Introduction

1.9 LED Operation

The table below lists the LED operation on the various devices of an SLC in CLIP (Classic Loop
Interface Protocol) Mode and FlashScan® Mode. When switching from FlashScan® to CLIP
mode, the loop circuit must be powered down for at least 30 seconds to reset devices to CLIP mode
LED operation.
Control Panel Device
IFC-1010 Monitor Module
IFC-2020 Control Module
Detector
IFC-300/IFC-400 Monitor Module
Control Module
Detector
IFC-200 Monitor Module
Control Module
Detector
IFC-320/E/C, IFC2- Monitor Module
640/E, IFC-640/E, Control Module
IFC-3030, Detector
IFC2-3030
NOTE: In CLIP mode, the 7251J and FTX-P1J blink GREEN in standby and stay RED when
activated.
16
CLIP Mode
Standby Activated
Blinks RED RED continuous
Blinks GREEN 2 sec. GREEN, then
Blinks RED OFF
RED continuous
Blinks RED RED continuous
Blinks GREEN GREEN continous
Blinks RED RED continuous
Blinks RED RED continuous
Blinks GREEN OFF
Blinks RED RED continuous
Blinks RED RED continuous
Blinks GREEN GREEN continuous
Blinks RED RED continuous
Johnson Controls, Inc. SLC Wiring Manual — P/N 51870:G 04/23/2009
LED Operation
FlashScan® Mode
Standby Activated
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
Blinks GREEN RED continuous
Blinks GREEN GREEN continuous
Blinks GREEN RED continuous
