Code 1993 •...
Page 12 All manuals and user guides at all-guides.com Hardware Installation—Installing the IFC-1010/2020...
Page 13: Installation Overview
All manuals and user guides at all-guides.com Installation Overview The basic equipment package for the Johnson Controls IFC-2020 is the Basic BE-2020 and the basic equipment package for the Johnson Controls Equipment IFC-1010 is the BE-1010. The following list may be used to identify various components in a received BE-2020 and/or BE-1010 shipment.
Page 14 All manuals and user guides at all-guides.com Hardware Installation—Installing the IFC-1010/2020...
Page 15: Cabinet And Component Installation
All manuals and user guides at all-guides.com Cabinet and Component Installation The cabinet assembly consists of two basic components; the backbox General (SBB) and door (DR). All cabinets for the IFC-1010/2020 are fabricated from 16-gauge steel. Cabinet parts are painted gray or red with navy blue windows. Provided with the key-locked door are a pin-type hinge, window, two keys, and the necessary hardware to mount the door to the backbox.
Page 16: Left Mount
All manuals and user guides at all-guides.com On a left mounted door, the Display Interface Assembly (DIA) dress panel Left Mount cannot be opened when the door is at less than a 120 degree angle to the cabinet. If you are using the left mounting option, be sure that the door can open at least 120 degrees.
Page 17: Door Assembly Instructions
All manuals and user guides at all-guides.com CAUTION: Unless you are familiar with the placement of components within this backbox, use only the knockout locations provided for conduit entry. Hinges can be either left or right mounted. The illustrations and text depict Door Assembly a left-mount example.
Page 18 All manuals and user guides at all-guides.com Bottom Left Corner Star Washer doorasy2 Figure 4: Door Assembly–Bottom Left Corner 4. Install the door alignment tabs (C) in the unused slots on the backbox (top and bottom) as shown in Figure 5. (In this example the door was mounted on the left, leaving the unused slots on the right).
Page 19: Series Backboxes
All manuals and user guides at all-guides.com The lock mechanism as viewed in a Open left-hinged mounting application. The lock world be placed in the right side of the door (as shown below). Locked Install Lock Here drlock Figure 6: Mounting the Lock CAB-3 Series Backboxes CAB-A3...
Page 20 All manuals and user guides at all-guides.com CAB-B3 The CAB-B3 is the cabinet and door assembly for two mounting tiers. An optional TR-B3 trim ring is available for use with the B-size cabinet (24.125 in. width by 28.625 in. height). The following replacement parts are available: DR-B3 door and SBB-B3 backbox.
Page 21: Mounting The Ica-4L
All manuals and user guides at all-guides.com CAB-D3 The CAB-D3 is the cabinet and door assembly for four mounting tiers. An optional TR-D3 trim ring is available for use with the D-size cabinet (24.125 in. width by 45.875 in. height). The following replacement parts are available: DR-D3 door and SBB-D3 backbox.
Page 22 All manuals and user guides at all-guides.com 16 Pins ICA-4L 16 Pins 16-position Receptacle 16 Pins ica2lib1 16-position Receptacle Figure 11: ICA-4L 16-position Receptacle Connections Expansion power cable, Part Number 75379, is able to mate properly with the ICA-4L since it consists of a 16-pin plug and a 16-position receptacle (Figure 12).
Page 23 All manuals and user guides at all-guides.com Power Cable Part Number 75378 Main Power Supply ICA-4L Expansion Power Cable Part Number 75379 Audio 6 5 4 3 2 1 8 7 6 5 4 3 2 1 6 5 4 3 2 1 Page Mode On Line AUDIO LEVEL...
Page 24 All manuals and user guides at all-guides.com Any board with a 15-position receptacle suitable for use on the ICA-4 may also be mounted on the 16-pin plug ICA-4L. The following nine boards have 15-position receptacles and may be installed on the ICA-4L: •...
Page 25 All manuals and user guides at all-guides.com Cable Part Number 75142 15-position 15-position Receptacle Plug cbl75142 Figure 16: Cable, Part Number 75142 Cable Part Number 75142 15-position Receptacle 16th Pin Front View (Chassis in Cabinet) cablecn Figure 17: Cable, Part Number 75142 Connected to the ICA-4L Hardware Installation—Installing the IFC-1010/2020...
Page 26 All manuals and user guides at all-guides.com Figure 18 illustrates the installation of a LIB-200, LIB-200A, and/or LIB-400 module in the back right position of an Interconnect Chassis Assembly (behind the CPU, which is installed later). Installation of boards in the remaining ICA-4L positions involve a similar procedure. Step 1 Place the board in front of the Interconnect Chassis Assembly (ICA-4L) in the position where it will be installed.
Page 27: Component Placement
All manuals and user guides at all-guides.com Each component in the system has a specific mounting position in the Component cabinet. Mount any optional AVPS supplies and amplifiers in Placement CHS-4/4L chassis Positions A through D as required. It is recommended that the CHS-4/4L chassis always be installed in the lowest cabinet row available (refer to Table 2).
Page 28 All manuals and user guides at all-guides.com Figure 20 depicts the LIB SLC numbering scheme for an IFC-1010 in a CAB-B3 cabinet. If CAB-A3 cabinet is used with LIB-400 modules exclusively, it may house a maximum four loop IFC-1010 system. One or two ICA-4L or ICA-4 chassis are required to mount the LIB modules, depending upon the number and type of LIB modules employed.
Page 29 All manuals and user guides at all-guides.com Figure 21 depicts the LIB SLC numbering scheme for an IFC-2020 in a CAB-D3 cabinet. Three ICA-4L chassis are required to mount the various types of LIB modules employed. Refer to Figure 20 as an example of IFC-1010 applications.
Page 30 All manuals and user guides at all-guides.com Figure 22 depicts a CAB-A3 cabinet used with LIB-400 modules exclusively, which means it may house a maximum four loop IFC-1010 system. An ICA-4L or ICA-4 chassis (neither of which is shown in the figure) is required for mounting the LIB-400.
Page 31 All manuals and user guides at all-guides.com Figure 23 depicts the IFC-1010 with a combination of LIB-400, LIB-200A, and LIB-200 modules installed in the first and second rows of a CAB-C3 cabinet. Two ICA chassis are required, but are not shown in the figure.
Page 32 All manuals and user guides at all-guides.com Figure 24 depicts a CAB-C3 cabinet used with LIB-400 modules exclusively, which means it may house a maximum ten loop IFC-2020 system. AN ICA-4L or ICA-4 chassis (neither of which is shown in the figure) is required for mounting the LIB-400.
Page 33 All manuals and user guides at all-guides.com Figure 25 depicts the IFC-2020 with a combination of LIB-400, LIB-200A, and LIB-200 modules installed in the first and second rows of a CAB-C3 cabinet. Two ICA chassis are required, but are not shown in the figure.
Page 34: Other Components
All manuals and user guides at all-guides.com If employing an optional CHS-4/4L chassis (Figure 26), mount the chassis Optional in the lowest available row in the cabinet, below previously mounted Chassis interconnect chassis assemblies (ICA-4L). The CHS-4/4L is marked to Mounting identify the top of the chassis.
Page 35 All manuals and user guides at all-guides.com INTELLIGENT FIRE DETECTION AND ALARM SYSTEM READ STAT US STEP POWER IFC-1010/2020 FIRE ALL SYSTEMS NORMAL 12:00P 3/01/93 ALTER SIGN AL ALARM STAT US SILENCE TROUBLE/ SECURITY SYST EM PRO G ALARM RESET DISPLAY TROUBLE BAC K...
Page 36 All manuals and user guides at all-guides.com DIA-1010 and/or DIA-2020 provide access to the system CPU and the Display optional SIB, and an EIA-232 unsupervised printer interface (Figure 28). Interface Connection When terminal supervision is not required and the terminal (if present) has no keyboard, the DIA-1010 and/or DIA-2020 provide an EIA-485 interface, which may be used to connect an LCD-80 (in Terminal mode).
Page 37 All manuals and user guides at all-guides.com Figure 29 depicts system wiring placement. 71030 (to ICA) DIA-1010 71031 DIA-2020 SIB-2048A CPU-2 SIB-NET CPU-2020 75226 71046 LIB-200 LIB-200 71033 71072 71070 71071 1 2 3 4 5 6 Battery Battery MPS-24A/E wireplac CAUTION: Be sure to allow for BP-3 Battery...
Page 38 All manuals and user guides at all-guides.com Figure 30 depicts a typical IFC-1010/2020 installation and is provided as a guide for proper wiring placement. The AC and battery wiring are not power-limited. A separation of at least 1/4 inch must be maintained between power-limited and non power-limited wiring.
Page 39 All manuals and user guides at all-guides.com Figure 31 is provided as a guide for dress panel placement. DIA-1010 or DIA-2020 INTELLIGENT FIRE DETECTION AND ALARM SYSTEM ACK/ READ STEP STATUS JOHNSON CONTROLS IFC-1010 A.C. ALL SYSTEMS NORMAL 04:08P 01/01/92 POWER SIGNAL ALTER SILENC E...
Page 40 All manuals and user guides at all-guides.com Hardware Installation—Installing the IFC-1010/2020...
Page 41: Power Supplies
All manuals and user guides at all-guides.com Power Supplies The IFC-1010/2020 requires connection to a separate dedicated AC fire AC Primary alarm circuit, which must be labeled FIRE ALARM. This AC circuit Power Input must connect to the line side of the main light and power feed of the protected premises.
Page 42 All manuals and user guides at all-guides.com The main power supply (MPS-24A or MPS-24AE) provides up to MPS-24A or 3.0 amperes of regulated current for operating the system in standby MPS-24AE (non-fire alarm) and up to 6.0 amperes during fire alarms. The MPS-24A Main Power Supply or MPS-24AE contains battery charging circuitry...
Page 43 All manuals and user guides at all-guides.com Primary, This column allows the user to calculate the current that will be drawn Non-Fire Alarm from the MPS-24A or MPS-24AE during a non-fire alarm condition, with Current AC power applied. This current draw cannot exceed 3.0 amperes. (amperes) Secondary, The last column of Table 5 allows the system designer to calculate the...
Page 44 All manuals and user guides at all-guides.com Table 5: IFC-1010/2020 System Current Draw Calculations Category Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, Non-Fire Current (amperes)* Current (amperes) Alarm Current (amperes) X Current Total X [Current Total X Current Total Draw] = Draw] = Draw] = x [0.162] =...
Page 45 All manuals and user guides at all-guides.com Category Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, Non-Fire (Cont.) Current (amperes)* Current (amperes) Alarm Current (amperes) X [Current Total X [Current Total X [Current Total Draw] = Draw] = Draw] = x [0.00030] x [0.00030] x [0.00030] M510CJ...
Page 46 All manuals and user guides at all-guides.com Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, Non-Fire Category Current (amperes)* Current (amperes) Alarm Current (amperes) (Cont.) X [Current Total X [Current Total X [Current Total Draw] = Draw] = Draw] = Notification x [ ] = x [ ] = Appliances...
Page 47 All manuals and user guides at all-guides.com Category Primary, Non-Fire Alarm Primary, Fire Alarm Secondary, (Cont.) Current (amperes)* Current (amperes) Non-Fire Alarm Current (amperes) X [Current Total X [Current Total X [Current Total Draw] = Draw] = Draw] = x [0.00084] x [0.00084] x [0.00084] XP5-C Relay...
Page 48 All manuals and user guides at all-guides.com Maximum Use Table 6 to determine the maximum current requirements of the Secondary secondary power source during fire alarm conditions. The total obtained in Power Fire Table 6 is the amount of current that the batteries must be capable of Alarm Current supplying.
Page 49 All manuals and user guides at all-guides.com Table 7: Secondary Power Standby and Fire Alarm Load Type of Load Required Time Result Required Secondary Non-Fire Alarm Secondary Secondary Non-Fire Alarm Standby Ampere Hours Non-Fire Alarm Standby Time Load (from 3rd column (24 or 60 hours) Table 5)
Page 50 All manuals and user guides at all-guides.com Battery Testing You may need to test the standby batteries occasionally. Here are two testing procedures you can use to determine the charge condition and capacity of the batteries in the system. Quick Test The quick test is a measure of charge condition;...
Page 51 All manuals and user guides at all-guides.com 2. Measure time of load. Take a fully charged battery and install the load resistor across the terminals. b. Measure the voltage across the battery for a period of 20 hours. If during the test the terminal voltage drops below the minimum acceptable levels (10.2 VDC for a 12 volt battery and 20.4 VDC for a 24 volt battery), note the number of hours that have elapsed when the battery voltage drops below its minimum operational...
Page 52 All manuals and user guides at all-guides.com Test of Ground Fault Detection Circuit If you have a persistent ground fault and suspect the MPS-24A ground fault detection circuit may be generating a false indication, use this test: 1. Remove the upper right circuit board mounting screw, just to the right of P2.
Page 53 All manuals and user guides at all-guides.com New Screw MPS-TR Board Standoff MPS Power Supply Board Existing Threaded Stud screw Figure 33: Threading the New Screws Mounting Hole (Keyhole Slot for Adjustment) 1 2 3 4 5 6 1 2 3 4 5 Screw MPS-TR MPS Series Power Supply...
Page 54 All manuals and user guides at all-guides.com Normally Closed Relay Common Normally System Common Open System Common MPS-24 Terminal Connection MPS-24A MPS-24A TB3-4 MPS-24B MPS-24B TB2-4 Syscomm Figure 35: System Common Terminal Connection Note: Relay contacts are specified in the NORMAL (no trouble condition) state.
Page 55 All manuals and user guides at all-guides.com Table 9 provides the MPS-24A or MPS-24AE main power supply load Connecting the capacitance. Figure 36 illustrates connections for primary and secondary Main Power power to the MPS-24A or MPS-24AE, as well as terminal and harness Supply connections for the control panel.
Page 56 All manuals and user guides at all-guides.com System Harness The power harness (Part Number 71030) provides internal power for Connections circuit boards installed in the ICA-4L. Connect this harness from P2 or P4 on the MPS-24A or MPS-24AE to Plug A on the uppermost ICA-4L (see Figure 29).
Page 57 All manuals and user guides at all-guides.com Table 9: MPS-24A or MPS-24AE Main Power Supply Loads (Regulated, Filtered Supply) Condition Maximum Maximum Circuit Type Description Supply Load Circuit Load (See Notes) (All Circuits) (Per Circuit) 3.0 amperes 3.0 amperes Internal 3 amperes of the power supply capacity Non-Fire are reserved for the battery charger when...
Page 58 All manuals and user guides at all-guides.com Four Wire Smoke Detector Power 24 VDC (20.4-26.4, 200 mV ripple), 1 ampere maximum Filtered, regulated,and resettable. Power-limited, but must Secondary Power be supervised via a power supervision relay. 27.6 VDC, supervised and power-limited. Fast charge = 2 amperes, Trickle charge = 20 mA Battery...
Page 59: Optional Main Power Meter
All manuals and user guides at all-guides.com The optional Main Power Meter (MPM-2) may only be installed on the Optional Main main power supply, MPS-24A or MPS-24AE (refer to Figure 37). Power Meter DC VOLTS DC AMPS 15 20 25 30 35 Step 1 Remove the two screws in the bottom left-hand corner of the MPS-24A or MPS-24AE.
Page 60: Nr45-24 Remote Battery Charger
All manuals and user guides at all-guides.com The Remote Battery Charger, NR45-24 is capable of charging NR45-24 Remote Battery 20-55 ampere-hour batteries. This unit is required if the Charger MPS-24A must deliver more than 3 amperes of current when no fire alarm signal is present.
Page 61 All manuals and user guides at all-guides.com The remote battery charger, CHG-120, is capable of charging CHG-120 25-120 ampere hour batteries. This unit is required if the MPS-24A must Remote Battery deliver more than 3 amperes of current when no fire signal is present. Charger Batteries up to 120 AH can be housed with the charger in the BB-55 cabinet: Batteries up to 25 AH can be housed with the charger in...
Page 62 All manuals and user guides at all-guides.com CHG-120 120/240VAC, 50/60 HZ 24 VDC (supervised). Maximum charge current for batteries is 4.5 amperes (fast charge) or 20mA (trickle charge). Use 12 AWG (3.25 mm²) wire in conduit ( 6.096 meters [ 20 feet or less]).
Page 63 All manuals and user guides at all-guides.com The Audio/Visual Power Supply provides up to 3 amperes of unfiltered, AVPS-24 or unregulated special purpose notification appliance power. AVPS-24E Audio/Visual Power Supply Installation With the circuit breaker at the main AC distribution panel turned off, connect the primary power input of the AVPS-24 or AVPS-24E in parallel with the primary power input of the main power supply.
Page 64 All manuals and user guides at all-guides.com 24 VDC Special Application Power (For Connections M5X0CJs) Unfiltered, unregulated, power-limited, 3.0 amperes maximum. Auxiliary Notification Appliance Power Harness (For Connection to XP Transponder) TB-2 Trouble Cable Connect to P5 on the CPU cable (Part Number 71033).
Page 65 All manuals and user guides at all-guides.com Mounting an An APS-6R can mount to a CHS-4 or a CHS-4L for use in a CAB-3 Series APS-6R in a cabinet (CAB-A3, CAB-B3, CAB-C3, or CAB-D3). To mount the CAB-3 Series APS-6R, follow these instructions: Cabinet Place the APS-6R onto the mounting studs of the CHS-4 or CHS-4L.
Page 66 All manuals and user guides at all-guides.com Field Wiring an Figure 44 shows typical wiring for an APS-6R. APS-6R WARNING: Use extreme caution when working the APS-6R high voltage and AC line-connected circuits are present in the APS-6R. Turn off and remove all power sources.
Page 67 All manuals and user guides at all-guides.com Output Circuit 2 (24 VDC) Output Circuit 1 (24 VDC) You can use J1 and J2 in place of TB2 when the APS-6R is powering internal modules (such as, ICM-4, ICE-A, TCM-2, TCM-4, UZC-256, IFC-200, XPC-8) with compatible connectors.
Page 68: Central Processing Unit (Cpu-2020, Cpu-2)
All manuals and user guides at all-guides.com To trouble input on control panel: IFC-2020 CPU-2020 P5, IFC-1010 CPU-2 P5, XPP-1 P6. Cable 71033/75098 Cable 71033/75098 Cable 71033/75098 To AVPS-24 or AVPS-24E, CCM-1, AMG-1, or another APS-6R if these devices are employed. Aps6rbus Figure 45: Trouble Bus Connections for Multiple APS-6R Power Supply Configuration...
Page 69 All manuals and user guides at all-guides.com DALLAS DALLAS No Connection MOMUOLATILE SROM MOMUOLATILE SROM No Connection DALLAS DALLAS No Connection System Trouble/ Normally Open Contact MOMUOLATILE SROM MOMUOLATILE SROM Supervisory/ Normally Closed Contact Security Contacts Common No Connection General Normally Open Contact Alarm Normally Closed Contact...
Page 70 All manuals and user guides at all-guides.com Hardware Installation—Installing the IFC-1010/2020...
Page 71: Signaling
All manuals and user guides at all-guides.com Signaling The IFC-1010/2020 communicates with intelligent and addressable LIB Signaling initiating, monitor, and control devices through a LIB Signaling Line Line Circuit Circuit (SLC). The Loop Interface Boards LIB-200 and LIB-200A each control an SLC loop. For XP Transponders connected to SLCs, refer to XP Transponder Technical Bulletin (LIT-448180).
Page 72 All manuals and user guides at all-guides.com Notes: In Canada, ULC Standard S524, for the installation of fire alarm systems, refers to signaling line circuits as Data Communication Links (DCL). An NFPA Style 4 is equivalent to a DCLB, Style 6 to a DCLA, and Style 7 to a DCLR.
Page 73 All manuals and user guides at all-guides.com lib200 Figure 47: LIB-200 LIB-200A The LIB-200A field wiring is electrically isolated from the rest of the system so that any two ground faults on separate SLCs will not cause invalid replays from devices. A short to any other system circuit will not cause communication loss.
Page 74 All manuals and user guides at all-guides.com New LIB The following features are only present on the LIB-200: Features • A Noise Filter Module (NFM-1) is built in to reduce common mode noise on the SLC. • Local mode general alarm bus support (during a CPU board failure). During a CPU failure, if one of the initiating devices programmed to participate in Local mode is activated, the following will occur: •...
Page 75 All manuals and user guides at all-guides.com LIB SLC Loop Wiring Requirements Short the termination point of one branch at a time and measure the DC Branch Resistance resistance from the beginning of the channel to the end of that particular branch.
Page 76 All manuals and user guides at all-guides.com Branch B SLC Loop Channel A Branch D Branch A Branch C Branch E Note: SLC Resistance Measurement When power is removed from the SLC, the positive side of the circuit is opened at each M500XJ isolation module.
Page 77 All manuals and user guides at all-guides.com Channel B Style 6/7 SLC Loop Channel A When T-taps are present they each represent a Total Length of the Style 6 SLC Loop Pair Style 4 branch. These branches will not degrade (including and Style 4 branches): the Style 6 loop and are permissible from an LIB-200 -...
Page 78 All manuals and user guides at all-guides.com LIB Signaling Line Circuit (SLC) loops can be wired to meet the requirements of an NFPA Style 4 (refer to Figure 51), Style 6 (refer to Figure 52), or Style 7 (refer to Figure 53) SLC. Detector Base Pull Stations 2(+)
Page 79 All manuals and user guides at all-guides.com Pull Stations LIB-400 2(+) 1(-) Loop Address Type Photo Their Detectors SLC Loop Connect to chassis via Cable 71073. Earth Ground Modules Channel B (-) No Connection Channel B (+) No Connection All terminals are power-limited. Channel A (-) No Connection Channel A (+)
Page 80 All manuals and user guides at all-guides.com Operation By flanking each SLC loop device, creating zones with a pair of M500XJ Fault Isolator Modules, each device is protected from opens and shorts on all other zones. A zone is defined as one device or equipment enclosure containing addressable points.
Page 81 All manuals and user guides at all-guides.com M500XJ M500XJ Zone 2 Isolator Module Isolator Module Zone 1 Zone 3 M50xMJ Monitor Module M50xMJ Monitor Module or XP Transponder or XP Transponder M500XJ M500XJ Isolator Module Isolator Module nfpastl7 Channel A Channel B LIB-200 SLC Loop Figure 53: NFPA Style 7 SLC...
Page 82: Slc Loop Shield Termination
All manuals and user guides at all-guides.com SLC Loop Shield Termination Use optional shield twisted pair to minimize radiated emissions of radio For an SLC Loop That Is Not frequency energy (refer to Figure 54). Contained in any Do not allow the shield drain wire to enter the cabinet. Connect the drain Conduit wire to the outside of the cabinet via a BX type connector.
Page 83 All manuals and user guides at all-guides.com The M500XJ continuously monitors the circuit by pulsing the coil of an integral relay, which is latched on at power up. A short circuit on the SLC loop resets the relay (refer to Figure 56). Continuation of the Loop Shorts on this branch of an NFPA Style 4 SLC loop will be isolated from all devices...
Page 84 All manuals and user guides at all-guides.com Device Loading Isolator modules are powered from the SLC loop. The internal relay is a and Isolator latching-type relay to limit the isolator’s power requirements. The contact Power Up will open when power is removed. During power up, the relay contact will close when the SLC voltage rises above 7 volts.
Page 85 All manuals and user guides at all-guides.com M502MJ Operating Power The M502MJ requires connection of 24 VDC filtered, regulated, and resettable power on Terminals 3 (-) and 4 (+). This power connection is supervised by the M502MJ. A maximum of 40 M502MJ modules may be installed on a LIB due to increased power consumption over the M500MJ.
Page 86 All manuals and user guides at all-guides.com Figure 60 illustrates an M500MJ monitoring normally open contact fire alarm initiating devices that do not require power and an M502MJ monitoring powered two wire smoke detectors and normally open contact alarm initiating device. Refer to Figure 62 for circuits using four wire detectors.
Page 87 All manuals and user guides at all-guides.com Figure 61 illustrates an M500MJ monitoring normally open contact fire alarm initiating devices that do not require power and an M502MJ monitoring powered two wire smoke detectors. Refer to Figure 63 for circuits using four wire detectors. Notes: For additional ratings, refer to Circuit/Device Ratings and Connections Technical Bulletin (LIT-448160).
Page 88 All manuals and user guides at all-guides.com 24 VDC Four Wire Smoke Detector Power Up to one ampere for four wire smoke detectors can be drawn from TB3 Terminals 1 (+) and 2 (-). Power is removed from these terminals during system reset.
Page 89 All manuals and user guides at all-guides.com Notes: • Place End-of-Line Resistor in series with supervision relay contacts as shown on last detector in loop. • The power supervision relay coil leads must be connected to the last detector base 24V screw terminal. •...
Page 90 All manuals and user guides at all-guides.com UL Listed Power Supervision Relay Black Software Type SCON SLC Loop Channel A M500MJ IDC (+) IDC (-) 24 VDC (+) Software Type PWRC Common (-) M5X0CJ UL Listed 24 VDC Four- Wire Detectors IDC (+) Break tabs.
Page 91 All manuals and user guides at all-guides.com Notes: • The power supervision relay coil leads must be connected to the last detector base 24V screw terminal. • For additional ratings, refer Circuit/Device Ratings and Connections Technical Bulletin (LIT-448160) • The M500MJ shown (when properly programmed) performs the reset function for all smoke detectors connected to the IDC.
Page 92 All manuals and user guides at all-guides.com The M5x0CJ Control Module is an addressable module that supervises Control Module and switches power to a Notification Appliance Circuit (NAC). The M5x0CJ circuit can be wired as an NFPA Style Y or Style Z NAC. Alternately, the M5x0CJ can be employed as a Form-C relay (refer to Figure 64).
Page 93 All manuals and user guides at all-guides.com Shield drain wire does not M5x0CJ connect to M5x0CJ but should continue to the next device. Common UL Listed 24 VDC regulated To next M5x0CJ or to a power-limited power supply for use +24 VDC power supervision relay with Fire Protective Signaling Systems.
Page 94 All manuals and user guides at all-guides.com M5x0CJ M5x0CJ No end-of-line relay Notification required here. Power-limited Appliance Alarm Polarity Shown UL Listed Power Supervision Relay M5x0CJ M5x0CJ No end-of-line relay Notification required here. Appliance Alarm Polarity Shown UL Listed Power TB3-4 (-) TB3-3 (+) Supervision Relay...
Page 95 All manuals and user guides at all-guides.com Listed Power Supervision Relay (Contacts shown in energized position.) 47K ELR, 1/2 Watt Alarm Polarity (A2143-20) Shown Shield Drain Wire To next device on SLC Loop Channel A SLC loop Supervised and Power-limited LIB Channel Terminal 3 (-) M5x0CJ...
Page 96 All manuals and user guides at all-guides.com Alarm Polarity Shown Shield Drain Wire To next device on SLC loop SLC Loop Channel A Supervised and Power-limited LIB Channel Terminal 3 (-) Terminal 1 (+) M5x0CJ Common +24 VDC Notification Appliance Power This power source must be power-limited.
Page 97 All manuals and user guides at all-guides.com SLC Loop Channel A Power-limited and Supervised Shield Drain Wire To next device on SLC Loop M5x0CJ LIB Channel Terminal 3 (-) Terminal 1 (+) Common N.O. Contact N.C. Contact Break off both tabs to enable Form-C operation.
Page 98 All manuals and user guides at all-guides.com Addressable The BGX-101L is an addressable manual pull station with a keylock reset Manual Pull feature (refer to Figure 70). Station PUSH IN THEN PULL DOWN pullstn Figure 70: Addressable Manual Pull Station Hardware Installation—Installing the IFC-1010/2020...
Page 99: Installation
All manuals and user guides at all-guides.com To install: Installation 1. Connect the SLC loop to the BGX-101L. If additional devices are to be connected to the SLC loop after the BGX-101L, use the second pair of screw terminals to continue the loop (see Figure 71 for wiring details).
Page 100 All manuals and user guides at all-guides.com Intelligent These intelligent, addressable detectors provide analog information to the Detectors control panel, which processes this analog information and continually makes decisions on the alarm, maintenance, or normal status of each device. Each detector head mounts to a B501 Base, B501BJ Base, B501BH Base, B524BI Isolator Base, or B524RB Relay Base with sounder for ease of installation or replacement.
Page 101: Smoke Detector Installation
1251J or the 2551J. When sufficient smoke is sensed, an alarm signal is initiated at the control panel. dh500j WARNING: The control panel will only operate with Johnson Controls intelligent addressable devices installed. The B501, B501BJ, B524BI, B524RB, and B501BH provide the Smoke...
Page 102 All manuals and user guides at all-guides.com The smoke detector base is supervised and power-limited. Refer to Circuit/Device Ratings and Connections Technical Bulletin (LIT-448160) for SLC loop rating. Wiring examples of the B524BI Isolator Base and the B524RB Relay Base are detailed in Figure 73 and Figure 74 respectively. Channel Channel SLC Loop...
Page 103 All manuals and user guides at all-guides.com Other Intelligent Devices Twisted Pair Recommendation 1-Comm In (+) 2-Comm Out (+) 3-Comm Out (+) 4-Comm In (-) 11 Relay Listed Compatible Control Panel 10 Normally Closed 9 Normally Open Class A Optional Wiring b524rb Figure 74: Wiring the B524RB Relay Base Hardware Installation—Installing the IFC-1010/2020...
Page 104 All manuals and user guides at all-guides.com M500XJ M5X0CJ M50XMJ M501MJ 12 11 10 9 8 7 6 5 4 3 2 1 BGX-101 B501BJ Base To Next Device on Channel A SLC Loop Maximums: 99 Module Addresses 99 Detector Addresses 40 ohms total loop resistance (LIB-200) 10,000 feet of loop (LIB-200) amslc2...
Page 105: Xp Series Transponder
All manuals and user guides at all-guides.com The XP Series Transponder provides the IFC-1010/2020 system with an XP Series efficient multiplex subsystem capability and standalone operation in case Transponder of failure. The XP Transponder communicates directly with the control panel’s CPU along the SLC communications loop. The XP Transponders are extremely effective in both high-rise and low-rise buildings where power losses over long wiring distances dictate the use of remote control equipment, amplifiers, or audio/visual power...
Page 106 All manuals and user guides at all-guides.com XPM-8/XPM-8L Provides eight Style B (Class B) or four Style D (Class A) Initiating Monitor Module Device Circuits supports conventional two wire smoke detectors and (Power-limited) normally-open contact devices such as pull stations, waterflow and supervisory switches, and four wire smoke detectors;...
Page 107 All manuals and user guides at all-guides.com Serial Communications The IFC-1010/2020 uses serial communication to move data between Optional Serial printers, CRT terminals, and annunciators. The various components used Interface are described here. Boards SIB-2048A The SIB-2048A has two printer and two terminal serial interfaces. The first printer interface supports a PRN Fire Protective Signaling System printer.
Page 108 All manuals and user guides at all-guides.com PRN Printers UL Fire Protective Signaling System Listed printer employing EIA-232 serial interface. CRT Terminals UL Fire Protective Signaling System Listed terminal employing EIA-232 serial interface and UL Listed protocol. Cabling and Male DB-25 connectors (Figure 77) are supplied with remote printers and Connections display terminals.
Page 109 All manuals and user guides at all-guides.com Pair Connection Not in Conduit IFC-1010/2020 SIB DB-25 Connector Connect to Cabinet No Connection (Shield) (Shield) Reference Transmit Receive Reference Receive No Connection Transmit Reference Connect to Pin 1 No Connection DB-25 Connector Pair Connections in Full Conduit IFC-1010/2020 SIB (Shield)
Page 110 All manuals and user guides at all-guides.com EIA-485 Reference Earth Ground EIA-485 (+) EIA-485 (-) EIA-485 (+) EIA-485 (-) EIA-232 Reference Terminals 1-4: Transmit to Printer Provide wiring for one PRN printer to this unsupervised circuit. EIA-232 Reference Receive from Printer Terminals 5-8: Provide connection to the Keltron VS4095/5 printer EIA-232 Reference...
Page 111 All manuals and user guides at all-guides.com The CRT-2 Terminal with keyboard features an 80-column, 25-line CRT-2 Terminal display. Function keys allow all control panel commands to be executed from the keyboard. Primary and The CRT-2 requires 120-240 VAC, 50/60 Hz primary power. A secondary Secondary power source (battery backup) is not provided;...
Page 112 All manuals and user guides at all-guides.com CRT Function The function keys on the CRT are labeled with special IFC-1010/2020 Keys commands. These keys function identical to the keys on the DIA. For a description of these commands, refer to the IFC-1010/2020 Operations Technical Bulletin (LIT-448100) in this manual.
Page 113 All manuals and user guides at all-guides.com The IFC-1010/2020 can employ PRN-4 Remote Printers. This printer Remote provides a hardcopy printout of all status changes within the system and Printers time stamps the printout with the current time of day and date. The PRN-4 provides 80 columns of data on standard 9 inch by 11 inch tractor-feed paper.
Page 114 All manuals and user guides at all-guides.com Printer Refer to the documentation supplied with the PRN-4 for instructions on Configuration the printer’s menu controls. Table 11: Printer Configuration (Set these printer options.) Control Setting L/R Adjust HS Draft Font 6 CPI Esc Character Bidirectional copy CG-Tab...
Page 115 All manuals and user guides at all-guides.com 50 feet Maximum SIB-2048 PRN-4 Remote Printer (Typical) or SIB-NET Wiring distance limited by cable capacitance. See EIA-232E standard. SIB (Connector P3) EIA-232 Reference Twisted Pair Transmit to Printer EIA-232 Reference Twisted Pair Receive from Printer Plug this DB-25 connector into the EIA-232 port of the printer.
Page 116 All manuals and user guides at all-guides.com Keltron Printer Model No. VS4095/5 50 feet Maximum SIB-2048 (Typical) or SIB-NET Wiring distance limited by cable capacitance. See EIA-232E standard. SIB Connector P3 (Power-limited) Twisted Pair Twisted Pair Plug this DB-25 connector into the EIA-232 port of the printer.
Page 117 All manuals and user guides at all-guides.com Notes: Outputs are power limited and are not supervised. Connections must be made with overall foil/braided-shield twisted paired cable suitable for EIA-232 applications. The SIB can employ two printers. Set the DIP switches as follows: SP1-1 SP2-1 SP1-2...
Page 118 All manuals and user guides at all-guides.com LDM-32 The LDM-32 Lamp Driver Annunciator Module provides 32 alarm or 16 alarm and 16 trouble lamp driver outputs, corresponding to 32 annunciator points, which can be connected to external devices such as a custom graphic annunciator.
Page 119 All manuals and user guides at all-guides.com aem32 Figure 86: AEM-32A SCS-8 The Smoke Control Station (SCS-8) module uses eight groups of four annunciator points for fan shutdown control or other heating, ventilation or air conditioning functions. SCE-8 The Smoke Control Expander (SCE-8) is used to expand the SCS-8 by an additional eight groups of four annunciator points.
Page 120 All manuals and user guides at all-guides.com sce8 Figure 87: SCS-8 EIA-485 Reference SIB-2048A CPU-2020 or SIB-NET or CPU-2 EIA-485 circuit characteristic impedance of twisted-pair wiring should be approximately 120 ohms. EIA-485 Reference 120 ohms, 6 5 4 3 2 1 6 5 4 3 2 1 1/4 watt P10 P9 P8 P7...
Page 121 All manuals and user guides at all-guides.com The EIA-485 Reference (P5-1) for the SIB must be connected to any ACS device that is not within the same cabinet. Connect P5-1 of the SIB to: • AMG-1 at P3-1, P3-2 • ACM-16AT at TB1-4 •...
Page 122 All manuals and user guides at all-guides.com Hardware Installation—Installing the IFC-1010/2020...
Page 123 All manuals and user guides at all-guides.com Standard-Specific Requirements The IFC-1010/2020 is an expandable multiplex Fire Alarm Control Panel (FACP) designed for use in commercial, industrial, and institutional applications. These panels meet the requirements for service under the National Fire Protection Association (NFPA) and Underwriters Laboratories (UL) Standards outlined in this chapter.
Page 124 All manuals and user guides at all-guides.com NFPA 72-1999 M5x0CJ Control Module installed on SLC Loop 1 and set to Module Protected Address 96. This unit must be installed as outlined in Figure 67 or Premises (Local) Figure 68 (notification appliances). Fire Alarm Systems NFPA 72-1999...
Page 125 All manuals and user guides at all-guides.com This unit must be installed in accordance with the following requirements: • Monitor modules located within the protected premises that are responsible for supervising the state of the protected premises control unit may be programmed for Tracking (non-latching) operation. Notification appliances and control relays will follow the tracking devices programmed to activate them.
Page 126 All manuals and user guides at all-guides.com For connection of initiating devices and modules in this system, refer to NFPA 72-1999 Figure 59 through Figure 63. This application is not suitable for separate Auxiliary Fire transmission of sprinkler supervisory or trouble conditions. For additional Alarm Systems ratings, refer to Circuit/Device Ratings and Connections Technical Bulletin (LIT-448160).
Page 127 All manuals and user guides at all-guides.com Generating Event-Pending Signals at a Remote Location Uninterruptable Power Supply UL Listed for Fire Protective Signaling Must be supervised by control panel. CRT with Keyboard remove or lock up keyboard. MA-241 Control Module (M5XCJ) programmed for Multi-Alert Sounders used to signal a pending trouble software Type TPND.
Page 128 All manuals and user guides at all-guides.com All connections are supervised and power limited. The M500MJ software Supervising an Type ID MTRB may be used to monitor either normally closed or Uninterruptable normally open supervisory contacts, as illustrated in Figure 91. An open Power Supply or a short condition on the circuit will produce the message POINT TROUBLE on the display.
Page 129 All manuals and user guides at all-guides.com NFPA 72-1999 Proprietary Fire Alarm Systems Fire Alarm, All LIBs are power-limited. If the wiring connected to the LIB-200 leaves Security Alarm, the building it must be in conduit. It can not exceed 1,000 meters and Trouble (10,000 feet), must not cross any power lines, and must not be in the Signal...
Page 130 All manuals and user guides at all-guides.com IFC-1010/2020 Central Station IFC-1010/2020 (Master) Protected Premises Control Unit (Remote) INTELLEGENT FIRE DETECTOR AND ALARM SYSTEMS TOR AND ALARM SYSTEMS SIB-2048A SIB-NET LIB-200, LIB-200A, or LIB-400 NIB-96 EIA-485 Loop OUT To additional EIA-485 devices if Installed.
Page 131 All manuals and user guides at all-guides.com The application provided in Figure 92 is not suitable for separate Fire Alarm and transmission of sprinkler supervisory signals. All circuits are supervised Trouble Signal and power limited. 18 AWG (0.75 mm ) is the minimum. There is a Transmission maximum loop resistance of 40 ohms for the LIB-200.
Page 132 All manuals and user guides at all-guides.com After completing the proper installation of all boards, cables and Applying/ components, apply power in the following manner: Removing Power to the • Apply AC power. Fire Alarm • Connect the battery/secondary power terminals (refer to Connecting System the Main Power Supply section in this document).
Page 133 Notes The IFC-1010/2020 product is listed as a UL Multiple Listing, in association with its original manufacturer. This allows Johnson Controls to provide the latest products, upgrades, and updates available from the manufacturer to the customer at the fastest rate and lowest cost. To conform to this UL Multiple Listing process, this documentation must closely reflect that which is distributed by the product’s original...
Page 134 All manuals and user guides at all-guides.com Note Section Note Number (Cont.) LIB SLC Loop The term zone is used here to describe either a segment of a Style 7 SLC Wiring loop or a T-tapped branch of a Style 4 SLC, which contain a number of Requirements: addressable devices (25 maximum) that are separated from the remainder of Operation...
Page 135 Backboxes Component The NAM-232 can only be used with Release M2.8 firmware. The NAM-232 Placement cannot be used with the IFC-1010/2020 in any Johnson Controls supported configuration. Component LIB-200A and LIB-400 can only be used with Release 2.8 firmware. Placement Secondary, The MPS-24A/E is UL Listed as a Special Application power supply.
Page 136 All manuals and user guides at all-guides.com Note Section Note Number (Cont.) NVRAMS The MPS-24A/E is UL Listed as a Special Application power supply. NVRAMS The MPS-24A/E is UL Listed as a Special Application power supply. Therefore, only notification appliances that are compatibility listed in the Device Compatibility Technical Bulletin (LIT-445180) may be used with the system if powered by the MPS-24A/E.
