  • Page 1 BDCOM S6508 Switch Hardware Installation Guide...

  • Page 2: Table Of Contents

    Content Table of Content Chapter 1 Information of BDCOM S6508 Switch........................1 1.1 Overview................................1 1.2 Features ................................1 1.3 S6508 Switch View..............................2 1.4 S6508 Switch Hareware composing........................3 1.4.1 Rack ................................3 1.4.2 Chassis..............................3 1.4.3 System module Slots..........................6 1.4.4 Power Supply ............................
  • Page 3 4.4.2 check version of software and hardware....................44 4.4.3 source of S6508 IOS..........................45 4.5 Install and upgrade S6508 IOS........................... 45 4.5.1 Installation and upgradation about S6508 system softerware..............45 4.5.2 update configuratation..........................49 4.5.3 Bootrom upgrade............................. 49 - II -...
  • Page 4 Content 4.5.4 upgrade in CLI(command line interface) ....................51 4.6 basic step of configing S6508..........................52 4.7 upload and download configuration file ....................... 53 Chapter 5 S6508 maintenance............................54 5.1 S6508’s monitor function ............................. 54 5.2 run diagnose function in s6508..........................54 5.3 S6508 hardware maintenance..........................

  • Page 5: Chapter 1 Information Of Bdcom S6508 Switch

    So ShangHai Baud Data Communication Co., Ltd. Provide a business ethernet scheme to support this application for business ISP, BDCOM S6508 is a switch that can be managned for buseniss ethernet. S6508 provides user network manage function and mutlilayer switch function, it also provides high performance in multilayer switch with wire speed, and provides various charge mode.

  • Page 6: S6508 Switch View

    Agile charge method. User bandwidth and priority control base on RADIUS. Use standard switch struct, can expand to other non-ethernet module. 1.3 S6508 Switch View S6508 Switch is a 10-slot vertical chassis. Figure 1-1 shows the S6508 Switch chassis. （1） （2） （3）...

  • Page 7: S6508 Switch Hareware Composing

    1.6m metal Rack（H×W×D =1600mm×600mm×600mm） 1.4.2 Chassis The S6508 Chassis is 19 Inchs Chassis, The chassis hight is 670mm（15U）, width is 440mm, depth is 455mm. The chassis include Airflow exhaust, Fan assembly, System module Slots, Airflow intake and Power Supply Slots.
  • Page 8 BDCOM S6508 Switch Hardware Installation Guide Figure 1-2 S6508 front View (1)LPU slot: there are 8 LPU slots, the LPU module such as LS65-32FE-TX, LS65-4GE-TX/SFP and LS65-16FE-SFP can be pluged in the Slots. (2)MSU slot:there are 2 MSU slots,only support LS6508-MSU.
  • Page 9 BDCOM S6508 Switch Hardware Installation Guide Figure 1-3 S6508 side view (1) Airflow intake: the system module air inlet. (2) Chassis handle: can be used to move the S6508. (3) Airflow exhaust: the system module air exhaust. - 5 -...

  • Page 10: System Module Slots

    System module Slots include the slot guides and the backplane. The S6508 chassis have 10 system module Slots, the space between the two near Slots is 40mm. The slots is vertical.The Slots number is ordinal, from left to right is Slot 1 to Slot 9.

  • Page 11: Power Supply

    LS65-16FE-SFP The system module’s height is 370mm, depth is 370mm. 1.4.4 Power Supply S6508 support AC-Power Input or DC-Power Input.There are 2 type Power supply module(AC-Power supply module and DC-Power supply module ) are supported in S6508. 1. DC-Power Supply When you want to use DC Supply input, you can use LS65-PWR-DC-800 module.The...
  • Page 12 There are 3 Type S6508 Chassis:Double-AC Power Chassis; Double-DC Power Chassis; AC＋DC Power Chassis. For difference environment, user can choose the type S6508 chassis. The following describes the difference between the 3 type chassis. Double-AC Power Chassis: the chassis’s Slot PowerA and Slot PowerB only Support LS65-PWR-AC-800 module.

  • Page 13: S6508 Switch Airflow

    Figure 1-9 AC＋DC Power Chassis Rear View 1.5 S6508 Switch Airflow S6508 operate at 0－40℃, The system fan assembly provides cooling air for the MSU modules and the LPU modules. Sensors on the MSU modules monitor the internal air temperatures. If the air temperature exceeds a preset threshold, the TEMPALM LED turns red.

  • Page 14: S6508 System Module Overview

    BDCOM S6508 Switch Hardware Installation Guide Figure 1-10 S6508 Switch internal Airflow 1.6 S6508 system module overview S6508 have 5 type system modules.One is MSU module,the other four are LPU modules. System Management and Switching Unit module（LS6508-MSU）: is the MSU module.

  • Page 15: System Management And Switching Unit Module (Ls6508-Msu)

    System Management and Switching Unit module (LS6508-MSU) Figure1-11 is System Management and Switching Unit module（LS6508-MSU）front view. LS6508-MSU is the center of Ethernet Switching.Manage and Control the S6508 system.The chassis provides 2 Slot （Slot 5 and Slot6）for the LS6508-MSU modules. When two LS6508-MSU modules are all pluged in Slot 5 and Slot 6, one module will operate at Master status, the other module will operate at Slave status.Then the...
  • Page 16 BDCOM S6508 Switch Hardware Installation Guide Figure 1-11 LS6508-MSU front view 1. Port LS6508-MSU module provides three Port: Console port, AUX port, 10/100Base-T Ethernet port. 2. LED There are 7 LEDs on the LS6508-MSU front panel.Table1-2 decribes the LEDs means.

  • Page 17: 4-Ports Gigabit Tx/Sfp Module（Ls65-4Ge-Tx/Sfp

    BDCOM S6508 Switch Hardware Installation Guide LED Name Decription Green means that the MSU module can be hot-pluged out SWAP Off means that the MSU module can not be hot-pluged out Green means that the MSU Module is Power On Off means that the MSU Module is Power Off Flashing Green with 0.5Hz frequency...
  • Page 18 BDCOM S6508 Switch Hardware Installation Guide Figure 1-12 LS65-4GE-TX/SFP front view 1. Port LS65-4GE-TX/SFP module provides 4 switched, full-duplex Gigabit Ethernet Ports. Every port have one RJ45 Connector and one SFP module connector. RJ45 Connector Support Category 5 UTP cable. SFP module Connector support any Gigabit SFP module include 1000BASE-SX, LX/LH, and ZX SFPs, or copper SFPs.

  • Page 19: 4-Ports Gigabit Sfp Module（Ls65-4Ge-Sfp

    BDCOM S6508 Switch Hardware Installation Guide 2. LED Table 1-4 LS65-4GE-TX/SFP module LEDs Decription Localtion LED Name Decription Green means that the Port is active（the link is connected and In the middle operational）. LINK of the RJ45 Off means that the Port is No link.
  • Page 20 BDCOM S6508 Switch Hardware Installation Guide Figure 1-13 4-Ports Gigabit SFP Module（LS65－4GE－SFP）Panel View 1. Port LS65-4GE-SFP module provides 4 switched,full-duplex Gigabit Ethernet Ports.The ports have SFP module connectors for 1000BASE-SX, LX/LH, and ZX SFPs, or copper SFPs. 2. LED Table 1-6 LS65－4GE－SFP module LEDs Decription...

  • Page 21: 16-Port 100Base Sfp Module （Ls65-16Fe-Sfp

    BDCOM S6508 Switch Hardware Installation Guide Localtion LED Name Decription Green means that the Port is active（the link is connected and operational）. LINK On the top of Off means that the Port is No link. ever module Green means that the Port is Activity, Port is transmitting or Connector receiving data.

  • Page 22: Led Description

    BDCOM S6508 Switch Hardware Installation Guide Figure 1-14 LS65-16FE-SFP module front view 1. Port LS65-16FE-SFP module provides 16 switched 100-Mbps full-duplex ports.The 16 ports have SFP module connectors for 100BASE SFP modules. 2. LED Description Table 1-8 LS65-16FE-SFP module LEDs Decription...

  • Page 23: 32-Port 10/100Base-Tx Module（Ls65-32Fe-Tx

    BDCOM S6508 Switch Hardware Installation Guide Localtion LED Name Decription Green means that the Port is active（the link is connected and operational）. On the top of LINK/ACT Flashing Green means that the Port is Activity,Port is Panel transmitting or receiving data.
  • Page 24 BDCOM S6508 Switch Hardware Installation Guide Figure 1-15 32-Port 10/100BASE-TX Ethernet Switching Module（LS65-32FE-TX） 1. Port LS65-32FE-TX module provides 32 switched 10/100-Mbps autosensing, full or half-duplex ports. The 32 ports have RJ45 connectors for Category 3, Category 5, Category 5e, or Category 6 UTP or FTP cable.
  • Page 25 BDCOM S6508 Switch Hardware Installation Guide Localtion LED Name Decription Green means that the Port is operating at 100Mbps. SPEEP Off means that the Port is not operating at 100Mbps. Orange means that the Port is active （the link is connected and...

  • Page 26: Chapter 2 Preparing For Installation

    Do not do anything that causes damage to human or device. 2.1.2 Safety principal of Moving Because the S6508 chassis is large and weight, before moving the chassis, read the following note: S6508 Weight is about 60kg, Avoid to move the chassis frequently.

  • Page 27: Safety Principal Of Operation With Electricity

    Before install, Must know the location of the room’s Power switch. Do not maintenance the S6508 with power on by one person alone. Do not place the chassis in the wet room, also do not allow the liquid inpour the chassis.

  • Page 28: Laser Warning

    2.2.1 Reqirements of the rack If the S6508 is planed to be installed in a rack, please confirm that the following requirements should be reached. It’s better to install the switch in openning rack. If the rack is closed, please confirm that the rack have good airiness for cooling system.

  • Page 29: Temperature And Humidity

    BDCOM S6508 Switch Hardware Installation Guide Figure 2-2 S6508 airflow 2.2.3 Temperature and Humidity To guarantee that S6580 can work smoothly, the temperature and humidity of the operational environment should be under control. Otherwise, the equipment may be damaged. High-humidity conditions can cause moisture migration and penetration into the system.

  • Page 30: Air Environment

    Extreme temperature fluctuations can cause chips to become loose in their sockets. So, the temperature and humidity must be carefully controled to meet the requirements as illustrated in table 2-1: Table 2-1 S6508 requirements for temperature and humidity Temperature Relative humidity Long term...

  • Page 31: Power Supply Condition

    BDCOM S6508 Switch Hardware Installation Guide sulfur dioxide 0.006 0.03 sulfureted hydrogen 0.04 0.15 nitrogen dioxide 0.05 0.15 gaseous ammonia 0.01 chlorine Do not permit smoking anywhere near the system. Do not permit food or drink near the system. 2.2.5...

  • Page 32: The Grounding Of Emc

    BDCOM S6508 Switch Hardware Installation Guide 2.3.3 The grounding of EMC The grounding of EMC includes: screen grounding, rejector grounding, yawp and jam control, voltage reference. The upwards description come into being the integrate require of grounding. The grounding resistance must be less than 1Ω.

  • Page 33: Fiber-Optic Connectors Note

    Expert tools multimeter Meter S6508 equipment is no saddlebag, so those tools need to be prepared by users. 2.5 Requirement of checking The equipment is sent according to the compact,the consignee must check the equipment by opening the package according the compact.

  • Page 34: Checking Equipment

    BDCOM S6508 Switch Hardware Installation Guide 2.5.1 Checking Equipment 1. Wrappage of equipment chassis Confirm that all kinds of faceplate in the equipment are installed OK. Confirm that the power modul of the equipment is the AC modul or DC modul whitch required in the compact.

  • Page 35: Record Local Log

    BDCOM S6508 Switch Hardware Installation Guide 2.5.2 Record local log After check all,please labeled on the transport box,and take the relevant record. Each equipment must have a local log record, including these information: produce date, debug record, software and hardware version number, product series number.

  • Page 36: Chapter 3 Installing Switch

    BDCOM S6508 Switch Hardware Installation Guide Chapter 3 Installing switch Before install the S6508, please confirm that the chapter 2 has be readed. Please confirm that the principals are all reached. 3.1 Installing flow Prepartion before install S6508 Install rack...

  • Page 37: Site For Installing

    BDCOM S6508 Switch Hardware Installation Guide 3.2 Site for installing Planning a proper location for the switch and layout of your equipment rack or wiring closet is essential for successful system operation. Please confirm that the following requirements are reached: The Site have enough air flowing in the switch.

  • Page 38: Installing Steps

    Setting the 19’’ Rack in the appointed place, and fixing it. Install the cable guides and the connection cable. Bases the actual instantce, install the stock in the Rack. 3.4 Installing the S6508 chassis in Rack 3.4.1 Notice proceeding Before installing the chassis in rack, check the location of the brackets are suitable.

  • Page 39: Notice Proceeding

    BDCOM S6508 Switch Hardware Installation Guide Figure 3-1 The system ground of S6508 3.5.1 Notice proceeding 6 AWG wire is recommended. Do not use naked wire. The resistance value between the house’s ground connector and the chassis’s ground connector should be less than 1Ω.

  • Page 40: Notice Proceeding

    BDCOM S6508 Switch Hardware Installation Guide Figure 3-2 DC-wires Connecting 3.6.1 Notice proceeding Before connecting the DC Power supply,Verify that the DC input reach the DC-Power supply required. Before connecting the AC Power supply,Verify that the power switch is the off(0) position.

  • Page 41: Notice Proceeding

    BDCOM S6508 Switch Hardware Installation Guide Figure 3-3 AC-wires Connecting 3.7.1 Notice proceeding Before connect the AC Power supply, please verify that the AC input reach the AC-Power supply required. Before connect the AC Power supply, please verify that the power switch is the off(0) position.

  • Page 42: Removing The System Module

    BDCOM S6508 Switch Hardware Installation Guide 3.9 Removing the system Module 3.9.1 Removing steps Disconnect any network interface cables attached to the module. Loosen the two captive screws on the module. Place your thumbs on the ejector levers, and simultaneously rotate the levers outward to unseat the module from the backplane connector.

  • Page 43: Installing The System Module

    BDCOM S6508 Switch Hardware Installation Guide 3.10 Installing the system module 3.10.1 Installing steps Choose a slot for the module. Remove the module from the choosed slot as 3.9, if there is the other module is installed in the choosed slot.

  • Page 44: Packing Steps

    BDCOM S6508 Switch Hardware Installation Guide Don’t pack fiber and cable too tightly so that avoid pressuring on the cables to reduce service life and performance of cables. 3.12.2 Packing Steps Pack pendent fibers and cables of all modules, and make them to branch either side of the chassis according to convenience.

  • Page 45: Chapter 4 System Debug

    BDCOM S6508 Switch Hardware Installation Guide Chapter 4 System debug 4.1 Debug flow Finish Installation Set up cofiguration envirament Pre-check Start system Check Init status Is software exist? Install software Config parameter Run self-test Debug over 4.2 set up configurable environment 4.2.1...
  • Page 46 BDCOM S6508 Switch Hardware Installation Guide Figure 4-1 set up local configurable enviroment by console Run hyperTerminal program(like Terminal in Windows 3.1 system or hyperTermial want please selet [program]->[accessary]->hyperTerminal, as shown in figure 4-2. Figure 4-2 new connection Set up a connection, and set connection port, as shown in figure 4-3.
  • Page 47 After POWER on, system will run self-checking, after self-checking, switch will prompt user to input <ENTER>, until command prompt string is displayed. Input command, config S6508 or watch S6508 run-time status, if you need help, you can input “?” at any time, specific information about command see 《S6508 Switch command manual》.

  • Page 48: Check The Status Before System Operating

    4.4 start system and watch initialization status 4.4.1 start system Usually, software of S6508 should have been installed, software is stored in flash media of board, so system can normally run once power on. 4.4.2 check version of software and hardware After system power on, users should check version, ensure it is a legal, release version.

  • Page 49: Source Of S6508 Ios

    1. download switch.bin by TFTP method Run S6508 system software of MSU, setup configurable enviroment as mentioned in 1.2, Connect PC’s COM port to console of primary MSU of s6508. TO finishe installation or upgradation of system software, Use following step to download system software to MSU.
  • Page 50 BDCOM S6508 Switch Hardware Installation Guide Figure 4-5 startup image Config ethernet ip address monitor#ip address <ip_addr> <net_mask> Patameter explanation: ip_addr: IP address net_mask: network mask For example: monitor#ip address 192.168.1.1 255.255.255.0 Test network by ping command monitor#ping <ip_address> <ip_address>: target ip address,...
  • Page 51 TFTP:successfully receive 3377 blocks ,1728902 bytes monitor# 2. download system software by zmodem protocal Run s6508 system software of MSU, setup configurable enviroment as mentioned in 1.2, Connect PC’s COM port to console of primary MSU of s6508. TO finishe installation or upgradation of system software, Use following step to download system software to MSU.
  • Page 52 BDCOM S6508 Switch Hardware Installation Guide Figure 4-6 startup image Input download command, ”?” will get help monitor#download c0 <local_filename> This command can copy file to flash by zmodem protocal. Parameter explanation: local_filename is the filename which is saved in flash, users must input the filename.

  • Page 53: Update Configuratation

    BDCOM S6508 Switch Hardware Installation Guide Figure 4-7 send file dialog Figure 4-8 z-modem download image Following information will display after transfer file finished Zmodem receive process completed. Software transfer successfully, and should reset baudrate of hyperTerminal to 9600bps. 4.5.2 update configuratation Switch’s config is stored in file, file name is startup-config, user can upgrade...
  • Page 54 BDCOM S6508 Switch Hardware Installation Guide 1. The steps of downloading the Bootrom by TFTP Run s6508 system software of MSU, setup configurable enviroment as mentioned in 1.2, Connect PC’s COM port to console of primary MSU of s6508 TO finishe installation or upgradation of system software, Use following step to download system software to MSU.

  • Page 55: Upgrade In Cli(Command Line Interface)

    BDCOM S6508 Switch Hardware Installation Guide prompt: Source file name[]?boot.bin prompt: Remote-server ip address[]?192.168.20.1 please wait ... ################################################################### ################################################################### ################################################################### ############################################# TFTP:successfully receive 524288 bytes Please wait for update Bootrom... Successfully update Bootrom monitor# 4.5.4 upgrade in CLI(command line interface) In order to convenient to upgrade software for on-line manufacture, the system software provide that upgrade the system software itself and Bootrom software.

  • Page 56: Basic Step Of Configing S6508

    BDCOM S6508 Switch Hardware Installation Guide For example: get a file named main.bin from server, and wirte it to switch store media switch#copy tftp flash prompt:Source file name[]?main.bin prompt:Remote-server ip address[]?192.168.20.1 prompt:Destination file name[main.bin]?switch.bin please wait ... ################################################################ ###### ################################################################...

  • Page 57: Upload And Download Configuration File

    Whole step can refer to chapter “upload and download configuration file”. In order to use the current configuration into the incept configuration of S6508, please use “write” command to save the current configuration into incept configuration files of flash.

  • Page 58: Chapter 5 S6508 Maintenance

    Chapter 5 S6508 maintenance 5.1 S6508’s monitor function When S6508 is running, users can watch led status of each board to decide staus of board. If RUN led is off or blink, probably the board has some hardware or softeware fault.

  • Page 59: Power Supply Maintenance

    5.4 remote maintenance S6508 supports remote maintenance. Users can log on switch by utilizing telnet method through internet. If switch have been connected to internet, user can log on switch by telnet method, execute all commands, and run remote maintenance.

  • Page 60: Chapter 6 Hardware Troubleshooting

    BDCOM S6508 Switch Hardware Installation Guide Chapter 6 Hardware Troubleshooting - 56 -...

  • Page 61: The Universal Flow Of Checking Installation Trouble

    BDCOM S6508 Switch Hardware Installation Guide 6.1 The universal flow of checking installation trouble - 57 -...

  • Page 62: Trouble Shooting Of Losting Switch Password

    BDCOM S6508 Switch Hardware Installation Guide 6.2 trouble shooting of losting switch password 【trouble 1】 The login password of system is lost. 【trouble description】 The system login password of switch is lost or forgotten, and cannot config the data. 【trouble shooting】...

  • Page 63: Trouble Shooting About The Module Installation

    BDCOM S6508 Switch Hardware Installation Guide 【trouble shooting】 First,set the switch of all power supply module to OFF status. Check if the connection of the chassis is correct. Check if DC feed-in connection is correct. If necessary, remove power supply module,and check if the connection between power supply module and plug on backboard is loose.

  • Page 64: Trouble Shooting About Software Installation

    BDCOM S6508 Switch Hardware Installation Guide 6.4 trouble shooting about software installation 【trouble 1】 Serical port console is no output. 【trouble description】 After power on, no prompt information in serical console. 【trouble shooting】 First confirm console cable is connected rightly, or cable is broken, connected COM port is justly port that hyperTerminal program specify.

  • Page 65: Chapter 7 Appendix

    BDCOM S6508 Switch Hardware Installation Guide Chapter 7 Appendix 7.1 Identification,Package,Transport,Stockpile 7.1.1 Identification in product Product Name:“S6508”. 7.1.2 Identification in Package Product Name:“S6508”. Company Name:“ShangHai BDCOM”. Produce Area:“Made in China”. Leave factory series number. 7.1.3 Produce Area ShangHai China 7.1.4...

  • Page 66: Transport

    BDCOM S6508 Switch Hardware Installation Guide Figure 7-1 Equipment package Figure 7.1.6 Transport Transport by ship, plane, truck. Used canopy avoid rainwater in trasport. Gently move it. 7.1.7 Stockpile Stockpile location: Repository. Stockpile condition Temperature: -25 C~55 Humidity: 40%~90%. Without caustic gas in air Stockpile requirement Stack height:three layers by outside—package.

  • Page 67: Tools Of Open And Close The Package

    BDCOM S6508 Switch Hardware Installation Guide 7.2 Tools of open and close the package Tools of open the package tommy bar, knife. Tools of close the package Knife, adhesive tape, nail, hammer, pack band, packer. 7.3 Other 7.3.1 Files in the package...
