1.2 S2928 Systematic Characteristic Parameters

Supported
standard
Protoc
ol
standa
rd
Network
management
standard
Memory
Standard
configuration
Dimensions
(W×D×H)
Operating
temperature/
humidity
Storage
temperature/
humidity
Power
characteristics
Power
consumption
IEEE 802.1d Spanning Tree Protocol
IEEE 802.1s multiple spanning trees
IEEE 802.1p Class of Service
IEEE 802.1q tagged VLAN
IEEE 802.3x Flow control
IEEE 802.3z asymmetric flow control
IEEE 802.3ad Link aggregation
RFC 1157 SNMP v1/v2
RFC 1213 MIB II
RFC 1757 RMON 1,2,3,9
Flash Memory: 16M Bytes
SDRAM: 128M Bytes;
24 10/100/1000BASE-T ports
4 10G SFP+ ports
4 gigabit SFP ports
1 Console port
mm 440*180*44
0℃～45℃; 10%～85% non-condensation
-40℃～80℃; 5%～95% non-condensation
input voltage AC100 ～ 240V, input frequency
47～63Hz
input current: 1.2A (MAX)
output voltage: 12VDC
output current: 6A(MAX)
35W
